Dear Hisense Customer,
We appreciate for your buying Hisense products, and believe that this wholly new product can bring you
infinite pleasure. Before using the TV, Please read this manual thoroughly, retain it for future reference.
Our company does not assume any liability for any accident arising from violation of the matters of
attention and instruction on use in this manual.
海信香港客服热线:00852-27811789
海信集团服务质量监督电话:0086-0532-83091111
This product involves high voltage. The user may not open the cabinet without authorization. Any
person other than the repairer may not repair and replace parts without authorization to avoid shock
and fire accidents.
WARNING
Please clean and maintain the entire TV set with clean and soft cotton cloths, and repeated forcible
cleanings are prohibited.
The screen may not be scribed, tapped, impacted with hard objects or rubbed with any grinding
CAUTION
materials.
During placement and use, the product should be kept from water droplet and splash. In case of
adverse weather e.g. thunderstorm, the power plug and cable TV (or outdoor antenna) plug shall be
rapidly pulled off to avoid damage due to lightning strike.
The TV set is a Type II equipment, and used without requiring grounding.
Attention:
Still images can result in permanent damage to TV screen.
1. The time for displaying static images on the LCD TV screen may not exceed 2 hours, or otherwise it will
result in residual image on the screen. To avoid this, you need to lower the screen brightness and contrast
when displaying the still images.
2. When viewing 4:3 format program over long time, different traces will be left on the left and right sides of
the screen and the edge of margin. So the user is advised not to use such pattern over long time.
3. Long-time display of electronic games and computer static images may result in local residual image, and
the screen may get burnt and result in residual image on the screen. To avoid this, you need to lower the
screen brightness and contrast during use.
For any image residual shadow, local residual image and trace problems with the TV screen due to the
said reasons, the display screen is not within the range of warranty.
Tips for energy saving:
1. Please choose AC power off (turn off the TV through the power switch) when not viewing TV program to
minimize energy consumption.
2. Under condition that the view quality is not impacted, reduce the brightness of display screen to minimize
the energy consumption of TV during use.
Check the Symbol
Triangle enclosing a lightning arrow is a warning symbol,
reminding you of the high voltage danger in the product.
Triangle enclosing an exclamation mark is a warning
symbol, reminding you of the important notes related to
the product.
General notes.
Preface
The correct way.
×
The wrong way.
->
Next step.
I

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LTDN32K560HK3D and is the answer not in the manual?

Questions and answers

Summary of Contents for Hisense LTDN32K560HK3D

  • Page 1 Preface Dear Hisense Customer, We appreciate for your buying Hisense products, and believe that this wholly new product can bring you infinite pleasure. Before using the TV, Please read this manual thoroughly, retain it for future reference. Our company does not assume any liability for any accident arising from violation of the matters of attention and instruction on use in this manual.
  • Page 2 New generation backlight source with the 4 cutting edges of magnificence, New generation backlight source with the 4 cutting  edges of magnificence,  Built-in WiFi wireless network function Capable to connect to wireless router directly for surfing on Internet. Small to Big/Big to Small Capable to interconnect between TV and mobile, Hisense I’TV, meet family entertainment sharing needs. Family share Easy to share picture, music and video display with extern mobile terminal Easy to share picture, music and video display with  extern mobile terminal  Hisense Community Hisense “envelope” special forum consists of how to use the device, experiences exchange, resource sharing, happiness  interchange and enjoy deposit. Magnitude Application The device carries Hisense App store and gfan market, provide magnitude Apps for users to download. SRS TruSurround XT sound effect Make TV audio more real and more shocking. Multi-Mode Widescreen Display Provide with multiple aspect ratio choice: full screen, normal, zoom in one, zoom in two, intelligence panorama, point to point. Power Saving Mode The device will enter sleep or standby mode after there is no input signal 15 minutes later, thus extending the device lifetime ...
  • Page 3 Specifications Model LTDN32K560HK3D LTDN42K560HK3D LTDN47K560HK3D LTDN55K560HK3D 738×450×63 971×582×61 1081×644.5×61 1255×744×62 Without stand Dimension (W × H × D) (mm) 738×501×200 971×639×250 1081×701.5×250 1255×802×330 With stand Without stand 8 13.5 15.5 23 Weight (kg) 9.3 16 18 27 With stand LCD Panel 80...
  • Page 4 Important Safety Instructions Alerts: Before using the product, please read the following clauses carefully. Power and signal Please do not cover or block the heat-radiating holes in order  not to hamper the unit to give off heat. When it is rainy, please pull out the power plug, CATV plug or  outside antenna plug to avoid any possible damage to the TV  Please do not stick the sharp objects, metal, or liquid into or  set. Do not touch the inducting wire of the antenna. use them to touch the signal interface or heat-radiating holes  in case of short circuit or damage to the product. If you do not use the product for a long time, please pull out  the power plug. Method of placement Please do not press the power line and signal line with other  things. √ Even and steady occasions.  Please do not make the power outlet overloaded, or it will  × Places under direct sunshine or close to heating devices.  result in the danger of fire. × Places with poor ventilation.  Keep the power line away from high temperature and heating ...
  • Page 5: Table Of Contents

    Contents Accessories List  . ............................................................................................... 2 G e t t i n g Installing the Stand ........................................................................................... 3 S t a r t e d Securing the Installation Space ........................................................................ 4 Control Pane  . .................................................................................................... 5 Remote Control ................................................................................................ 6 TV Terminal ...................................................................................................... 9 Connections Connecting an Antenna or Cable ................................................................... 10 Connecting a USB Device .............................................................................. 10 Connecting a SD Device ................................................................................ 10 Connecting a Headphone  . .............................................................................. 11 Connecting an A/V Device ...
  • Page 6 Getting Started Accessories List Please make sure the following items are included with your TV. If any items are missing, contact your dealer. 保 修 卡   Manual Book×1  Warranty card×1  Remote Control×1  3D  Glasses×2    AV Adapter×2  HD Adapter×1         Audio Adapter ×1   RF Cable×1   "AAA" Battery×2  Screws (M5×12)×12      | USER MANUAL   ...
  • Page 7: G E T T I N G Accessories List

    Getting Started Installing the Stand To install the base stand 1. Secure the stand column to the base plate with the four provided Screws. as figure 1. 2. Secure the stand cover to the stand column with the four provided Screws. as figure 2.  To install the stand 1. Lay the soft froth on the table which can hold enough weight of the whole TV in case of causing damage to TV or person. 2. Put the TV on the froth, with its back upwards and the LCD downwards. 3. To install the base stand, slide in the base stand until the screw holes are aligned. Secure the base stand to the TV with the four  provided screws.  NOTES ・ To install the base stand with the provided screws in the accessory bag is in case of causing damage to TV ・ You need not install the base stand of 32 inches  |    Getting Started       USER MANUAL...
  • Page 8: Securing The Installation Space

    Getting Started Securing the Installation Space Never cover or block the heat-radiating holes. Avoid operating the TV at temperatures below Inadequate air 5 ℃ . Make sure that your TV has adequate air circulation. Allow enough space around the TV as shown below. Install with stand: Install on the wall: Leave at least this much space around the set. Leave at least this much space around the set. Never install the TV set as follows: Air circulation is blocked. Wall Wall Inadequate air circulation can lead to overheating of the TV and...
  • Page 9 Getting Started Control Panel MENU Menu button VOL Λ Volume up/Enter VOL V Volume down CH Λ Channel up CH V Channel down SOURCE Source button Standby button Standby indicator Power button  Remote receiver Light-emitting LOGO Item/Operations Description Power button   Turn on or off the TV set....
  • Page 10: Remote Control

    Getting Started Remote Control Remote sensor Standby button M M u u t t e e Standby/on switch Mute button Weibo button 3D button Source Weibo Input Source button Display 3D menu Energy saving button Display PwSave menu Numeric button Program selecting/Type characters Display Recall Display button Recall button Go to the previous channel in ATV...
  • Page 11 Getting Started Remote Control Mute button Sound button Press to mute the sound and again to restore the sound.  Set the sound mode among Standard, Live1, Live2,  The function is used to temporarily turn off the sound. Theater, Music, Speech and User. The User achieves the  specific sound effect by setting EQ. Input Source button Picture button Input Source Set the picture mode among Standard, Stadium, Game,  Cinema, Concert, Studio and User. The User achieve the  certain image effect by setting brightness, contrast, color  and so on. Subtitle button COMPONENT HDMI1 This unit only supports the add-on subtitle of .srt. In DTV,  Press the button repeatedly to switch among different  HDMI2 subtitles if the movie has multi subtitles. HDMI3 Sleep button Press to display the Input Source menu, including DTV,  You can set the TV to enter the standby mode automatically.  ATV, AV1, AV2, Component, HDMI1, HDMI2, HDMI3 and  Press the button repeatedly to set the time when the  VGA. TV enters standby made among Off-10min-20min-...- Press ...
  • Page 12 Getting Started Sound/Track button Favorite List In DTV mode, press the button to display the sound track  Functions: Your favorite channels are stored in this  information. Press the button repeatedly to switch among  list, you can use this list of favorite channels for quick  different sound track if the movie has multi sound tracks. switching. Operations: Audio Track Enter the List: In DTV mode, You can press FAV button enter this list. Language 1 Language 2 Common  Favorite  All Channels    Channels Channels    1     CCTV-1    2     CCTV-2    3     CCTV-10 NOTE If you want to add/delete favorite channel, please enter the  Channel List Programme Edit. In DTV/ATV mode, press OK to display Channel List menu. button to select the channel and press  / Press ▲/ button to turn to previous/next page, then press OK to ...
  • Page 13: Connections

    Connections TV Terminal AUDIO/R AUDIO/L HEADPHONE Power input AV OUT HDMI 2 HDMI 3 COAXIAL AUDIO IN COMP AV 2 ETHERNET Antenna ETHERNET AV OUT HDMI HDMI COAXIAL AUDIO IN COMPONENT HDMI NOTES ・ Some external devices impossible insert to this set for individual difference. Please replace with appropriate external signal  cable or increase the adapter to match with the port in such case.  ・ Illustrations for reference only. Item Description Antenna Connect an antenna or cable TV to this jack....
  • Page 14: Connecting An Antenna Or Cable

    Connections Connecting an Antenna or Cable Making Connections The TV must receive the signal from one of the following Sources: antenna or CATV network. Antenna should be placed away from roads, power distribution lines, neon signs and other places, so as to avoid disruption of  television signals, this can prevent accidents from happening. In addition, as long-term exposure outside, antenna prone to  degradation, if the image is not clear, you should first turn off the power, and then check the antenna. NOTES ・ When using the outdoor antenna, please unplug the cord of the indoor antenna (if any) from the antenna terminal outlet. ・ It is recommended that coaxial cable (75Ω) be used to eliminate the interference caused by the mismatched impedance. ・ The antenna cable should not be bound together with the power cord. ・ When using the CATV or closed circuit TV, please insert the plug of the coaxial cable (75Ω). TV JACK EXTERNAL DEVICES ANT OUT ANT 75Ω Connecting a USB Device Making Connections TV JACK EXTERNAL DEVICES Connect to the USB jack in the TV with USB cable or  directly USB port....
  • Page 15: Connecting A Headphone

    Connections Connecting a Headphone Making Connections TV JACK EXTERNAL DEVICES While the headphone is connected, the sound from the  built-in speakers will be disabled. HEADPHONE Headphones can be connected to the HEADPHONE  output on the TV. Connecting an A/V Device With the AV Cable Connect the TV's AV1/AV2 jack to video output jack of the external A/V devices (VCD, DVD, VCR or Camcorder).  Connect the TV's AV1/AV2 jack to audio output jacks (Audio Left/Right) of the external A/V devices.  NOTE  AV2 signal are connected to external devices with AV Adapter provided. TV JACK EXTERNAL DEVICES Audio R Audio L Video Audio R Audio R Audio R DVD/VCD White...
  • Page 16 Connections EXTERNAL DEVICES TV JACK Audio R Audio R Audio L Audio L DVD/VCD White Video Set-top box Blue Camera Green Satellite Receiver Component Connecting an A/V Device With the HDMI Cable The set has HDMI jack. It can be connected with other devices such as DVD, Set-top Box, AV Receiver, DTV and so on. The connection between sending and receiving equipment don't need separate audio cable. NOTES ・ Be sure the signal format are supported  HDMI Input by HDMI when connected with other  RGB/60Hz 640×480, 800×600, 1024×768 devices(see the table above). otherwise ...
  • Page 17: Connecting A Pc

    Connections Connecting a PC Making Connections The TV set has D-sub15 pin RGB computer standard jack, connect the TV VGA jack to the PC. Connect the TV's AV OUT jack to audio output jacks (Audio Left/Right) of PC. NOTES ・ The VGA signal are connected to PC with  AV/Component Adapter provided. Please  TV JACKS EXTERNAL make sure that the audio connects,  DEVICES otherwise the sound will be abnormal. ・ For video format supported by VGA input,  refer to the form. VGA Input Audio R Audio R Format Resolution Frequency Audio L Audio L VGA 640×480 60Hz SVGA 800×600 60Hz XGA...
  • Page 18: Connecting A Tv Monitor Or Vcr

    Connections Connecting a TV Monitor or VCR Making Connections Connect the TV's AV OUT jack to video input jack of the external A/V devices (VCR or TV Monitor).  Connect the TV's AV OUT jack to audio input jacks (Audio Left/Right) of the external A/V devices.  NOTES ・ The signal are connected to external devices with AV Out Adapter provided.  ・ When used as TV monitor, please carefully read the Attention on still images of the TV. EXTERNAL DEVICES TV JACK Audio R Audio R Audio R AV OUT Audio L Audio L Audio L White Video Video Video Yellow TV Monitor A/V IN Selecting the Input Source You should connect to the corresponding equipment and select the right input source with remote control when you want to watch ...
  • Page 19: Basic Features

    Basic Features Using the TV for the First Time Turning the TV On or Off Changing the Channel and Volume / (or CH +/ 1. Use an AC cord to connect the TV's Power input jack to AC  1. Press the CH ) on the TV/remote control to  outlet. change the channel. 2. Press the Power button / (or VOL +/  on the TV set. When the TV is  2. Press the VOL ) on the TV/remote control  on, press the Standby button  on the remote control,  to adjust the volume. and the TV will enter Standby mode. Press this button ...
  • Page 20 Basic Features Channel Setting Search channel in ATV signal -Search for analog television  signal before the Input Source is set up as "ATV". (For more  Search channel can be divided into in DTV signal and in ATV  information, see "Remote Control" -> "Input Source button") signal. Channel: Select the channel number. ▲ Search channel in DTV signal -Search for digital television  Video System: Set the video pattern  Auto Install signal before the Input Source is set up as "DTV". (For more  for local channels, including PAL, NTSC,  Manual Tuning information, see "Remote Control" -> "Input Source button") SECAM and AUTO Channel Audio System: Set the audio pattern for  Fine-Tune local channels, including D/K, B/G, M, I. Audio System Fine-Tune: Adjust the current frequency  Video System...
  • Page 21 Basic Features Sound Zoom Sound Mode: The sound modes including  Standard, Live1, Live2, Music, Theater,    Speech and User. Zoom 2 SRS Effect Balance: Adjust the relative volume of the  Zoom 1 Auto Volume speakers in a multiple speaker system. EQ Normal E Q : A d j u s t   e a c h   s o u n d   c o m p o n e n t .  Balance...
  • Page 22 Basic Features To enjoy the 3D effect, the TV set needs to use in Before you or your child uses 3D function, please combination with the Hisense special 3D glasses read the following alarm: NOTES WARNING 1. Watching TV at short range for a long time may weak- 1. Some picture functions may not be available in 3D  mode, such as E.S/Zoom button is not applicable ...
  • Page 23 Basic Features Book Manage: Press  OK to display the Book menu  after selected program. Select Book Manage then  Functions: You will get to know the programs of different  press  OK to enter the Book Manage menu. You can  channels by using this menu, then you can book these  check and manage the reserved program in this menu. programs. Return: Complete booking or reservation management,  NOTE select the icon, press the OK or Return to return to the  program. The E-program guide information is provided by the  broadcasting company. Because the broadcasting  NOTE information is provided on the specified channel, the  program entries are possibly displayed as null or the date  The only way to booking the program successfully is  fails to be displayed. The display will automatically renew  the start time of the program you have booked must  when new information are available for use. be later than the Current time. The same time period  can only respond to one program. When booking  conflicts, it responds the highest priority program,  according to the priority you have chosen. Book Manage PwSave (Power Save) Program Weekly User Dynamic Auto2 EGP...
