Hisense L5H Installation Manual

Hisense L5H Installation Manual

Laser tv screen

Advertisement

Quick Links

INSTALLATION GUIDE
Hisense Laser TV Screen
Read this guide carefully before installing the product and
make sure you understand all the content
for Multilingual QSGs.
ENGLISH
ES-A2253Z1

Advertisement

loading
Need help?

Need help?

Do you have a question about the L5H and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Hisense L5H

  • Page 1 INSTALLATION GUIDE Hisense Laser TV Screen Read this guide carefully before installing the product and make sure you understand all the content for Multilingual QSGs. ENGLISH ES-A2253Z1...
  • Page 2 Overall Structural Diagram of Laser TV screen...
  • Page 3: Required Tools

    Required Tools Electric drill Tape measure Pencil Hammer Philips screwdriver Level ruler Stud finder Ø Ø 6 & Hardware and Parts Lists The appearance drawing in this manual is a schematic diagram. Please refer to the purchased actual product. After opening the package, please check the part list carefully. Due to product upgrading, the accessories are subject to change without prior notice.
  • Page 4: Assembling The Inner Frame

    Read this guide carefully before installing this product and retain it for future reference. Maintenance of Laser TV Screen Use dust-free soft cotton cloth dipped in absolute ethanol to wipe gently the screen and frame. Warning • Do not touch or wipe the screen directly by hands or with an ordinary towel. •...
  • Page 5 Note: Remove the screws (M)(pre-installed) on the Inner frame connectors(H)(preinstalled), insert the two inner frame connectors(H)in diagonal position, and then tighten the screws (M)to attach the Inner frame connectors (H).
  • Page 6 II. Assembling the screen 1. Carefully unroll the screen (K) on the frame in the direction shown in the figure then remove the protective cotton. Note: Please pay attention not to scratch the screen and keep the side with “BOTTOM” upwards. Completely insert 4 fiber rods (J1) into the sleeves of the two long sides .
  • Page 7 3. Slide the edges of the screen into the grooves of the long side screen tension knobs (D) and the short side screen tension knobs (C). 4. Adjust the position of the screen tension knob to fit the screen tension knob screw (N) (pre-installed) into the U-shaped groove of the frame.
  • Page 8 6. Place the screen upright to check if the front screen surface is flat. If not, adjust the tension of the screen tension knob screw (N) as needed. III. Assembling Outer Frame 1. Rotate the screen, with the label "BOTTOM" facing up. 2.
  • Page 9 IV. Assembling Mounting Bracket 1. Pinpoint the positions according to the distance measurements in the illustration below. 2. There are three methods for installation, the first method (1) is used for solid wall, the second method (2) is used for drywalls or hollow walls (Thickness>0.39inch(10mm)), and the third method (3) is used for solid wood wall, only screws used.
  • Page 10 6. Hang the screen on the hanging brackets and check if it is horizontally straight. If not, twist adjusting rods (W) as needed. Note: Make sure the “BOTTOM” label is at the bottom of the screen and facing the wall. Model 12.9in.

This manual is also suitable for:

L9h100l5h-dlt100c100l9h-dlt100c
