Pure Fun SUPA-BOUNCE 12FT TRAMPOLINE SET Product Manual page 10

TRAMPOLINE ASSEMBLY INSTRUCTIONS
10
7
16
3
13
6
12
MODEL# 9412TS- TRAMPOLINE
1
11
9
2
STEP 8:
Place the Jumping Mat (Part 1) in the
middle of the frame and unfold it
completely.
5
NOTE:
Make sure the stitching of the Jumping mat
is facing the floor
14
In order to avoid ripping and to distribute
tension when attaching springs to the
frame, follow the numbered order shown.
Once a spring is attached to the Jumping
mat, you must attach the other in the
4
opposite direction of the mat.
Once the first 16 Springs (Part 7) have
been placed, Attach all remaining Springs
using the Spring Tool (Part 10) that was
15
provided clockwise.
NOTE:
Failure to use appropriate tools may result
8
in injury or pinching due to tension of the
springs. We recommend you use gloves
when attaching springs to the frame.
HOW TO USE SPRING TOOL:
In order to insert the spring properly, hook
the curved end to the V-ring of the jumping
Mat. Then, pull on the Long Round end
with the Spring Tool until it is attached on
one of the corresponding openings of the
Top Rail as shown.
HOW TO USE SPRING TOOL:
In order to insert the spring properly, hook
the curved end to the V-ring of the jumping
Mat. Then, pull on the Long Round end
with the Spring Tool until it is attached on
one of the corresponding openings of the
Top Rail as shown.
10
