Home PBXware SERVERware TELCOware SIPmon SIPProt Desktop & Mobile UADs Appliances From Bicom Systems Wiki Contents 1 Introduction 2 Requirements 2.1 Identifying phone model 2.2 Phone firmware 2.3 DHCP server 2.4 PBXware version 3 Installation 3.1 Power adapter 3.2 Power over Ethernet (PoE) 3.3 Find the phone IP address 3.4 Reset to factory settings 4 Registering phone...
This User Guide is written as general guide on how to set up the Grandstream phone model GXP-2140 to work with PBXware 5.3.6. Requirements Identifying phone model To start and successfully complete registration of your Grandstream phone you need to know which phone model you will setup.
the Software Version-Prog. DHCP server Fully configured and operational DHCP server. PBXware version In order to find out the PBXware version, please login to PBXware and navigate to Settings: About. On the top of About page is a code similar to this one "PBXware Edition: Business, Release: 5.3.6 (041373f), Running: 1.4.24-gc-75ee203", where "Release"...
Find the phone IP address Find out your Grandstream phone IP Address. Press the Middle navigation key. Go to Status->Network Status and the IP address will be displayed on the display. Reset to factory settings Reset to factory settings. This step is not required for out-of-the-box phones, however, if the phone has been already used then it is a must.
Page 5
UAD settings Login to PBXware web administration interface. Open a new browser window and enter the IP address in order to access the PBXware web administration login screen. Example: http://192.168.1.10 Login to PBXware with your e-mail address and password. UAD settings Navigate to Settings:UAD.
Page 6
Enter a name for the extension being created. Example: John Smith. E-mail Enter the e-mail address associated with this extension. This e-mail address will receive all system notification messages. Example: john.smith@bicomsystems.com. Click on the Save button. Registering phone This chapter describes how to register Grandstream phone using Hostname or IP Address, or DNS SRV.
Auto provisioning This chapter describes how to set UAD settings, create PBXware extension and register the phone using DHCP or Static IP address. The following topics are covered: UAD settings Creating extension Registering phone UAD Settings UAD settings Login to PBXware web administration interface Open a new browser window and enter the IP address in order to access the PBXware web administration login screen.
Page 8
Select Location: Local or Remote. Local is for all extensions registered on the LAN and Remote is for all extensions registered from remote networks, WAN, Internet etc. Click on the Next step button. Extension values Enter values into the required field text boxes. REQUIRED FIELDS: Name Enter a name for the extension being created.
Page 9
Phone first boot or user initiated reboot Auto provisioning process will start during phone first boot or after reboot process has been initiated by user. DHCP server will instruct the phone where from to pickup appropriate configuration file. If everything is done as above described, you should have successfully registered your phone to PBXware.
Example for IP Address USING HTTPS: 192.168.1.10/prov Enter Auto Provisioning username and password into Config HTTP/HTTPS User Name and Config HTTP/HTTPS Password fields. If you choose to use server type TFTP enter Hostname or IP Address Example for Hostname: voip.bicomsystems.com Example for IP Address: 192.168.1.10 Click on Save and Apply button.
Page 11
NOTE: Your DNS Server needs to be configured correctly for this to work. Bicom Systems can provide service to set up this for you. Check if the DNS SRV is enabled in your PBXware Contact your PBXware administrator to find out if the DNS SRV is enabled in your PBXware, or if you have access to the PBXware you can check this yourself.
