- Page 1 Grandstream Networks, Inc. GXP2130v2/GXP2140/GXP2160/GXP2135/GXP2170 Bluetooth User Guide GXP2130v2/2140/2160/2135/2170 Bluetooth User Guide...
-
Page 2: Table Of Contents
OVERVIEW ....................4 BASIC FUNCTIONS ..................5 TURN BLUETOOTH ON OR OFF ......................6 CHANGE GXP2130v2/2140/2160/2135/2170 BLUETOOTH NAME ............ 6 PAIRING TO A BLUETOOTH DEVICE ....................6 CONNECTING TO A BLUETOOTH DEVICE ................. 7 UNPAIRING AND DISCONNECTING A BLUETOOTH DEVICE ........... 8 USE BLUETOOTH HEADSET .............. - Page 3 Table of Tables GXP2130v2/2140/2160/2135/2170 Bluetooth User Guide Table 1: Bluetooth Configuration ........................5 GXP2130v2/2140/2160/2135/2170 Bluetooth User Guide Page 2 of 13...
- Page 4 Table of Figures GXP2130v2/2140/2160/2135/2170 Bluetooth User Guide Figure 1: Bluetooth Configuration ......................... 5 Figure 2: Scan Bluetooth Device ........................7 Figure 3: Pairing to Bluetooth Device ......................7 Figure 4: Bluetooth Device Connected ......................8 Figure 5: Disconnect Bluetooth Device ......................8 Figure 6: BT is OFF ............................
-
Page 5: Gxp2130V2/2140/2160/2135/2170 Bluetooth User Guide
GXP2130v2/2140/2160/2135/2170 supports Bluetooth Class 2 of version 2.1. On GXP color phones, users could connect to mobile phones (which support Bluetooth function) via hands free mode, or use Bluetooth headset to answer calls. -
Page 6: Basic Functions
GXP2130v2/2140/2160/2135/2170’s Bluetooth power first. The first time when using a new Bluetooth device with GXP2130v2/2140/2160/2135/2170, "pair" the device with the phone so that both devices know how to connect securely to each other. After that, users could simply connect to a paired device. Turn off Bluetooth if it is not used. -
Page 7: Turn Bluetooth On Or Off
Both devices will stay paired afterwards unless they are unpaired. 1. Go to GXP2130v2/2140/2160/2135/2170's LCD MENU->System->Bluetooth 2. Enter Start Scan option 3. GXP2130v2/2140/2160/2135/2170 scans and displays the Names of all available Bluetooth devices in range. See Figure 2 Scan Bluetooth Device If the device you would like to pair with does not show up in the list, ensure that the device is turned on and set to be discoverable. -
Page 8: Connecting To A Bluetooth Device
Figure 3: Pairing to Bluetooth Device CONNECTING TO A BLUETOOTH DEVICE After successfully paired, the GXP2130v2/2140/2160/2135/2170 will show "Paired" behind the Bluetooth device name in the scan list. Highlight the device name and press “Connect” soft key to connect. Once connected, GXP2130v2/2140/2160/2135/2170 will show “Connected” behind the Bluetooth device... -
Page 9: Unpairing And Disconnecting A Bluetooth Device
Figure 5: Disconnect Bluetooth Device USE BLUETOOTH HEADSET On GXP2130v2/2140/2160/2135/2170, user can answer/terminate incoming call from Bluetooth headset. BT ON AND BT OFF After Bluetooth headset is successfully connected, GXP2130v2/2140/2160/2135/2170 will show “BT On” GXP2130v2/2140/2160/2135/2170 Bluetooth User Guide Page 8 of 13... -
Page 10: Figure 6: Bt Is Off
Figure 7 BT is ON. Figure 7: BT is ON When BT is on, both Bluetooth headset and GXP2130v2/2140/2160/2135/2170 will alert for incoming calls. User may press the answer button on Bluetooth headset to answer the incoming call. During an active call, user may switch the audio channel between Bluetooth headset and phone handset by pressing “BT Off”/”BT On”... -
Page 11: Handsfree Mode
HANDSFREE MODE By connecting cell phone to GXP2130v2/2140/2160/2135/2170 phone via hands free mode, user can sync up cellphone phonebook to GXP phone and make calls on GXP phone via cell phone account. GXP2130v2/2140/2160/2135/2170 plays the role of Bluetooth headset in hands free mode. -
Page 12: Connect To Hands Free Device
CONNECT TO HANDS FREE DEVICE The hands free account virtually maps to Line Key 3 for GXP2130v2; Line 4 for GXP2140/2135; or Line Key 6 for GXP2160/2170. Press hands free account line key. It will bring up Bluetooth scan page. In scan page, highlight the desired Bluetooth device from discovered list. -
Page 13: Use Bluetooth Phonebook
GXP2130v2/2140/2160/2135/2170. 1. Go to LCD Menu –> Contacts to see Bluetooth Phonebook option. 2. Press “Select” soft key to enter Bluetooth phonebook and see the connected cell phone’s contacts. Figure 11: Bluetooth Phonebook In Bluetooth phonebook, user can enter number digits to search contacts and phone will list the matching ones. -
Page 14: Initiate A Call With Hands Free Mode
On idle screen, when the hands free account is connected, pressing the last Line Key will bring up call screen (Line Key 3 for GXP2130v2; Line 4 for GXP2140/2135; Line Key 6 for GXP2160/2170). User can enter the destination number from key pad followed by “SEND” button to dial out.
