MA-5588V
4K-HDR 8X8 HDBaseT Lite Matrix with PoC
User Manual
The MA-5588V
safety regulations and requirements, and has been certified for international use. However, like all
electronic equipments, the MA-5588V should be used with care. Please read and follow the safety
instructions to protect yourself from possible injury and to minimize the risk of damage to the unit.
● Follow all instructions and warnings marked on this unit.
● Do not attempt to service this unit yourself, except where explained in this manual.
● Provide proper ventilation and air circulation and do not use near water.
● Keep objects that might damage the device and assure that the placement of this unit is on a
stable surface.
● Use only the power adapter and power cords and connection cables designed for this unit.
● Do not use liquid or aerosol cleaners to clean this unit. Always unplug the power to the device
before cleaning.
TABLE OF CONTENTS
INTRODUCTION................................................................................................................. 1
FEATURES ......................................................................................................................... 1
PACKAGE CONTENTS ...................................................................................................... 2
SPECIFICATIONS .............................................................................................................. 3
PANEL DESCRIPTIONS ..................................................................................................... 4
IR PASS-THROUGH ........................................................................................................... 5
CONNECTION DIAGRAM .................................................................................................. 6
OPERATION APPROACH .................................................................................................. 7
EDID LEARNING .............................................................................................................. 23
FAQ .................................................................................................................................. 24
NOTICE ............................................................................................................................ 25
WARRANTY ..................................................................................................................... 26
rev: 190308
Made in Taiwan
4K-HDR 8x8 HDBaseT Lite matrix with PoC
has been tested for conformance to
