GoMax Electronics MA-5288H User Manual

8x8 hdmi matrix switcher with full 3d support
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
M
A
-
5
2
8
8
H
M
A
-
5
2
8
8
H
8x8 HDMI Matrix Switcher
with Full 3D Support
User Manual
rev: 130411
Made in Taiwan

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MA-5288H and is the answer not in the manual?

Questions and answers

Related Manuals for GoMax Electronics MA-5288H

Summary of Contents for GoMax Electronics MA-5288H

  • Page 1 8x8 HDMI Matrix Switcher with Full 3D Support User Manual rev: 130411 Made in Taiwan...

  • Page 2: Table Of Contents

    However, like all electronic equipments, the MA-5288H should be used with care. Please read and follow the safety instructions to protect yourself from possible injury and to minimize the risk of damage to the unit.

  • Page 3: Introduction

    ● Easy installation with rack-mounting and wall-mounting designs for master and receiver respectively ● Fast response time – 2~5 seconds for channel switch PACKAGE CONTENTS ● 1x MA-5288H ● 1x IR Receiver ● 1x DC 12V 5A ● 1x IR Remote control* ●...

  • Page 4: Specifications

    SPECIFICATIONS Model Name MA-5288H Technical Role of usage True 8x8 matrix HDMI compliance HDMI Deep Color & full 3D HDCP compliance Video bandwidth Single-link 225MHz [6.75Gbps] Video support 480i / 480p / 720p / 1080i / 1080p60 36-bit color Audio support Surround sound (up to 7.1ch) or stereo digital audio...

  • Page 5: Panel Descriptions

    PANEL DESCRIPTIONS Front Panel Source Status: Input source indicator LED IR SENSOR: IR sensor for receiving the IR commands from IR remote Output Push Button & 7-segment LED: Front panel push buttons used to select the number of display channel & LED display for output ports Input Push Button &...

  • Page 6: Hardware Installation

    1. Connect all sources to HDMI Inputs on the 8x8 HDMI Matrix MA-5288H. 2. Connect all display to HDMI Outputs on the 8x8 HDMI Matrix MA-5288H 4. Connect the +12V 5A DC power supply to the 8x8 HDMI Matrix MA-5288H. CONNECTION DIAGRAM...

  • Page 7: Operation Approach

    OPERATION APPROACH Method A: Push-in Button preset save learn default 1. IN/OUT MAP 1) Use the “+”or “-“ output push button to select the number of display 2) Use the “+”or “-“ input push button to select the number of input source “+”: change selected input/output port in ascending order “-”...
  • Page 8 4. Default EDID Mode 1) Push “input+(default)”button to select the input channel which you want to learn default EDID and then keep pushing “input+(default)”button when you select your desired input channel 2) Push the “+”or “-” output push button and then the LED will show “E”“d” one time to enter Learn Default EDID Mode 3) Use “+”or “-”...
  • Page 9 Method B: IR Remote Control 1. IN/OUT Switch Operation Procedure 7-Segment LED IN/OUT Switch Output Number (1~8) + Input Number (1~8) 1. Press output number key “3” to select Output 3 Ex: Input 2 To Output 3 2. Press input number key “2” to select Input 2 2.
  • Page 10 Operation Procedure 7-Segment LED Mute Output Mute + Output Number (1~8) + Take 1. Press “MUTE” button 2. Press output number key “3” to select Output 3 Ex: Mute Output 3 3.Press “TAKE” button Output Status Status + Output Number (1~8) + Take 1.Press “STATUS”...
  • Page 11 Method C: Software Control through RS-232 port 1. System Requirement 1) OS Information: MS WinXP/7 2) Baud rates: 9600 3) Software size: 3 MB 4) Minimum RAM requirement: 256 MB FW/SW Version Button COM Port Selection Connection Status Connect/Disconnect Button Power On/Off Button EDID Button Firmware Update Button...
  • Page 12 2. Step by step for connecting matrix and controller Step1: Use RS-232 cable to connect the RS-232 port on matrix and controller Step2: Open the software and then choose the correct com port Step3: Click connection button “ ” 3. FW/SW Version Button Click “...
  • Page 13 1) Learn EDID from Default a) Select Default EDID(1-8 Default EDID) b) Select Input c) Click “Learn” button to learn default EDID 2) Load EDID File to Input a) Select Input b) Click “Load” button to select the EDID file 3) Learn EDID From Display a) Select HDMI output b) Select Input...
  • Page 14 b) Select the EDID content c) Click “Save EDID on Computer” to save the generated EDID as a file 5) View EDID content a) Select Input, HDMI output, or From File b) Click “View” button to read the EDID and analysis c) Click “Save As”...
  • Page 15 9. Firmware Update Button 1) Click “Load File” to select the firmware file which you want to update 2) Click “Break” button 3) Quickly remove and reconnect the power input connector 4) Click “Start” button to begin the firmware update 10.
  • Page 16 11. Mapping Button 1) Save Mapping: a) Select Mapping(1-8) b) Click “Save” button to save current mapping 2) Preset Mapping: a) Select Mapping(1-8) b) Click “Recall” button to recall previous mapping which are saved 3) Rename Mapping: a) Rename the mapping(Mapping1-Mapping8) b) Click “Confirm”...
  • Page 17 13. In/Out Switch Button Click the button on the checkerboard to select Input & Output port User can click the input number button to let all outputs select the same input Ex: All outputs select input 3 14. Mute Output Button Click the circle button to turn off output’s video and audio Ex: Mute Output 2...

  • Page 18: Edid Learning

    EDID LEARNING The EDID learning function is only necessary whenever you encounter any display on the HDMI output port that cannot play audio and video properly. Because the HDMI source devices and displays may have various level of capability in playing audio and video, the general principle is that the source device will output the lowest standards in audio format and video resolutions to be commonly acceptable among all HDMI displays.

  • Page 19: Faq

    Can every TV work with the HDMI matrix? Basically, the answer is YES. But if your TV can not support 1080p, please refer the EDID LEARNING section to learn EDID from your TV. What is EDID? Why do I need to learn EDID? EDID contains the whole information of the display such as the resolution and audio setting which this display can support.

  • Page 20: Warranty

    SELLER will NOT be liable for direct, indirect, incidental, special, or consequential damages resulting from any defect or omission in this manual, even if advised of the possibility of such damages. Also, the technical information contained herein regarding the MA-5288H features and specifications is subject to change without further notice.
