8X8 HDBaseT Lite Matrix with PoC,
HDCP2.2 & 4K2K60 (YUV420)
User Manual
rev: 151209
Made in Taiwan

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MA-5488V2 and is the answer not in the manual?

Questions and answers

Related Manuals for GoMax Electronics MA-5488V2

Summary of Contents for GoMax Electronics MA-5488V2

  • Page 1 8X8 HDBaseT Lite Matrix with PoC, HDCP2.2 & 4K2K60 (YUV420) User Manual rev: 151209 Made in Taiwan...

  • Page 2: Table Of Contents

    However, like all electronic equipments, the MA-5488V2 should be used with care. Please read and follow the safety instructions to protect yourself from possible injury and to minimize the risk of damage to the unit.

  • Page 3: Introduction

    IP control. Furthermore, the built-in IR extension function makes users at display site access the DVD player, PS3 or any HDMI supported devices directly! In addition, MA-5488V2 also supports PoC (Power over Cable) which can power both units from TX with power supply.

  • Page 4: Specifications

    SPECIFICATIONS Model Name MA-5488V2 Technical MA-5488V2 CV-745V True 8x8 matrix switcher Role of usage Receiver [RX] Transmitter [TX] HDMI Deep Color, full 3D & 4K2K@60Hz (YUV 4:2:0) HDMI compliance HDCP compliance Video bandwidth Single-link 340MHz [10.2Gbps] Video support 480i / 480p / 720p / 1080i / 1080p60 / 4K2K@60Hz (YUV 4:2:0) Audio support Surround sound (up to 7.1ch) or stereo digital audio...

  • Page 5: Panel Descriptions

    PANEL DESCRIPTIONS Transmitting unit ► MA-5488V2 Front Panel Power Switch Source Status: Input source indicator LED IR SENSOR: IR sensor for receiving the IR commands from IR remote Output Push Button & 7-segment LED: Front panel push buttons used to select the number of display channel &...

  • Page 6: Receiving Unit ► Cv-745V

    ► Receiving unit CV-745V Rear Panel Front Panel RJ-45: Plug in a Cat.X cable LED: Link indicator IR Blaster: Infrared 3.5mm socket for plugging in the extension cable of IR blaster IR Receiver: Infrared 3.5mm socket for plugging in the extension cable of IR receiver HDMI Output: Connect to HDTV with a HDMI cable Mini-USB: F/W update LED: Power indicator...

  • Page 7: Ir Pass-Through

    IR BLASTER: IR control on individual display device IR RECEIVER: IR receiver connected here can receive all IR command signals from the IR remote controls of MA-5488V2 and all other HDMI source devices. CAUTION! Incorrect placement of IR Blaster and Receiver may result in the failure of the IR extenders. Please check carefully before plugging in the IR extender to the respective IR sockets.

  • Page 8: Connection Diagram

    CONNECTION DIAGRAM...

  • Page 9: Operation Approach

    OPERATION APPROACH Method A: Push-in Button preset save learn default 1. IN/OUT MAP 1) Use the “+”or “-“ output push button to select the number of display 2) Use the “+”or “-“ input push button to select the number of input source “+”: change selected input/output port in ascending order “-”...
  • Page 10 4. Default EDID Mode 1) Push “input+(default)”button to select the input channel which you want to learn default EDID and then keep pushing “input+(default)”button when you select your desired input channel 2) Push the “+”or “-” output push button and then the LED will show “E”“d” one time to enter Learn Default EDID Mode 3) Use “+”or “-”...
  • Page 11 Method B: IR Remote Control 1. IN/OUT Switch Operation Procedure 7-Segment LED IN/OUT Switch Output Number (1~8) + Input Number (1~8) 1. Press output number key “3” to select Output 3 Ex: Input 2 To Output 3 2. Press input number key “2” to select Input 2 2.
  • Page 12 Operation Procedure 7-Segment LED Output Status Status + Output Number (1~8) + Take 1.Press “STATUS” button Ex: Output 4 2.Press output number key “4” to select Output 4 (Input 2) 3.Press “TAKE” button Save Current Mapping Save + Output Number (1-8 storage site) + Take 1.Press “SAVE”...
  • Page 13 Method C: Software Control through RS-232 port / Ethernet port 1. System Requirement 1) OS Information: MS WinXP/7 2) Baud rates: 9600 3) Software size: 3 MB 4) Minimum RAM requirement: 256 MB Method D: Software Control through RS-232 port Power ON/ Standby mode I/O Routing Button Control SW via RS-232...
  • Page 14 1. I/O Routing Button 1) I/O Mapping: a) Switch the input for each output 2) Recall Mapping: a) Select the stored Mapping(1-8) b) Click “Recall” button to recall previous mapping which are saved 3) Save Mapping: a) Select Mapping(1-8) b) Click “Save” button to save current mapping...
  • Page 15 2. EDID Button 1) Learn EDID from Default to Input a) Select Default EDID(1-11 Default EDID) b) Select designated Input c) Click “Apply” button to learn from default EDID 2) Learn EDID from Display to Input a) Select output b) Select designated Input c) Click “Apply”...
  • Page 16 3. Rename I/O Button 1) Rename I/O: a) Rename the Inputs b) Rename the Outputs 2) Rename Mapping: a) Rename the Mappings...
  • Page 17 4. System Button 1) Network a) DHCP mode => Click DHCP and then click the “Read” button to get the IP address Info b) Static mode => Click Static and then key in the “IP”, “MASK”, ”GATEWAY” info. After setting IP Address, please click “Save”...
  • Page 18 Method E: Web Interface Control The default IP address: 192.168.1.111 Account: admin Password: matrix I/O Routing Button Setting Button EDID Button Refresh I/O Status & Read I/O Name Button 1. I/O Routing Button 1) I/O: a) Select the input 2) Save Mapping: a) Select Mapping(1-8) b) Click “Save”...
  • Page 19 2. Setting Button 1) Rename I/O: a) Rename output name b) Rename input name c) “Read” button: to read I/O name from device d) “Send” button: to send the changed I/O name to device 2) Rename Mapping: a) Rename Mapping name b) “Read”...
  • Page 20 3. EDID Button 1) Learn EDID from Default a) Select Default EDID(1-11 Default EDID) b) Select Input c) Click “Send” button to learn default EDID 2) Learn EDID From Display a) Select output b) Select Input c) Click “Send” button to learn display EDID 4.

  • Page 21: Edid Learning

    EDID LEARNING The EDID learning function is to resolve audio and video playing issues at HDMI output port. Because the HDMI source devices and displays may have various level of capability in playing audio and video, the general principle is that the source device will output the lowest standards in audio format and video resolutions to be commonly acceptable among all HDMI displays.

  • Page 22: Faq

    Can I use any kind of LAN cable? Please check the NOTICE section for more information about how to pick up a suitable cable. Can every TV work with the HDMI matrix? Basically, the answer is YES. But if your TV can not support 1080p, please refer the EDID LEARNING section to learn EDID from your TV.

  • Page 23: Notice

    NOTICE 1. If the DVI or HDMI device requires the EDID information, please use EDID Reader/Writer to retrieve and provide DVI/HDMI EDID information. 2. All HDMI over Cat.X transmission distances are measured using Belden 1583A CAT5e 125MHz LAN cable and ASTRODESIGN Video Signal Generator VG-859C & VG-870B. 3.

  • Page 24: Warranty

    SELLER will NOT be liable for direct, indirect, incidental, special, or consequential damages resulting from any defect or omission in this manual, even if advised of the possibility of such damages. Also, the technical information contained herein regarding the MA-5488V2 features and specifications is subject to change without further notice.
