Urban collection
Noah / Elyse / Logan cot
Assembly instruction
Logan cot
Logan toddler bed
RECYCLED
Packaging and instructions
printed on recycled materials
1
Elyse cot
Elyse toddler bed
Save this instruction for furture reference.
Assembly of this furniture is best under taken by two people.
Noah cot
Noah toddler bed
SJC Brands Pty Ltd
abn.
58 106 988 578
4-6 Merryvale Rd, Minto, NSW 2566
t.
02 9603 5000
f. 02 9603 7000
e.
customer.service@sjcbrands.com.au
p.o. box
5878 Minto,DC,NSW 2566
www.tasmaneco.com.au
w.
Advertisement
Related Manuals for SJC brands tasman eco Urban Noah
Summary of Contents for SJC brands tasman eco Urban Noah
- Page 1 Noah toddler bed Save this instruction for furture reference. RECYCLED Assembly of this furniture is best under taken by two people. customer.service@sjcbrands.com.au SJC Brands Pty Ltd abn. 58 106 988 578 Packaging and instructions 4-6 Merryvale Rd, Minto, NSW 2566 p.o.
- Page 2 Elyse cot parts list Left headboard ( top) Left headboard ( bottom ) Right headboard Side panel x 2 Rail cover panel x 2 Rails x 2 Base slats x 2 Logan cot parts list Left headboard ( top ) Left headboard ( bottom ) Side panel x 2 RIght headboard...
- Page 3 Regularly check cot for weakness in timber joints and timber panels. If any weaknesses are found, report immediately to SJC Brands via: www.tasmaneco.com.au Do not use cot if it has been damaged in any way and always use genuine Tasman Eco parts. Contact your nearest Tasman Eco...
- Page 4 Step 1- Attach the rail cover panels to headboards secure with lunar washers and M6 x 50mm bolts. M6 x 50mm bolts x 4 Lunar washer x 4 Step-2- Use lunar washers to connect rails to headboards when fixing M6 x 50mm bolts to headbaords, fix M6 x 15mm cap screws to unused holes.
- Page 5 Step 3- Connect the base slats to cot rails secure with M6 x 35mm bolts. M6 x 35mm x24 Step 4- Insert the left headboard ( top ) to left headboard ( bottom ) ensure tighten.
- Page 6 Step 5- Connect the side panels to headboard secure with M6 x 50mm bolts and cap screws. M6 x 50mm bolt x 8 M6 x 15mm cap screw x 2 Step 6- Allen key Step 7-...
- Page 7 Toddler bed assembly Step 1- Connect the rail cover panels to right headboard & left headboard ( top ), secure with lunar washers and M6 x 50mm bolts. M6 x 50mm bolt x 4 Lunar washer x 4 Step 2- Use lunar washers to connect rails to headboards when fixing M6 x 50mm bolts to headboard.
- Page 8 Step 4- Fix M6 x 15mm cap screws to unused holes. M6 x 15mm cap screw x 8 Step 5- Check all the bolts and screws are tight and do not over tightem Allen key Step 6- Put on the recommended mattress ( 1300mm x 690mm ), now toddler bed is completed.
- Page 9 The replacement product will be identical to the originally purchase product wherever possible, though in situations where the identical model is discontinued or out of stock, then SJC Brands Pty Ltd will replace the product with a model that is functionally equivalent This Guarantee is made to the purchaser and/or original owner only.
