OUTDOOR GRILL
BE1-30 Models
INSTALLATION GUIDE
US CA
592074A
11.19

Advertisement

Table of Contents
loading

Summary of Contents for Fisher & Paykel DCS BE1-30

  • Page 1 OUTDOOR GRILL BE1-30 Models INSTALLATION GUIDE US CA 592074A 11.19...
  • Page 2: Safety And Warnings

    SAFETY AND WARNINGS WARNING! Electric Shock Hazard Failure to follow this advice may result in electric shock or death. • This appliance is equipped with a three-prong or four-prong grounding plug for your protection against shock hazard and should be plugged DANGER directly into a properly grounded power outlet.
  • Page 3 SAFETY AND WARNINGS WARNING! WARNING! Hot Surface Hazard Explosion Hazard Failure to follow this advice may result in fire, Failure to follow this advice may result in injury burns, scalds or personal injury. or death • Accessible parts may become hot during use. •...
  • Page 4 SAFETY AND WARNINGS Do not store a full LP tank in direct sunlight. Gas requirements After a period of storage or non-use, the appliance should be checked for gas leaks, This appliance can be used with any brand of 20lb LP gas tank provided it is deterioration, proper assembly, and burner obstructions before use.
  • Page 5: Product Dimensions

    PRODUCT DIMENSIONS FRONT PROFILE BE1-30 MODELS PRODUCT DIMENSIONS INCHES A Overall height of grill 10 1/2 B Overall width of grill C Overall depth of grill (excluding dials) 26 7/8 D Depth of chassis 22 1/2 E Width of chassis (including support bracket) 27 13/16 F Height of chassis 9 15/16...
  • Page 6: Cutout Dimensions

    CUTOUT DIMENSIONS STANDARD CUTOUT INSULATED JACKET CUTOUT If the unit is to be placed into a combustible enclosure, an insulated jacket is required. ventilation ventilation BE1-30 MODELS BE1-30 MODELS CUTOUT DIMENSIONS CUTOUT DIMENSIONS INCHES INCHES A Height of cutout 10 1/8 A Height of cutout 11 1/8 B Depth of cutout...
  • Page 7 CLEARANCES Clearances to non-combustible construction Material which is not capable of being ignited and burned, such as materials consisting entirely of, or a combination of, steel, iron, brick tile, concrete, slate, and plaster. The grill is designed for easy placement into built-in masonry enclosures.
  • Page 8 CLEARANCES Clearances to combustible construction Any materials of a building structure or decorative structure made of wood, compressed paper, plant fibres, vinyl/plastic or other materials that are capable of transferring heat or being ignited and burned. Such material shall be considered combustible even though flame-proofed, fire-retardant treated or surface-painted, or plastered.
  • Page 9: Electrical Connection

    ELECTRICAL CONNECTION All units are supplied with a 12V power transformer to operate the products ignition and dial illumination features. The transformer is sealed in a box with an attached power supply cord. Electrical requirements Use only a Ground Fault Interrupter (GFI) protected circuit with this product.
  • Page 10: Gas Requirements

    GAS CONNECTION GAS REQUIREMENTS NATURAL GAS CONNECTION Verify the type of gas supply to be used, either natural or LP, and make sure the marking Connection: 1/2” NPT female. Operating pressure: 4.0” W.C. Supply pressure: 5” to 14” W.C. on the appliance rating plate agrees with that of the supply. The rating plate is located on If in excess of 14”...
  • Page 11 GAS CONNECTION CART LP CONNECTION BUILT-IN LP CONNECTION Units set for use with LP gas come equipped with a high capacity hose/regulator assem bly If the grill is to be installed in a built-in application, then the grill must be installed in for connection to a standard 20 lb.
  • Page 12: Leak Testing

    LEAK TESTING RADIANT TRAYS A complete gas tightness check must be performed at the installation site. Periodically check Before assembling the radiant, check that the radiant trays have not moved during transit. the whole system for leaks, or immediately if the smell of gas is present. They should sit securely on their locating pins in the base of the grill.
  • Page 13: Flame Height Adjustment

    BURNER ADJUSTMENT FLAME HEIGHT ADJUSTMENT LOW FLAME ADJUSTMENT Flames should be blue and stable with no yellow tips, excessive noise or lifting (Note: LP The valves on the grill feature an adjustable low setting. Due to fluctuations in gas pressure, units may have some yellow tipping).
  • Page 14 FREESTANDING CART INSTALLATION (OPTIONAL) Designed with flexibility in mind, the 30” grill can be either built-in or mounted on a Securing grill to cart freestanding cart. If the grill is to be placed onto a freestanding cart, an approved DCS cart is required and can be purchased separately from your local DCS dealer.
  • Page 15: Installer Checklist

    INSTALLER CHECKLIST Read all installation instructions in this manual to see if the unit has been correctly installed. Ensure that installation has been completed correctly before use. Ensure that: specified clearances are maintained to combustibles the low flame setting is satisfactory proper enclosure ventilation has been verified the drip pan is in place properly and sliding freely each burner lights satisfactorily - individually or with adjacent burner lit...
  • Page 16 DCSAPPLIANCES.COM © Fisher & Paykel Appliances 2019. All rights reserved. The product specifications in this document apply to the specific products and models described at the date of issue. Under our policy of continuous product improvement, these specifications may change at any time.
