- Page 1 PROFESSIONAL GRILL CART CAD1 models INSTALLATION GUIDE / USER GUIDE US CA...
-
Page 3: Table Of Contents
CONTENTS Safety and warnings Introduction Model identification & dimensions Shipping inspection Locating the cart Cart assembly instructions Components Cart assembly instructions Side shelf assembly instructions (optional) Using the cart Removing the drawers Re-installing the drawers Freezer pack (optional, kit #70696A) Care and maintenance Service &... -
Page 4: Safety And Warnings
SAFETY AND WARNINGS To reduce the risk of fire, electrical shock, injury to persons, or damage when using the appliance, follow the important safety instructions listed below: hazard or other injury. WARNING! Explosion Hazard Failure to follow this advice may result in injury or death. - Page 5 SAFETY AND WARNINGS Do not allow children or pets to play in or around the cart. To prevent personal injury or damage to the drawers, do not overload them. The maximum rating of each drawer is 35 pounds. Do not store items of interest to children above or on the inside of any cart. Children could be seriously injured if they should climb onto or into the cart to reach these items.
-
Page 6: Introduction
INTRODUCTION Thank you for selecting this DCS by Fisher & Paykel Grill Cart. This installation and user guide contains valuable information on how to properly install, and maintain your new Professional Grill Cart for years of safe and enjoyable use. For your convenience, product questions can be answered by a DCS Customer Care Representative at www.dcsappliances.com, or email: customer.care@fisherpaykel.com. -
Page 7: Model Identification & Dimensions
MODEL IDENTIFICATION & DIMENSIONS CAD1-30 and side shelf CAD1-36/36E Front Front CAD1-48/48E CAD1-30, CAD1-36/36E and CAD1-48/48E Front Profile CAD1-30 CAD1-36/36E CAD1-48/48E PRODUCT DIMENSIONS A Overall width of cart 1219 B Overall height of cart 35 1/2 35 1/2 35 1/2 C Height of cart chasis (excluding wheels) D Overall depth of cart... -
Page 8: Shipping Inspection
INSTALLATION Compatibility IMPORTANT! All Series 9 grills MUST only be used with either CAD1-36E or CAD1-48E model carts. They cannot be used with any other CAD1 carts. Series 7 grills can be used with both CAD1 and CAD1-E cart models. Shipping inspection IMPORTANT! Do not discard any packing material (box, straps) until the unit has... -
Page 9: Locating The Cart
INSTALLATION Locating the cart For proper use, this product should be installed/positioned on a flat ground or patio. Unevenness such as bumps, cracks and protrusions should be 1/4” or less. Refer to illustration and the below table for required flat area dimensions. CAD1-30 CAD1-36/36E CAD1-48/48E... -
Page 10: Components
INSTALLATION Components Your cart is packaged in one box. The box contains your cart and a universal hardware kit to be used for grill installation and may contain extra hardware for your convenience. Table of quantity of parts CONTENTS MODEL PART NO. -
Page 11: Cart Assembly Instructions
INSTALLATION Cart assembly instructions Linking carts together (optional) To link two or more CAD1 carts, the following instructions must be done first, using the hardware provided, before installing the top modules. IMPORTANT! Once the carts are linked, they cannot be moved. Moving the carts once linked could damage the carts. - Page 12 INSTALLATION Outdoor appliance head preparation IMPORTANT! For the CAD1-48/48E there are two sets of brackets. If you have the BGB48-BQR, use the brackets labeled LEFT-48 BQR and RIGHT-48 BQR. If you have the BGB48-BQAR, use the brackets labeled 48-BQAR. First you will need to remove the angle brackets from the side of the unit and replace them with cart mount brackets.
- Page 13 INSTALLATION Position tabs on side bracket to fit into slots on the cart. When complete, the landing ledge should sit flush on the top of the cart. Pinch point Secure the head to rear of cart with Phillips- head screws provided (10-24 x 1/2”). Front end screw installation Install remaining screws (10-24 x 1/2”) into the front of head to the cart.
- Page 14 INSTALLATION Transformer installation (for Series 9 grills only) Your Series 9 grill comes supplied with a power transformer for ignition and internal lighting, which is concealed in a box with an attached power supply cord. It is recommended that the transformer is mounted to the rear panel of the CAD1-E cart using the 4 holes provided.
- Page 15 INSTALLATION Gas hook-up – LP Place your 20 lb cylinder (type 1) into the tank retention device as shown. Refer to your product user guide for detailed gas connection guidance. IMPORTANT! To prevent personal injury or damage to the drawers, do not overload them. The maximum rating of each drawer is 35 pounds.
-
Page 16: Side Shelf Assembly Instructions (Optional)
INSTALLATION Side shelf assembly instructions (optional) Optional attach side shelf accessory on either side Note: side shelf model CAD1-SK can be installed with the head already on the cart. Shoulder bolt screw location Screw two shoulder bolts into the bottom screws on the side of the cart. -
Page 17: Using The Cart
USING THE CART Removing the drawers IMPORTANT! To prevent personal injury or damage to the drawers, do not overload them. The maximum rating of each drawer is 35 pounds. To remove the drawers, pull them out until their slider latch is visible. Carefully push the latch down on the left side while pulling up on the latch on the right side and pull the drawer completely out of the frame. -
Page 18: Freezer Pack (Optional, Kit #70696A)
USING THE CART While holding the drawer up by the handle, pull the glides from the drawer cavity out over the drawer glide until they click. As you push the drawers in, you will encounter moderate resistance. Continue to push the drawer all the way in to complete the engagement process. -
Page 19: Care And Maintenance
CARE AND MAINTENANCE All parts of the Professional Grill Cart can be cleaned with hot soapy water, rinsed, dried and buffed to a shine with a soft, heavy cloth. Always try this first, as it is the mildest cleaning procedure. 1 Use the mildest cleaning procedure first. -
Page 20: Service & Warranty
SERVICE & WARRANTY For warranty service, please contact your local service provider or DCS Customer Care Representative at www.dcsappliances.com, please have the following information ready: Model number (can be found on the inside, left wall of the tank drawer). Serial number (can be found on the inside, left wall of the tank drawer). Code (can be found on the inside, left wall of the tank drawer).
