DataCard SP75 Plus Quick Install Manual page 2

Open the printer cover. Remove the protective wrap
from the cleaning roller (b) and install the cleaning
roller in the printer (c).
a Load the ribbon on the ribbon cartridge.
b Load the ribbon cartridge in the printer.
Fan the cards, and then load them
in the input hopper.
a Load the laminator cartridge(s) in the printer.
b Close the printer cover.
a Connect the power cable to
the printer.
b Connect the power cable to
an outlet.
c Power on the printer.
d Wait for the Ready light (on
the LCD panel) to turn green.
Page 2
a Open the laminator cartridge gate.
b Push the full supply roll onto the
supply spindle.
c Push the empty take-up spool
onto the take-up spindle with
the black gear.
d Close the gate.
