Data formats summary

The following table summarizes the requirements and features for each data format.
Source of data
Data formatted by
Type of connection
Printer Messages
Configuration tools
Open Card
Any host computer that produces
an ASCII data stream and uses
TCP/IP (RAW or LPD/LPR)
Open Card commands or Card
Layout menus
Ethernet or USB ports
Displayed on LCD panel
• Network configuration utility
and LCD panel
• Telnet to use Card Layout
menus (optional)
• Text editor or batch process to
insert Open Card commands
in data (optional)
• SmartDriver Diagnostics (on
PC)
SmartDriver
Windows application (with the
SmartDriver running on a
Windows PC)
SmartDriver running on a
Windows PC
Ethernet or USB ports
Displayed in Windows message
boxes and on LCD panel
• Network configuration utility
and LCD panel
• SmartDriver Printer Toolbox
• Printer Properties and Printing
Preferences
• SmartDriver Diagnostics (on
PC)
Page 19
