Fagor Automation
MANUAL CODE:
MANUAL VERSION:
LINEAR ENCODER MODEL: SAS
ENCODER LINEAL MODELO: SAS
14460100
V1503

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SAS and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Fagor SAS

  • Page 1 Fagor Automation LINEAR ENCODER MODEL: SAS ENCODER LINEAL MODELO: SAS MANUAL CODE: 14460100 MANUAL VERSION: V1503...
  • Page 2 Page 2/16 - "SAS" - V1503...
  • Page 3 Dimensions in mm Dimensiones en mm V1503 - "SAS" - Page 3/16...
  • Page 4: Mounting Possibilities

    MOUNTING POSSIBILITIES POSIBILIDADES DE MONTAJE MOUNTING PRECAUTIONS PRECAUCIONES PARA EL MONTAJE Page 4/16 - "SAS" - V1503...
  • Page 5: Mounting Process

    PROCESO DE MONTAJE MOUNTING PROCESS - 1 - - 2 - - 3 - V1503 - "SAS" - Page 5/16...
  • Page 6 Pa = 20 Nm M8x20 DIN 7984 Inox. Washer / Arandela: AET 8.4 M4x20 DIN 912 Washer / Arandela: AET 4.3 M4x20 DIN 912 Pa = 2.5 Nm - 4 - - 5 - Page 6/16 - "SAS" - V1503...
  • Page 7 - 6 - After mounting it on the machine Tras montarla en la máquina - 7 - - 8 - V1503 - "SAS" - Page 7/16...
  • Page 8 Class 4(7 bar) - Punto rocío / dewpoint 3ºC Class 1 - Max. oil concentration 0.01 mg/m Pa = 1 Nm · Unidades de filtro de aire recomendadas por FAGOR. Modelos AI-400 AI-525 para 2 ejes, AI-550 para 4 ejes, AI-590 para 6 ejes.
  • Page 9: Electrical Characteristics

    20 s to 35 s Gray or binary (configurable) Parity Fully configurable Configuration of the SSI protocol Values for SSI protocol in Fagor SAS linear encoders Number of bits 26 (25 data + 1 parity) Counting resolution 0.1 µm Data type...
  • Page 10 20 s a 35 s Gray o binario (configurable) Paridad Totalmente configurable Configuración del protocolo SSI Valores en reglas Fagor SAS para el protocolo SSI Número de bits 26 (datos + 1 paridad) Resolución de contaje 0.1 µm Tipo de datos...
  • Page 11 The CNC can request the position of the linear encoder at any time. La posición de referencia entre la cabeza lectora y el encoder lineal se determina sin tener que mover el eje. El CNC puede solicitar la posición del encoder lineal en cualquier momento. V1503 - "SAS" - Page 11/16...
  • Page 12 CABLES / MANGUERAS Page 12/16 - "SAS" - V1503...
  • Page 13 EXTENSION CABLES / ALARGADERAS V1503 - "SAS" - Page 13/16...
  • Page 14 ELECTRICAL INFORMATION / INFORMACIÓN ELÉCTRICA Page 14/16 - "SAS" - V1503...
  • Page 15: Warranty

    * Term: 12 months from factory invoice date. * 12 meses desde fecha de expedición de fábrica. * It covers parts and labor at FAGOR AUTOMATION. * Cubre gastos de Materiales y Mano de Obra de repa- * Travel expenses are payable by the customer.
  • Page 16 Fagor Automation S. Coop. Bº San Andrés Nº19 Apdo Correos 144 20500 - Arrasate/Mondragón - Spain - Web: www.fagorautomation.com Email: info@fagorautomation.es Tel.: (34) 943 719200 Fax: (34) 943 791712...
