Page 1: Table Of Contents
FLT-03-2-1 User Manual Contents Caution Specifications Dimensional Drawing Components/Setup Operation... -
Page 2: Caution
Caution Warning Ensure no obstacles are in the lifting column's path. Ensure the top is not touching any walls. Ensure all Pinch Point cords are appropriate length to accommodate the change Keep hands and fingers clear. in height. Keep children away from electric height-adjustable lifting columns, control units, and handsets. There is a risk of injury and electric shock. -
Page 3: Specifications
Specifications Input Voltage 120 VAC, 60 Hz Output Voltage 24 VDC Stroke 16" 440lbs Weight Capacity Speed 0.5"/sec 22.8" - 37.9" (without tabletop) Height Range 10% Max. 2 mins on, 18 mins off Duty Cycle Material Aluminum Alloy Certification IP Rating IP43 Feature Description... -
Page 4: Dimensional Drawing
Dimensional Drawing Control Box 7.9" 4.5" 1.6" 2.3" 0.3" 2.4" 0.2" 0.3" Ø0.8" 3.9" 0.8" Ø0.2" 3.9" 1.6" 1.5" 4.4" 2.8" 1.0" 0.5" 0.5" 0.8" Ø0.3" 3.2" 3.3" 6.7" 2.8" 2.4" 1.0" 0.7" 0.4" 0.4" 1.4" 3.6" 4.1" 4.5" 3.8" Ø0.5"... -
Page 5: Components/Setup
Components 1 Lifting Column Control Box and Remote Setup FLT-03-2-1 LIFTING COLUMN Wired Remote Control Box... -
Page 6: Operation
Once the lifting column is installed, use the wired remote for full up and down motion control. The momentary buttons require the user to press and hold the button for both up and down control. Once the button is released, the FLT-03-2-1 will stop moving.
