progressive automations FLT-06 User Manual

Hide thumbs
1
2
3
4
5
6
7

Advertisement

Table of Contents

FLT-06
User Manual
Contents
1
2
3
4
5
6

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FLT-06 and is the answer not in the manual?

Questions and answers

Related Manuals for progressive automations FLT-06

Summary of Contents for progressive automations FLT-06

  • Page 1: Table Of Contents

    FLT-06 User Manual Contents Caution Specifications Dimensional Drawing Components/Setup Operation/Reset Procedure Troubleshooting...

  • Page 2: Caution

    Caution Warning Ensure no obstacles are in the column's path. Ensure the columns are not touching any walls. Ensure all cords Pinch Point are appropriate length to accommodate the change in Keep hands and fingers clear. height. Keep children away from electric height-adjustable lifting columns, control units, and handsets. There is a risk of injury and electric shock.

  • Page 3: Specifications

    Specifications Input Voltage 120 VAC, 60 Hz Output Voltage 24 VDC Stroke 25" Weight Capacity 350 lbs (175 lbs Per Leg) Speed 1.30"/sec Height Range 23.5” - 49” (without table top) Duty Cycle 10% Max. 2 mins on, 18 mins off Material Steel Certification...

  • Page 4: Dimensional Drawing

    Dimensional Drawing Legs 3.2" 2.8" 0.4" 2.0" M6X10 Remote 3.3" 1.4" 0.2" 3.4" 2.0" 3.2" 2.0" 22.0" ˄ ˅ M8X10 0.6" 5.7" 2.2" 1.6" 2.5" 0.6" 6.6" 2.0" M6X10 7.6" 3.8" Control Box 1.6" 0.7" 3.5" 3.5" 0.3" 0.1" 10.1"...

  • Page 5: Components/Setup

    Components Control Box & Remote Connector Cables x 2 Lifting Columns x 2 AC Power Cord Setup FLT-06 FLT-06 LIFTING COLUMN [M1] LIFTING COLUMN [M2] 110/240VAC FLT-06 CONTROL BOX WIRED REMOTE...

  • Page 6: Operation/Reset Procedure

    Operation Normal Operation Using the wired remote, press and hold the 'Up' button to raise the lifting columns. To lower the lifting columns, press and hold the 'Down' button. The 'Up' and 'Down' buttons are momentary controlled, when they are released, the lifting columns will stop immediately.

  • Page 7: Troubleshooting

    Troubleshooting Troubleshooting Guide Problem Possible Cause Corrective Action Low power mode Press any button on the remote and LED will activate. activated Remote LED is off. Disconnect and reconnect the RJ-45 remote connector. Ensure connection is Connection issue secure and cable is not damaged. Follow "Setting Limit Switches"...
