Table 5: Termination details
Type of Input/
Type of field device
Output
Current Input - Internal
UI
Source (3-wire)
Current Input - External
UI
Source (in Loop)
Feedback from
UI
EPP-1000
Dry Contact (Binary
UI
Input)
0–10 VDC Output to
Actuator (External
AO
Source)
0–10 VDC Output to
Actuator (Internal
AO
Source)
10
IOM2721 Input/Output Module Installation Guide
Termination diagrams
