THORLABS ELL7 Operating Manual page 16

ELL7K Linear Stage Evaluation Kit
Communications
f
Bus
Connector on Linear Stage Board
Connectors on Interface Board
Speed
Data Length
Protocol Data Format
Module Address and Command Format
8-Conductor Ribbon Cable Length (Supplied)
8-Conductor Ribbon Cable Length (Maximum)
General
Operating Temperature Range
Dimensions with bracket fitted
Dimensions of interface board
Weight (Stage plus Bracket)
Weight (Stage Only)
Notes
f. Use two 10 kΩ pull-up resistors in multi-drop mode for RX/TX
Page 14
Multi-Drop 3.3 V/5 V TTL RS232
Picoflex®
Picoflex®
Micro-B USB
5 VDC Power:
[For Plug with Ø5.5 mm OD (Ground)
and Ø2.1 mm ID (+5 V)]
9600 baud
(1 Stop Bit, No Parity) 8 bit
ASCII HEX
Mnemonic Character
250 mm
3 m
15 to 40 °C (59 to 104 °F)
68.0 x 67.0 x 18.4 mm (2.68" x 2.64" x 0.73")
66.0 x 32.0 x 12.5 mm
(2.6" x 1.26" x 0.49")
Metric 0.076 Kg, Imperial 0.168 lb
Metric 0.052 Kg, Imperial 0.114 lb
Chapter 6: Specifications
DTN000044-D02
