KEYPAD OPTIONS

UP: Pressing and holding the UP button for 5 seconds will take you into the data Upload mode
(refer to USB data upload
UP: Consecutive (short) button press cycles between the following information on top of the
display.
a. Gas: Current selected Gas
b. Pressure: Gas pressure in PSI
c. Pressure: Gas pressure in PSIA
d. Totalizer: Total volume of gas according to the selected units.
e. Temperature: Temperature in degree Celsius
f. Temperature: Temperature in degree Fahrenheit
g. Battery: Battery charge level percentage
Options (a) through (f) are saved in the memory so that next time you turn the power on it
will remember the display settings.
DOWN: Consecutive button press cycles between the different flow units. SCFH, SLPM and
SCCM. Once selected, the setting is saved into the memory of the device. Long pressing this
button will take it into data Download mode (refer to USB
To reset the totalizer, press SET until the LCD shows "TARING". Release the SET button
immediately, and the totalizer will be reset.
To tare the meter (at zero flow) press SET until the LCD shows "TARING". Keep holding the
SET button (for 5 seconds) until the LCD shows "TARED" and the flow output will be set to
zero.
FDMAN-1-190214
mode).
5 seconds
data download mode).
