GETTING STARTED GUIDE
NI cRIO-9065
Embedded Real-Time Controller with Reconfigurable FPGA for C
Series Modules
This document describes how to begin using the NI cRIO-9065.
Safety Guidelines
Caution
Product misuse can result in a hazard. You can compromise the safety protection
built into the product if the product is damaged in any way. If the product is
damaged, return it to NI for repair.
Safety Guidelines for Hazardous Locations
The cRIO-9065 is suitable for use in Class I, Division 2, Groups A, B, C, D, T4 hazardous
locations; Class I, Zone 2, AEx nA IIC T4 and Ex nA IIC T4 hazardous locations; and
nonhazardous locations only. Follow these guidelines if you are installing the cRIO-9065 in a
potentially explosive environment. Not following these guidelines may result in serious injury
or death.
Do not operate the cRIO-9065 in a manner not specified in this document.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the NI cRIO-9065 and is the answer not in the manual?

Questions and answers

Summary of Contents for National Instruments NI cRIO-9065

  • Page 1 GETTING STARTED GUIDE NI cRIO-9065 Embedded Real-Time Controller with Reconfigurable FPGA for C Series Modules This document describes how to begin using the NI cRIO-9065. Safety Guidelines Caution Do not operate the cRIO-9065 in a manner not specified in this document.
  • Page 2: Special Conditions For Hazardous Locations Use In Europe And Internationally

    IP54 as defined in IEC/EN 60079-15. Caution The enclosure must have a door or cover accessible only by the use of a tool. 2 | ni.com | NI cRIO-9065 Getting Started Guide...
  • Page 3: Electromagnetic Compatibility Guidelines

    Ensure that the environment in which you are using the cRIO-9065 meets the following specifications. Operating temperature -40 °C to 70 °C (IEC 60068-2-1, IEC 60068-2-2) Operating humidity (IEC 60068-2-56) 10% RH to 90% RH, noncondensing Pollution degree Maximum altitude 5,000 m NI cRIO-9065 Getting Started Guide | © National Instruments | 3...
  • Page 4: Unpacking The Kit

    Before using the cRIO-9065, you must install the following application software and device drivers on the host computer in this order: LabVIEW 2014 SP1 or later LabVIEW Real-Time Module 2014 SP1 or later 4 | ni.com | NI cRIO-9065 Getting Started Guide...
  • Page 5: Installing C Series Modules

    The cRIO-9065 has the following connectors, LEDs, and buttons. LabVIEW FPGA Module is not required when using Scan Interface mode. To program the user- accessible FPGA on the cRIO-9065, LabVIEW FPGA Module is required. NI cRIO-9065 Getting Started Guide | © National Instruments | 5...
  • Page 6 Tighten the grounding screw to 0.5 N · m (4.4 lb · in.) of torque. Attach the other end of the wire to the grounding electrode system of your facility using a method that is appropriate for your application. 6 | ni.com | NI cRIO-9065 Getting Started Guide...
  • Page 7 Do not tighten or loosen the terminal screws on the power connector while the cRIO-9065 is powered on. Connect the power supply to the power connector, as shown in the following figure. NI cRIO-9065 Getting Started Guide | © National Instruments | 7...
  • Page 8 Refer to the user manual on ni.com/manuals for more information about Ethernet connections. Configuring the System in Measurement & Automation Explorer (MAX) Complete the following steps to find the system in MAX. 8 | ni.com | NI cRIO-9065 Getting Started Guide...
  • Page 9: Setting A System Password

    Select Add/Remove Software to launch the LabVIEW Real-Time Software Wizard. You must log in if you set a system password. Select the recommended software set for your LabVIEW and NI-RIO Device Drivers versions. Click Next. NI cRIO-9065 Getting Started Guide | © National Instruments | 9...
  • Page 10 Windows 7, select Start»Control Panel»Device Manager»Network adapters»National Instruments»USBLAN adapter. If the USBLAN adapter is not recognized, you must reinstall NI-RIO Device Drivers. • Temporarily disable any network firewalls or other security software. 10 | ni.com | NI cRIO-9065 Getting Started Guide...
  • Page 11: Verify The System Ip Configuration

    Ensure that UDP port 44525 is open to communication on the host computer. If you are using an intelligent switch on the network, ensure that it is not disabling UDP port 44525. System Reset The following figure shows the reset behavior of the cRIO-9065. NI cRIO-9065 Getting Started Guide | © National Instruments | 11...
  • Page 12: Status Led Indicators

    & Automation Explorer (MAX) Help for information about safe mode. Blinks four times The cRIO-9065 is in safe mode. The software has crashed twice and pauses without rebooting or cycling power between crashes. 12 | ni.com | NI cRIO-9065 Getting Started Guide...
  • Page 13: Where To Go Next

    The NI website is your complete resource for technical support. At ni.com/support, you have access to everything from troubleshooting and application development self-help resources to email and phone assistance from NI Application Engineers. NI cRIO-9065 Getting Started Guide | © National Instruments | 13...
  • Page 14 CONTAINED HEREIN AND SHALL NOT BE LIABLE FOR ANY ERRORS. U.S. Government Customers: The data contained in this manual was developed at private expense and is subject to the applicable limited rights and restricted data rights as set forth in FAR 52.227-14, DFAR 252.227-7014, and DFAR 252.227-7015. © 2015 National Instruments. All rights reserved. 376902A-01 Oct15...
