A5 DashMaster
USER MANUAL
INNOSILICON CONFIDENTIAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the A5 DashMaster and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for INNOSILICON A5 DashMaster

Summary of Contents for INNOSILICON A5 DashMaster

  • Page 1 A5 DashMaster USER MANUAL INNOSILICON CONFIDENTIAL...

  • Page 2: Table Of Contents

    INNOSILICON A5 DashMaster High Efficient LTCMaster Table of Contents 1. OVERVIEW 2. MINER ASSEMBLE 2.1 Check the miner before power on 2.2 Connect the PSU 2.3 Connect the Ethernet Cable 3. ENTER THE MINER CONSOLE 4. CONFIG THE MINER 5. APPENDIX 5.1 Modify the login password...

  • Page 3: Overview

    A5 DashMaster 1. OVERVIEW Chip Type A5 DashMaster ASIC Hash Rate 32.5GH/s(+/-8%) Power 750W +/-8% Size (L×W×H) 400mm×135mm×158mm Net Weight 4.0KG(without PSU) Operating Temperature 0-40 ℃ Network Connection Ethernet INNOSILICON CONFIDENTIAL...

  • Page 4: Check The Miner Before Power On

    A5 DashMaster 2. CABLE CONNECTION 2.1 CHECK THE MINER BEFORE POWER ON · Check the warranty sticker is well or not, especially the hashboards PSU port side. If the warranty sticker is damaged when you received the miner, please contact our After-sales.

  • Page 5: Connect The Psu

    A5 DashMaster 2.2 CONNECT THE PSU Every hashboard needs to be inserted with 2 PSU cables according to the following image (Image 3). They as listed as slots 1, 2, 3, 4, 5, and 6 in the image. Controller only needs 1 PSU cable. It should be inserted in slot labeled 7 (Image 1.3).

  • Page 6: Connect The Ethernet Cable

    A5 DashMaster 2.3 CONNECT THE ETHERNET CABLE Insert one end of the Ethernet cable into the router and the other end into the slot shown in the following image, you should plug in the miner one by one, only when you have accomplished IP Setting of the previous one you can plug in another miner .

  • Page 7: Enter The Miner Console

    A5 DashMaster 3. ENTER THE MINER CONSOLE By default, the miner uses Static IP to access the control webpage of the miner. Input 192.168.1.254 into the browser, then click ‘Enter’ to enter the miner’s control webpage (Chrome is the suggested browser).
  • Page 8 A5 DashMaster · In the properties panel, double click the “Internet protocol version 4(TCP/IP)” . Then select the “Use the following IP address”, fill in the IP address and Subnet mask as the right image. INNOSILICON CONFIDENTIAL...

  • Page 9: Config The Miner

    A5 DashMaster · Press the OK button twice to confirm the changes.Then modify the IP address of the miner (Do it as the follow step 4.4) to guarantee the miner and the router have the same network segment.Then connect the miner with the router,connect the PC with the router and select the “Obtain the IP address automatically”.Now you can enter the IP through the browser into the control interface...
  • Page 10 A5 DashMaster Password is wrong/error?—Please contact our support team 4.3 Enter the mining pool’s URL, Worker, password according to the following image, then click .The miner will start mining, and the page will return to the ‘Miner Configuration’ page. It will show the user’s modified setting.
  • Page 11 A5 DashMaster 4.4 To avoid IP conflict when using 2 or more miners at the same time, the IP address needs to be changed. Enter the network interface shown in the following image, and modify the IP address to you need, then click the “Save”...
  • Page 12 A5 DashMaster 4.5 Enter ‘Miner Status’ page to check the status on the mining pool configuration and performance of the miner. HW: means error in calculating INNOSILICON CONFIDENTIAL...

  • Page 13: Appendix

    A5 DashMaster 5. APPENDIX 5.1 MODIFY THE LOGIN PASSWORD Select the “Administration” interface at System, then you can modify your password. Then click to save your new password. Note: As the factory reset will not reset the password to the default password, you must take care your new password.
  • Page 14 A5 DashMaster Build date is the version of the firmware. If your miner build date is before NOV 24,please upgradeyour miner via a TF card. Here is the instruction: http://www.innosilicon.com.cn/api/download.php?url=TF-card-firmware-update-manual-en.pdf If your miner build date is NOV 24 or later, a web upgrade is OK, you can do it as below .
