- Page 1 One Channel Receiver 315MHz VIS-8004 USER MANUAL For support: sales@visionistech.com...
-
Page 2: Specifications
DESCRIPTION The model VIS-8004 is a 1-Channel 315MHz RF receiver supplied with antenna. This receiver is designed for use with the VISIONIS VIS-8005 1 channel remote. The 1 channel RFreceiver operates for opening doors, garage doors, and gates. Very easy and convenient as well for home/store anti-theft security systems. -
Page 3: Important Notes
INSTRUCTIONS TO PROGRAM A NEW TRANSMITTER ( REMOTE CONTROL) Each VIS-8004 Visionis receiver can program up to 50 transmitters (remotes) (VIS-8005). Before you program this function make sure you have one of your remotes on hand. Now press the “Learning Button” once and release it right away. Then immediately press the button on the remote one time and release it. -
Page 4: Wiring Diagram
ON/ Off Toggle Function (L): This function works exactly like an on/off switch. When the Transmitter (remote) button is pressed once, the receiver turns on. When the transmitter (remote) is pressed again the relay turns off. Latched: Press transmitter button A, the receiver relay A is on, Press transmitter button B, the receiver relay A will stop work. - Page 5 DIFFERENT TYPE OF APPLICATION Positive Output Negative Output Positive Power Sources Negative Power Sources Positive Power Output Negative Power Output Power Power Typical N.C. Application Typical N.O. Application Magnetic locks Magnetic locks 12VDC 12VDC N.O. Application with independent N.C. Application with independent Power Sources Power Sources Magnetic locks...
