- Page 1 One Channel Receiver 315mhz VIS-8004 USER MANUAL For support: sales@visionistech.com...
-
Page 2: Specifications
20 DESCRIPTION The Visionis VIS-8004 RF Wireless Receiver was built to feed the demand for a device that can meet multiple functions without having to purchase additional devices. The VIS-8004 RF receiver can be used to control all sorts of Electrical devices such as Garage door Openers, Lights, Motorized gates, Mag locks, Electric Strikes, lifts and many more devices. -
Page 3: Important Notes
INSTRUCTIONS TO PROGRAM A NEW TRANSMITTER ( REMOTE CONTROL) Each VIS-8004 Visionis receiver can program up to 20 Transmitters (remotes) (VIS-8005) Make sure that while you are programming the transmitter (remote) you have the remote in your hands ready to be programmed. -
Page 4: Led Indication
Clamp Function: When The Transmitter (remote) button is pressed once the receiver turns ON and stays ON. The receiver will remain on regardless if another remote is pres sed. To turn OFF the receiver Press the Receiver function mode button once and the device will reset. - Page 5 DIFFERENT TYPE OF APPLICATION Positive Output Negative Output Positive Power Sources Negative Power Sources Positive Power Output Negative Power Output Power Power Typical N.C. Application Typical N.O. Application Magnetic locks Magnetic locks 12VDC 12VDC N.O. Application with independent N.C. Application with independent Power Sources Power Sources Magnetic locks...
