- Page 1 Two Channels Receiver 315mhz VIS-8007 USER MANUAL For support: sales@visionistech.com...
- Page 2 DESCRIPTION The Visionis VIS-8007 RF Wireless Receiver was built to feed the demand for a device that can meet multiple functions without having to purchase additional devices. The VIS-8007 RF receiver can be used to control all sorts of Electrical devices such as Garage Door Openers, Lights, Motorized Gates, Mag Locks, Electric Strikes, Lifts and many more devices.
- Page 3 INSTRUCTIONS TO PROGRAM A NEW TRANSMITTER ( REMOTE CONTROL) Each VIS-8007 Visionis receiver can program up to 50 transmitters (remotes) (VIS-8008 and VIS-8005). Before you program this function make sure you have one of your remotes on hand. Now press the “Learning Button” once and release it right away. Then immediately press the button on the remote one time and release it.
- Page 4 ON/ Off Toggle Function (L): This function works exactly like an on/off switch. When the Transmitter (remote) button is pressed once, the receiver turns on. When the transmitter (remote) is pressed again the relay turns off. Latch: Press transmitter button A, the receiver relay A is on, Press transmitter button B, the receiver relay A will stop work.
- Page 5 DIFFERENT TYPE OF APPLICATION Positive Output Negative Output Positive Power Sources Negative Power Sources Positive Power Output Negative Power Output Power Power Typical N.C. Application Typical N.O. Application Magnetic locks Magnetic locks 12VDC 12VDC N.O. Application with independent N.C. Application with independent Power Sources Power Sources Magnetic locks...
