  • Page 1 MatriX 1050/650 40011616-1623 MatriX 1050/650 ENG...
  • Page 2 Installation Instructions...
  • Page 3 Installation Instructions...
  • Page 4 Installation Instructions...
  • Page 5 Installation Instructions...
  • Page 6 Installation Instructions...
  • Page 7 Installation Instructions I.T.C. versie: Symax versie:...
  • Page 8 Installation Instructions...
  • Page 9 Installation Instructions...
  • Page 10 Installation Instructions...
  • Page 11 Installation Instructions...
  • Page 12 Installation Instructions WRONG!!

  • Page 13: Installation Requirements

    For devices with flexible gas pipes, the gas regulator block is mounted on the right side of the fire for transport reason (fig 1.6). Glen Dimplex Benelux certifies that this Faber fire complies with the The gas regulator block with the receiver and the I.T.C. must be essential requirements of the gas appliances directive.

  • Page 14: Preparation And Installation Instructions

    Ø100mm or Ø130mm with CE marking for 600°C. 4.2.2 Faber ITC (Intelligent Technical Controller) > Please note: The ITC gives you more options, such as ECO control, control, The minimum chimney diameter for a 130mm flexible stainless error messages, maintenance advice and such.

  • Page 15: Removing Theglass

    Do not insulate but ventilate built-in flue material (approx. 100cm²). Removing the glass from the front Constructing the false chimney MatriX 1050/650-I • Remove the moldings “A” left and right (fig. 3.0). If possible, carry out a performance test at the fire before finally •...

  • Page 16: Checking The Installation

    Installation Instructions Checking the burner pressure and primary Removing the glass from the side pressure It is not necessary to take out the glass from the side to place the log set or for maintenance. Check that the burner pressure and primary pressure match with the information listed in the manual, Chapter 14 “Technical MatriX 1050/650-IIL, -IIR and 1050/650-III specifications”.

  • Page 17: Annual Maintenance

    A simple way to calculate whether the exhaust configuration is qualified specialist to ensure the safe use and to guarantee a possible in combination with your fire, use the free “Faber Flue App” long service life. and download it from: •...
  • Page 18 Installation Instructions • Pipes under a tilt angle: These are pipes which are vertically ascending at an angle of 30° or 45° (fig. 12.1 C). Fill in only in combination with at least 2x 30 or 45° bends in the vertical part. •...
  • Page 19 Installation Instructions 11.1 Restrictor table (100/150) NG Starting length (STL), Vertical (TVH) and Horizontal (THL) 40,2 45,2 45,2 45,5 50,2 50,2 50,2 50,2 60,2 60,2 60,2 30,2 60,2 30,2 70,2 30,2 70,2 30,2 30,2 70,2 30,2 30,2 70,2 30,2 30,2 80,2 30,2 30,2...
  • Page 20 Installation Instructions 11.2 Restrictor table (130/200) NG Starting length (STL), Vertical (TVH) and Horizontal (THL) 30,4 30,3 30,4 30,4 30,4 30,4 30,4 30,4 30,3 30,4 30,4 30,4 30,4 30,4 30,4 30,3 30,4 30,4 30,4 30,4 30,4 40,4 40,3 40,4 30,4 30,4 30,4 30,4...
  • Page 21 Installation Instructions 11.3 Restrictor table (130/200) LPG Starting length (STL), Vertical (TVH) and Horizontal (THL) THL in meters 40,4 40,4 40,4 30,4 30,4 50,4 40,4 40,4 40,4 30,4 30,4 50,4 50,4 40,4 40,4 40,4 30,4 30,4 60,4 50,4 50,4 40,4 40,4 40,4 30,4...
  • Page 22 Installation Instructions Examples flue materials fig. 12.1 fig.12.2 fig. 12.3...
  • Page 23 Installation Instructions Calculation sheet Starter length (STL) First part on top of the appliance Value Flue length from 0,1m till 0,45m Flue length from 0,5m till 0,90m Flue length from 1m till 1,4m Flue length from 1,5m till 2m Flue length 2m or more Bend 90°...
  • Page 24 Installation Instructions found value Search in the table at TVH and THL and enter the value that is found. ……………………………… If the detected value is a number, check whether the completed STL is higher or equal to the value in the table. Is the STL value lower as specified in the table then the installation is not possible.

  • Page 25: Tecnical Data

    Installation Instructions Tecnical data II2H3+ II2H3+ II2H3+ Gas category Type appliance C11/C31/C91 C11/C31/C91 C11/C31/C91 Reference gas Input Hi 11,3 11,3 11,3 Efficiency class NOx-class Inlet pressure mbar Gas rate m³/h 1,187 0,341 0,443 gr/h (at 15º C and 1013 mbar) Burner pressure at full mark mbar 13,8...

  • Page 26: Terminal Position

    Installation Instructions Terminal position > Please note: These rules apply only for the proper functioning of the unit, for ventilation and environmental protection you need to comply with the applicable rules Short roof terminal. as defined in the building regulations. Only for existing Chimney connection Extension pipe over roof...

  • Page 27: Troubleshooting Guide

    Installation Instructions Troubleshooting guide - See inst. manual. - Learn a new code for remote. Light the pilot flame with - 1x 9V Alkaline. the remote, beep every - Battery remote. - 4x 1.5V AA Alkaline. - Battery receiver. second? - Replace 6V adapter.
  • Page 28 Installation Instructions Min. 4 mV Main burner stays on? Min 1.2 mVolt - Check fluecalculation. (horizontal length to long?) Flame stays blue, lift from The flames are yellow - Correct fluerestrictor? the burner and fireswitch after 10/15 minutes? - Flue parts not correctinstalled? - Wall/roof terminal blocked?
  • Page 29 Installation Instructions - RESET the receiver Optional: - Check the wiring from Step burner function can solenoid valve to receiver. be turned ON and OFF. - Faulty solenoid valve. - Replace solenoid valve. (only with remote) - Faulty receiver. - Replace receiver. - RESET the receiver.

  • Page 30: Dimensional Drawings

    Installation Instructions Dimensional drawings 17.1 MatriX 1050/650-I...
  • Page 31 Installation Instructions 17.2 MatriX 1050/650-IIL...
  • Page 32 Installation Instructions 17.3 MatriX 1050/650-IIR...
  • Page 33 Installation Instructions 17.4 MatriX 1050/650-III...
  • Page 34 Installation Instructions 17.5 Wall bracket...
  • Page 35 Installation Instructions 17.6 Remote acces door...
  • Page 36 Installation Instructions 17.7 Ventilation grid...
  • Page 37 Installation Instructions 17.8 Adjustable feet...
  • Page 38 Installation Instructions...
  • Page 39 Installation Instructions...
  • Page 40 Installation Instructions...
  • Page 41 Installation Instructions Dealerinfo: www.faber.nl info@faber.nl Saturnus 8 NL - 8448 CC Heerenveen Postbus 219 NL - 8440 AE Heerenveen...
