AUDIO SETTINGS

• Before making an adjustment for [DISTANCE] and [GAIN] of [DTA SETTINGS], select the

speaker you want to adjust:

When 2-way crossover is selected:

FRONT LEFT/FRONT RIGHT/REAR LEFT/REAR RIGHT/SUBWOOFER

– You can only select [REAR LEFT], [REAR RIGHT] and [SUBWOOFER] if a setting other

than [NONE] is selected for [REAR] and [SUBWOOFER] of [SPEAKER SIZE]. ( 23)

When 3-way crossover is selected:

TWEETER LEFT/TWEETER RIGHT/MID LEFT/MID RIGHT/WOOFER

– You can only select [WOOFER] if a setting other than [NONE] is selected for [WOOFER] of

[SPEAKER SIZE]. ( 24)

• [R-SP LOCATION] of [CAR SETTINGS] is selectable only if:

– 2-way crossover is selected. ( 6)

– A setting other than [NONE] is selected for [REAR] of [SPEAKER SIZE]. ( 23)

Determining the value for [DISTANCE] and [GAIN] of [DTA SETTINGS]

If you specify the distance from the center of the

currently set listening position to every speaker,

the delay time will be automatically computed

and set.

1 Determine the center of the currently set

listening position as the reference point.

2 Measure the distances from the reference

point to the speakers.

3 Calculate the differences between the

distance of the furthest speaker (rear

speaker) and other speakers.

4 Set the [DISTANCE] calculated in step

individual speakers.

5 Adjust [GAIN] for individual speakers.

Example: When [FRONT ALL] is selected as the

listening position
