Connecting HPT225BT and Computer
computer using special cable (not included in the standard kit) Access Data-Ser Cable, USB/DB15
(1,8m) (p/n 14-578123-01).
1. Download the zip-archive with USB driver from www.javad.com;
2. Extract the archive to the new empty folder;
3. Connect the USB port of the computer to the USB port of the modem at the switched off power
supply by using of a cable.
4. Turn on your computer.
5. Power HPT225BT.
6. Widows will detect USB driver automatically. Otherwise it will ask to specify driver location.
Select the folder with extracted file.

4.3. Connecting through Bluetooth

Note:
Do not forget to attach the Bluetooth
modem.
The HPT225BT modem contains Bluetooth
the modem and any other external device that supports Bluetooth
HPT225BT and external device connection procedure varies slightly depending on the type of external
device used. In general, the connection procedure is as follows:
Note:
Refer to your Bluetooth
information.
1. Turn on a Bluetooth
mode is Master; the modem's Bluetooth
2. Instruct the external device (Master) to search for the modem (Slave).
3. Once the Master device detects the modem, use the procedure described in the external device's
documentation to connect it with the modem.
18
Figure 3. Cable p/n 14-578123-01
®
antenna to Bluetooth antenna connector on the back panel of the
®
wireless technology that allows synchronization between
®
-enabled external device documentation for more detailed connection
®
-enabled external device and your receiver. The default external device
®
module mode is Slave.
®
®
wireless technology.
