System Requirements; Hardware Installation - D-Link DCS-2100+ Quick Installation Manual

System Requirements

•
Internet Explorer 5.x or above
•
CPU: Pentium III, 800MHz or above (Required for use with IP surveillance software)
•
Memory Size: 128MB (256MB recommended)
•
VGA card resolution: 800x600 or above

Hardware Installation

Connect the Ethernet Cable
If you will be using the DCS-2100+ in a wired network,
connect an Ethernet cable to the network cable connector
located on the Internet Camera's back panel and attach it
to the network.
If you connect this camera directly to
a PC, you will need a cross-over
Ethernet cable. If you plug the camera into a
hub or router, you will be able to use the cable
included with your camera.
Attach the antennas to the camera
If you will be using the DCS-2100+ in a wireless network,
attach the antennas to the back of the camera by turning
the antennas in the clockwise direction until snug, do not
over tighten.
