REPAIR AND MAINTENANCE

Before beginning repair or maintenance:
• Read the instructions
• Disconnect charger
Front Wheel Replacement
Tools Required: 13mm socket wrench
1
Using the 13 mm socket loosen
the locknut.
3
Insert replacement wheel,
washer and locknut.
Rear Wheel Replacement
Tools Required: 13mm socket wrench
1
Using the 13 mm socket, loosen
the locknut.
• Turn the power button OFF
• Exercise caution around
exposed parts
2
Remove the locknut, washer and
wheel.
4
Tighten the locknut.
2
Remove the locknut, washer and
wheel.
Note: Make sure to align the holes
on the replacement wheel with the
splines on the motor gear.
• Contact Razor Customer Service
if unsure about any repair or
maintenance
8
5-2
5-3
5-4
5-2
5-3
5-1
Wheel
5-1 Lock Nut
5-2 Washer (x2)
5-3 Bearing (x2)
5-4 Spacer
