AP-8533 Access Point
Installation Guide
Published June 2017
9035105
9035105
Published June 2017
9035105

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AP-8533 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Extreme Networks AP-8533

Summary of Contents for Extreme Networks AP-8533

  • Page 1 AP-8533 Access Point Installation Guide Published June 2017 9035105 9035105 Published June 2017 9035105...
  • Page 2 Copyright © 2017 Extreme Networks, Inc. All Rights Reserved. Legal Notices Extreme Networks, Inc. reserves the right to make changes in specifications and other information contained in this document and its website without prior notice. The reader should in all cases consult representatives of Extreme Networks to determine whether any such changes have been made.

  • Page 3: Table Of Contents

    Wall Mount Instructions ..............................13 Wall Mount Procedure - New Installation .........................13 Suspended Ceiling T-Bar Mount Instructions ......................15 LED Indicators ...................................19 Basic Access Point Configuration................. 21 AP-8533 Access Point Specifications ..............31 Electrical Characteristics ..............................31 Physical Characteristics ..............................31 Radio Characteristics ..............................32 Regulatory Information ..................33 Bluetooth Wireless Technology ..........................33...
  • Page 4 Thailand ......................................42 Eurasian Customs Union ................................ 42 Waste Electrical and Electronic Equipment (WEEE) ..................42 TURKISH WEEE Statement of Compliance ........................43 Support ........................45 End-User Software License Agreement.............. 47 AP-8533 Access Point China ROHS Compliance..........53 AP-8533 Access Point Installation Guide...

  • Page 5: Introduction

    The AP-8533 external antenna and internal antenna Access Point's are high-tier Access Point's for dependable and efficient network performance. The AP-8533 is a tri-radio Wave 2 802.11ac Access Point utilizing one 5GHz 802.11ac radio, one 2.4GHz 802.11n radio and a dual-band unlock 2.4GHz/5GHz 802.11ac radio for sensor functionality.

  • Page 6: Ap-8533 Package Contents

    • Verify cable lengths are within the maximum allowable distances for optimal signal transmission. AP-8533 Package Contents An AP-8533 Access Point is available in both external antenna (AP-8533) and internal antenna (AP-8533I) configurations. An AP-8533 ships with the following: • AP-8533 Access Point •...

  • Page 7: Ap-8533 Antennas

    6.92 7.23 3.95 Panel ML-2452-PTA4M4-036 Patch Dual Band 2.4 GHz / 5 GHz Internal Antennas - US/Taiwan An AP-8533 internal antenna Access Point supports the following dual band antenna: Antenna 2.4 GHZ 5 GHZ Elevation Type Gain (dBi) Gain (dBi)

  • Page 8: Dual Band 2.4 Ghz / 5 Ghz Wifi Antennas - Canada

    AP placement is outdoors. This information can be found in the Enterprise Wireless LAN Antenna Specification Guide located at http://www.extremenetworks.com/support/ documentation/. An AP-8533 external antenna Access Point supports the following dual band antenna options: 2.4 GHZ 5 GHZ Antenna...

  • Page 9: Dual Band 2.4 Ghz / 5 Ghz Wifi Antennas - Emea

    AP placement is outdoors. This information can be found in the Enterprise Wireless LAN Antenna Specification Guide located at http://www.extremenetworks.com/support/ documentation/. An AP-8533 external antenna Access Point supports the following dual band antenna options: 2.4 GHZ 5 GHZ Antenna...
  • Page 10 Introduction AP-8533 Access Point Installation Guide...

  • Page 11: Hardware Installation

    Hardware Installation Installation Instructions An AP-8533 Access Point mounts either on a wall (with M 3.5 x 0.6 x 23 MM pan head screws and mounting bracket or equivalent) or on a suspended ceiling T-bar. To prepare for the installation: 1 Match the part number on the purchase order with the part numbers in the packing list and on the case of the Access Point.

  • Page 12: Access Point Placement

    Access Point. Power Injector System An AP-8533 Access Point can receive power via an Ethernet cable connected to the GE1/ POE (LAN) port. When users purchase a WLAN solution, they often need to place Access Points in obscure locations.
  • Page 13 However, using the wrong solution (including a POE system used on a legacy Access Point) could either limit functionality or severely damage the Access Point and void the product warranty. A separate Power Injector is required for each AP-8533 Access Point comprising the network. AP-8533 Access Point Installation Guide...
  • Page 14 Hardware Installation Table 1: AP-8533 Power Management AP-8533 Radio 1 Radio 2 Radio 3 The Power Injector can be installed free standing, on an even horizontal surface or wall mounted using the Power Injector's wall mounting key holes. The following guidelines should be adhered to before cabling the Power Injector to an Ethernet source and an Access Point: •...

  • Page 15: Wall Mount Instructions

    Wall Mount Instructions A wall mount deployment requires hanging the AP-8533 with the provided mounting bracket and two screws. The AP-8533 can be mounted on to any plaster, wood or cement wall surface using the provided mounting bracket. The hardware required to install the AP-8533 on a wall consists of: •...
  • Page 16 Attach the power supply line cord to a power supply. 6 Verify the Access Point is receiving power by observing the LEDs are lit or flashing. For more information on AP-8533 LED behavior, see LED Indicators on page 19.

  • Page 17: Suspended Ceiling T-Bar Mount Instructions

    Ceiling mount requires holding the AP-8533 up against the T-bar of a suspended ceiling grid and twisting the unit on to the T-bar. If deploying the AP-8533 on a sculpted ceiling T- Bar, the Access Point mounting kit (Part No. KT-135628-01) can optionally be used as well.
  • Page 18 Access Point. 2 Cable the Access Point using either the Power Injector solution (AP-PSBIAS-2P3-ATR) or the approved AP-8533 power supply (PWR-BGA48V45W0WW). For Power Injector installations: a Connect a RJ-45 CAT5e (or CAT6) Ethernet cable between the network data supply (host) and the Power Injector Data In connector.
  • Page 19 Access Point and void the product warranty. Do not actually connect to the power source until the cabling portion of the installation is complete. 3 Verify the unit has power by observing the LEDs. For more information on AP-8533 LED behavior, see LED Indicators on page 19.
  • Page 20 Hardware Installation 8 Rotate the Access Point chassis 45 degrees counter-clockwise. The clips click as they fasten to the T-bar. The Access Point is ready to configure. AP-8533 Access Point Installation Guide...

  • Page 21: Led Indicators

    Hardware Installation LED Indicators The AP-8533 LED activity indicators are located on the front of the housing and are visible through the enclosure. AP-8533 Access Point Installation Guide...
  • Page 22 Sensor without connected Sensor with connected Blinking 0.5 Termination second in 1 state second duty cycle BT radio disabled BT radio enabled (operational) AP-8533 Access Point Installation Guide...

  • Page 23: Basic Access Point Configuration

    Basic Access Point Configuration Once the AP-8533 is installed and powered on, complete the following steps to get the Access Point up and running and access management functions: 1 The Access Point’s IP address is optimally provided using DHCP. A zero config IP address can also be derived if DHCP resources are unavailable.
  • Page 24 The first page of the Initial Setup Wizard displays the Navigation Panel and Function Highlights for the configuration activities comprising the Access Point's initial setup. This page also displays options to select the typical or advanced mode for the wizard. AP-8533 Access Point Installation Guide...
  • Page 25 8 The Typical Setup Wizard displays the Access Point Settings screen to define the Access Point's Standalone versus Virtual Controller AP functionality. This screen also enables selection of the country of operation for the Access Point. AP-8533 Access Point Installation Guide...
  • Page 26 Access Point, as it defines the correct channels of operation and ensures compliance to the regulations of the selected country. This field is only available for the Typical Setup Wizard. AP-8533 Access Point Installation Guide...
  • Page 27 When Bridge Mode is selected, WAN configuration cannot be performed and the Typical Setup Wizard does not display the WAN configuration screen. 14 Select Next. The Typical Setup Wizard displays the LAN Configuration screen to set the Access Point's LAN interface configuration. AP-8533 Access Point Installation Guide...
  • Page 28 • Secondary DNS - Enter an IP Address for the backup Domain Name Server providing DNS services for the Access Point's LAN interface. 16 Select Next . The Typical Setup Wizard displays the Wireless LAN Setup screen to set the an Access Point's WLAN 1 and WLAN 2 configuration. AP-8533 Access Point Installation Guide...
  • Page 29 Access Point and requesting clients. 18 Select Next . The Typical Setup Wizard displays the RADIUS Server Configuration screen if required. Otherwise, the Typical Setup Wizard displays the Summary and Commit screen. AP-8533 Access Point Installation Guide...
  • Page 30 • Password - Provide a password to authenticate the user. • Confirm Password - Confirm the password by entering the same password entered in the Password field. • Description - Provide a description to identify the user created in the RADIUS server database. AP-8533 Access Point Installation Guide...
  • Page 31 No user intervention or additional settings are required. Its an additional means of validating the Access Point’s updated configuration before it’s deployed. However, if a screen displays settings not intended as part of the initial configuration, then any screen AP-8533 Access Point Installation Guide...
  • Page 32 Access Point’s configuration. If additional changes are warranted based on the summary, either select the target page from the Navigational Panel, or use the Back and Next buttons to scroll to the target screen. AP-8533 Access Point Installation Guide...

  • Page 33: Ap-8533 Access Point Specifications

    AP-8533 Access Point Specifications Electrical Characteristics An AP-8533 Access Point has the following electrical characteristics: Operating 48VDC, 0.5A (AUX input voltage) Current & 48VDC PWR-BGA48V45W0WW Power Supply Voltage 48VDC, 0.5A (POE) 802.3at AP-PSBIAS-2P3-ATR Power Injector Physical Characteristics An AP-8533 Access Point has the following physical characteristics: Dimensions 8.25 in.

  • Page 34: Radio Characteristics

    AP-8533 Access Point Specifications Radio Characteristics The AP-8533 Access Point has the following radio characteristics: Data Rates 802.11b/g: 1,2,5.5,11,6,9,12,18,24,36,48 and 54 Mbps Supported 802.11a: 6,9,12,18,24,36,48, and 54 Mbps 802.11n: MCS 0-31 up to 600Mbps 802.11ac: MCS 0-9 up to 1.733Gbps...

  • Page 35: Regulatory Information

    Regulatory Information This guide applies to the following Model Numbers: AP-8533, AP-8533I. All Extreme Networks devices are designed to be compliant with the rules and regulations in the locations they are sold and will be labeled as required. Any changes or modifications to Extreme equipment, not expressly approved by Extreme Networks could void the user's authority to operate the equipment.

  • Page 36: Country Selection

    High power radars are allocated as primary users (meaning they have priority) of 5250-5350 MHz and 5650-5850 MHz and these radars could cause interference and/or damage to LE-LAN devices. AP-8533 Access Point Installation Guide...

  • Page 37: Warnings For Use Of Wireless Devices

    Wireless devices transmit radio frequency energy and may affect medical electrical equipment. When installed adjacent to other equipment, it is advised to verify that the adjacent equipment is not adversely affected. Wireless devices transmit radio frequency energy and may affect medical electrical equipment. AP-8533 Access Point Installation Guide...

  • Page 38: Rf Exposure Guidelines

    To comply with EU RF exposure requirements, antennas that are mounted externally at remote locations or operating near users at stand-alone desktop of similar configurations must operate with a minimum separation distance of 40 cm from all persons. AP-8533 Access Point Installation Guide...

  • Page 39: Us And Canada

    EN 60950-1, LPS/SELV) power supply with electrical ratings: Output 48 Vdc, min 0.75 A or 55 Vdc min 0.6 A, with a recommended ambient temperature greater than X degrees C. Use of alternative power supply will invalidate any approvals given to this unit and may be dangerous. AP-8533 Access Point Installation Guide...

  • Page 40: Radio Frequency Interference Requirements-Fcc

    (1) Ce dispositif ne peut causer des interférences; et (2) Cet appareil doit accepter toute interférence, y compris les interférences qui peuvent causer un mauvais fonctionnement de l'appareil. AP-8533 Access Point Installation Guide...

  • Page 41: Ce Marking And European Economic Area (Eea)

    This radio transmitter (AP-8533I and AP-8533) has been approved by Industry Canada to operate with the antenna types listed below and having a maximum gain allowable and the impedance required for each type of antenna.

  • Page 42: Statement Of Compliance

    Regulatory declarations for AP-8533I, AP-8533 - BRAZIL For more information consult the website www.anatel.gov.br. Nota: A marca de certificação se aplica ao Transceptor, modelo AP-8533. Este equipamento opera em caráter secundário, isto é, não tem direito a proteção contra interferência prejudicial, mesmo de estações do mesmo tipo, e não pode causar interferência a sistemas operando em caráter primário.

  • Page 43: Chile

    (2) este equipo o dispositivo debe aceptar cualquier interferencia, incluyendo la que pueda causar su operación no deseada. S. Korea For a radio equipment using 2400~2483.5MHz or 5725~5825MHz, the following two expression should be displayed; AP-8533 Access Point Installation Guide...

  • Page 44: Taiwan

    Bu cihaz Türkçe karakterlerin tamam?n? ihtiva eden ETSI TS 123.038 V8.0.0 (veya sonraki sürümün kodu) ve ETSI TS 123.040 V8.1.0 (veya sonraki sürümün kodu) teknik özelliklerine uygundur. Ukraine Thailand Eurasian Customs Union Waste Electrical and Electronic Equipment (WEEE) AP-8533 Access Point Installation Guide...

  • Page 45: Turkish Weee Statement Of Compliance

    4 It is the users’ responsibility to utilize the available collection system to ensure WEEE is properly treated. For information about the available collection system, please contact Extreme Customer Support at +353 61 705500 (Ireland). TURKISH WEEE Statement of Compliance EEE Yönetmeliğine Uygundur AP-8533 Access Point Installation Guide...

  • Page 46: Support

    If you purchased your product from a business partner, contact that business partner for support. Customer Support Web Sites The Support site, located at http://www.extremenetworks.com/support/, provides information and online assistance including developer tools, software downloads, product manuals and online repair requests. Manuals http://www.extremenetworks.com/support/documentation/ AP-8533 Access Point Installation Guide...
  • Page 47 3 GRANT OF LICENSE. Extreme will grant You a non-transferable, non-sublicensable, nonexclusive license to use the Licensed Materials and the accompanying documentation for your own business purposes subject to the terms and conditions of this Agreement AP-8533 Access Point Installation Guide...
  • Page 48 Licensed Materials and the associated usage to Extreme. This is to verify the Licensed Materials are being used in accordance with a valid license and/or entitlement. By using the Licensed Materials, you consent to the transmission of this information. AP-8533 Access Point Installation Guide...

  • Page 49: End-User Software License Agreement

    Extreme’ prior written approval, and shall return such information and data to Extreme at its request. Nothing herein shall limit your use or dissemination of information AP-8533 Access Point Installation Guide...
  • Page 50 You agree not to directly or indirectly export, import or transmit the Licensed Materials, including the Licensed Software to any country, end user or for any Use that is prohibited by applicable United States regulation or statute (including but not limited to AP-8533 Access Point Installation Guide...
  • Page 51 (an Open Source License). Your use, modification and redistribution of the Open Source Software are governed by the terms and conditions of the applicable Open Source License. More details regarding the Open AP-8533 Access Point Installation Guide...
  • Page 52 Any notice or other communication to be sent to Extreme must be mailed by certified mail to the following address: Extreme Networks, Inc. 6480 Via Del Oro San Jose, CA 95119, USA Tel: +1 408-579-2800 Toll-free: +1 888-257-3000 AP-8533 Access Point Installation Guide...

  • Page 53: Ap-8533 Access Point China Rohs Compliance

    (PBB) (PBDE) (Metal Parts) (Circuit Modules) (Cables and Cable Assemblies) (Plastic and Polymeric Parts) (Optics and Optical Components) (Batteries) This table was created to comply with China RoHS requirements for AP-8533 and AP-8533I Access Points. AP-8533 Access Point Installation Guide...
