SPLIT-TYPE,HEAT PUMP AIR CONDITIONERS

TECHNICAL & SERVICE MANUAL

Wall Mounted

Series PKFY

PKFY-20VAM

Models

PKFY-25VAM

INDOOR UNIT

CONTENTS

1. PART NAMES AND FUNCTIONS ········2

2. SPECIFICATION ···································4

3. OUTLINES AND DIMENSIONS············6

4. WIRING DIAGRAM·······························7

5. REFRIGERANT SYSTEM DIAGRAM ··8

6. TROUBLESHOOTING ··························9

7. DISASSEMBLY PROCEDURE···········14

MODEL NAME

8. PARTS LIST········································17

1997

No. OC112

Need help?

Do you have a question about the PKFY-20VAM and is the answer not in the manual?

Questions and answers

Summary of Contents for Mitsubishi Electric PKFY-20VAM

Page 1: Table Of Contents
1997 SPLIT-TYPE,HEAT PUMP AIR CONDITIONERS No. OC112 TECHNICAL & SERVICE MANUAL Wall Mounted Series PKFY <Indoor unit> PKFY-20VAM Models PKFY-25VAM CONTENTS 1. PART NAMES AND FUNCTIONS ········2 2. SPECIFICATION ···································4 3. OUTLINES AND DIMENSIONS············6 4. WIRING DIAGRAM·······························7 5. REFRIGERANT SYSTEM DIAGRAM ··8 INDOOR UNIT 6.
