SPLIT-TYPE, HEAT PUMP AIR CONDITIONERS
TECHNICAL & SERVICE MANUAL
Wall Mounted
Series PKFY
Indoor unit
[Model names]
PKFY-P20VAM-A
PKFY-P25VAM-A
INDOOR UNIT
All manuals and user guides at all-guides.com
R407C
[Service Ref.]
PKFY-P20VAM-A
PKFY-P25VAM-A
2001
R22
CONTENTS
1. SAFETY PRECAUTION ·····················3
3. SPECIFICATION·································7
4. OUTLINES AND DIMENSIONS ·········9
5. WIRING DIAGRAM···························10
7. TROUBLESHOOTING······················12
8. DISASSEMBLY PROCEDURE·········17
9. PARTS LIST ·····································20
No. OC254

Advertisement

Table of Contents
loading

Summary of Contents for Mitsubishi Electric PKFY Series

  • Page 1: Table Of Contents

    All manuals and user guides at all-guides.com 2001 SPLIT-TYPE, HEAT PUMP AIR CONDITIONERS No. OC254 TECHNICAL & SERVICE MANUAL Wall Mounted Series PKFY R407C Indoor unit [Model names] [Service Ref.] PKFY-P20VAM-A PKFY-P20VAM-A PKFY-P25VAM-A PKFY-P25VAM-A CONTENTS 1. SAFETY PRECAUTION ·····················3 2. PART NAMES AND FUNCTIONS······5 3.
  • Page 2 All manuals and user guides at all-guides.com...
  • Page 3: Safety Precaution

    All manuals and user guides at all-guides.com SAFETY PRECAUTION Cautions for using with the outdoor unit which adopts R407C refrigerant. · Do not use the existing refrigerant piping. -The old refrigerant and lubricant in the existing piping contains a large amount of chlorine which may cause the lubricant deterioration of the new unit.
  • Page 4 All manuals and user guides at all-guides.com [1] Service tools Use the below service tools as exclusive tools for R407C refrigerant. Tool name Specifications Gauge manifold ·Only for R407C. ·Use the existing fitting SPECIFICATIONS. (UNF7/16) ·Use high-tension side pressure of 3.43MPa·G or over. Charge hose ·Only for R407C.
  • Page 5: Part Names And Functions

    All manuals and user guides at all-guides.com PART NAMES AND FUNCTIONS Indoor Unit PKFY-P20VAM-A PKFY-P25VAM-A Air intake Air intake grille Filter Auto Vane Guide vane Air Outlet MA remote controller [PAR-20MAA] Once the operation of the unit is set, subsequent operations can only be performed by pressing the ON/OFF button repeatedly.
  • Page 6 All manuals and user guides at all-guides.com Display In this display example on the bot- CENTRALLY CLOCK display tom left, a condition where all dis- CONTROLLED display play lamps light is shown for expla- The current time , start time and stop time can be displayed in ten second nation purposes although this differs This indicates when the unit is con-...
  • Page 7: Specification

    All manuals and user guides at all-guides.com SPECIFICATION 3-1. Specification Item Unit PKFY-P20VAM-A PKFY-P25VAM-A Single phase, 220-230-240V, 50Hz [,V,Hz Power Single phase, 220V, 60Hz Cooling capacity Heating capacity Cooling 0.04 Power Supply Heating 0.04 Cooling 0.20 Starting Current Heating 0.20 Exterior <munsell symbol>...
  • Page 8 All manuals and user guides at all-guides.com 3-2. Electrical parts specifications Model Symbol PKFY-P20VAM-A PKFY-P25VAM-A Parts name Room temperature TH21 Resistance 0:/15k", 10:/9.6k", 20:/6.3k", 25:/5.2k", 30:/4.3k", 40:/3.0k" thermistor Liquid pipe thermistor TH22 Resistance 0:/15k", 10:/9.6k", 20:/6.3k", 25:/5.2k", 30:/4.3k", 40:/3.0k" Gas pipe thermistor TH23 Resistance 0:/15k", 10:/9.6k", 20:/6.3k", 25:/5.2k", 30:/4.3k", 40:/3.0k"...
  • Page 9: Outlines And Dimensions

    All manuals and user guides at all-guides.com OUTLINES AND DIMENSIONS PKFY-P20VAM-A Unit : mm PKFY-P25VAM-A...
  • Page 10: Wiring Diagram

    All manuals and user guides at all-guides.com WIRING DIAGRAM PKFY-P20VAM-A PKFY-P25VAM-A Legend Symbol Name Symbol Name Symbol Name Indoor controller board TH23 Thermistor Pipe temperature,detection/Gas Terminal Power supply Remote switch (0:/15T,25:/5.4T) Transmission CN32 Connector block CN41 HA terminal-A Indoor power board Circuit board Address board CN51...
  • Page 11: Refrigerant System Diagram

    All manuals and user guides at all-guides.com REFRIGERANT SYSTEM DIAGRAM PKFY-P20VAM-A PKFY-P25VAM-A Gas pipe temperature thermistor TH23 Gas pipe Flare Strainer (#50mesh) Liquid pipe temperature thermistor TH22 Liquid pipe Heat exchanger Linear expansion valve Strainer (#100mesh) Room temperature thermistor TH21 Models PKFY-P20VAM-A, PKFY-P25VAM-A Item...
  • Page 12: Troubleshooting

    All manuals and user guides at all-guides.com TROUBLESHOOTING 7-1. How to check PKFY-P20VAM-A, PKFY-P25VAM-A Part Name Check points Room temperature Disconnect the connector, then measure the resistance using a tester. thermistor(TH21) (Surrounding temperature 10°C~30°C) Liquid pipe temperature thermistor(TH22) Normal Abnormal (Refer to the next page for a detail.) Gas pipe temperature 4.3k...
  • Page 13 All manuals and user guides at all-guides.com <Thermistor Characteristic graph> < Thermistor for lower temperature > Room temperature thermistor(TH21) Thermistor for Liquid pipe temperature thermistor(TH22) lower temperature Gas pipe temperature thermistor(TH23) Thermistor R =15k' ± 3% Fixed number of B=3480k' ± 2% Rt=15exp { 3480( 273+t 15k'...
  • Page 14 All manuals and user guides at all-guides.com <Output pulse signal and the valve operation> Output Output (Phase) Closing a valve : 1 Opening a valve : 4 The output pulse shift in above order. 1. When linear expansion valve operation stops, all output phase become OFF.
  • Page 15 All manuals and user guides at all-guides.com 7-2. FUNCTION OF DIP SWITCH PKFY-P20VAM-A, PKFY-P25VAM-A Operation by switch Switch Pole Function Remarks Thermistor<Intake temperature> Indoor unit Built-in remote controller Address board position Filter clogging Provide Not provide <At delivery> Filter sign indication 2,500 hr 100 hr 1 2 3 4 5 6 7 8 9 10...
  • Page 16 All manuals and user guides at all-guides.com Switch Operation by switch Remarks Address board SW11 1st digit Address can be set while the address unit is stopped. SW12 SW11 setting Address setting should be done when M-NET <At delivery> SW12 remote controller is being used.
  • Page 17: Disassembly Procedure

    All manuals and user guides at all-guides.com DISASSEMBLY PROCEDURE PKFY-P25VAM-A Be careful on removing heavy parts. OPERATION PROCEDURE PHOTOS & ILLUSTRATIONS 1. REMOVING THE LOWER SIDE OF THE INDOOR UNIT FROM Figure 1 Figure 2 THE INSTALLATION PLATE When there is removing plate (1) Remove the corner box at right lower side of the indoor unit.
  • Page 18 All manuals and user guides at all-guides.com OPERATION PROCEDURE PHOTOS & ILLUSTRATIONS 3. REMOVING THE INDOOR MICRO CONTROLLER BOARD Electrical box cover Photo 2 AND INDOOR POWER BOARD (1) Remove the front panel. (Refer to 2) (2) Remove the electrical box cover (screw 4 10).
  • Page 19 All manuals and user guides at all-guides.com OPERATION PROCEDURE PHOTOS & ILLUSTRATIONS 5. REMOVING THE NOZZLE ASSEMBLY Photo 5 (1) Remove the front panel (Refer to 2). Heat exchanger Electrical box (2) Remove the electrical box cover. (3) Disconnect the connector (CN5V) on the indoor micro con Drain hose troller board.
  • Page 20: Parts List

    All manuals and user guides at all-guides.com PARTS LIST PANEL PARTS PKFY-P20VAM-A PKFY-P25VAM-A Part number that is circled is not shown in the figure. Q'ty / set Price Wiring Recom- Remarks No. Parts No. Parts Name Specifications PKFY-P20VAM-A Diagram mended Unit Amount (Drawing No.) Symbol...
  • Page 21 All manuals and user guides at all-guides.com ELECTRICAL PARTS PKFY-P20VAM-A, PKFY-P25VAM-A CENTRALLY CONTROLLED 1Hr. ON OFF ˚C CHECK CLOCK FILTER CHECK MODE ˚C TEST RUN STAND BY ERROR CODE FUNCTION DEFROST NOT AVAILABLE TEMP. ON/OFF FILTER CHECK TEST PAR-20MAA TIMER SET 12 13 Q'ty / set Price...
  • Page 22 All manuals and user guides at all-guides.com HEAT EXCHANGER PARTS PKFY-P20VAM-A PKFY-P25VAM-A Q'ty / set Price Wiring Recom- Remarks No. Parts No. Parts Name Specifications PKFY- PKFY- Diagram mended Unit Amount (Drawing No.) P20VAM-A P25VAM-A Symbol Q'ty T7W E83 480 HEAT EXCHANGER With connection pipe T7W E84 480...
  • Page 23 All manuals and user guides at all-guides.com...
  • Page 24 All manuals and user guides at all-guides.com HEAD OFFICE : MITSUBISHI DENKI BLDG., 2-2-3, MARUNOUCHI, CHIYODA-KU TOKYO 100-8310, JAPAN cCopyright 2001 MITSUBISHI ELECTRIC ENGINEERING CO., LTD. New publication, effective Feb. 2001 Distributed in Feb. 2001. No. OC254 785 Specifications subject to change without notice...

This manual is also suitable for:

Pkfy-p20vam-aPkfy-p25vam-a
