Ventilator Sizing
Tables 1 and 2 should be used to determine the required airflow for a home. These guidelines are taken from ASHRAE 62.2- -2007.
Table 1 – Ventilation Air Requirements, cfm
FLOOR
2
AREA (ft
)
0---1
2---3
<1500
30
45
1501--- 3000
45
60
3001--- 4500
60
75
4501--- 6000
75
90
6001--- 7500
90
105
>7500
105
120
Although the ventilators process the outside air before it enters the home, additional heating and cooling loads need to be considered.
HEATING LOAD BTUH
Heating Load (Btuh) @
Outside
Inside Design Temp 72°F
Temp °F
ERV1150
ERV1200
–25
5186
8143
–20
4919
7723
–15
5075
7967
–10
4783
7509
–5
4491
7051
0
4200
6594
5
4234
6647
10
3918
6151
15
3958
6214
20
3611
5669
25
3264
5124
30
2916
4579
35
2569
4034
40
2222
3489
The heating load chart shows the heating loads in Btuh for a range
of winter design temperatures for each model of ventilator.
EXAMPLE: The heating design temperature for Little Rock, AR is
20_F. The additional heating load of the ERVBBLHA1200 at
20_F is 559 Btuh. This additional load should be taken into
consideration when sizing the heating equipment.
METHOD TO SIZE ERVs and HRVs
BEDROOMS
4---5
6---7
>7
60
75
90
75
90
105
90
105
120
105
120
135
120
135
150
135
150
165
HEATING AND COOLING LOAD CHARTS
HRV1150
HRV1250
6636
10603
6294
10057
5952
9510
5610
8964
5268
8417
4925
7871
4583
7324
4241
6777
3899
6231
3557
5684
3215
5138
2873
4591
2531
4045
2189
3498
Table 2 – Ventilation Air Requirements, L/s
FLOOR
2
AREA (m
)
0---1
2---3
<139
14
21
139.1--- 279
21
28
279.1--- 418
28
35
418.1--- 557
35
42
557.1--- 697
42
50
>697
50
57
COOLING LOAD BTUH
Cooling Load (Btuh) @ Inside Design Temp
Outside
72°F and 50% Relative Humidity
Enthalpy
Btu/lb
ERV1150
ERV1200
30
380
31
618
1040
32
855
1441
33
1093
1841
34
1331
2241
35
1568
2641
36
1806
3041
37
2043
3441
38
2281
3842
39
2519
4242
40
2756
4642
41
2994
5042
42
3231
5442
The cooling load chart shows loads in Btuh as well. To use the
cooling load chart, first find the design enthalpy from a
psychrometric chart using the design dry bulb and wet bulb
temperatures. The cooling load can then be found for a range of
enthalpies for each ventilator.
EXAMPLE: The design dry bulb temperature for Miami is 90_F
and the average wet bulb at that temperature is 77_F. Using the
psychrometric chart, the enthalpy is about 40.5 Btu per pound
(Btu/lb) of dry air, which would round up to 41 Btu/lb dry air. In
the left column, at 41 Btu/lb dry air, the ERVBBLHA1200 has an
additional cooling load of 5042 Btuh, while the HRV1150CFM
unit has an additional cooling load of 8437 Btuh.
6
BEDROOMS
4---5
6---7
>7
28
35
42
35
42
50
42
50
57
50
57
64
57
64
71
64
71
78
HRV1150
HRV1250
640
670
1071
1090
1741
1509
2411
1928
3080
2347
3750
2766
4419
3185
5089
3604
5759
4023
6428
4442
7098
4861
7767
5280
8437
5699
9107
