Split type air conditioner indoor unit/outdoor unit

Advertisement

Table of Contents

NAMES AND FUNCTIONS OF EACH PART

INDOOR UNIT

OUTDOOR UNIT

MODEL NAME AND DIMENSIONS
MODEL
RAS-S18CAK
RAC-S18CAK
Pre-À lter
To prevent dust from coming into the indoor unit.
(Refer page 17)
Front panel
Indoor unit indicators
Light indicator showing the operating condition.
(Refer page 5)
Horizontal deÁ ector
(Air Outlet)
(Refer page 12)
Remote controller
Send out operation signal to the indoor unit. So as
to operate the whole unit.
(Refer page 6)
Drain pipe
Condensed water drain to outside.
Connecting cord and insulation pipe for piping
Air inlet (Back and Left side)
Air outlet
WIDTH (mm)
HEIGHT (mm)
1030
850
– 4 –
Vertical deÁ ector
DEPTH (mm)
207
295
298
650
