HUSTLER 933945CE Parts Manual
  1. Manuals
  2. Brands
  3. HUSTLER Manuals
  4. Lawn Mower
  5. 933945CE
  6. Parts manual
HUSTLER 933945CE Parts Manual

HUSTLER 933945CE Parts Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Hustler
Parts Manual
®
®
200 South Ridge Road
Hesston, Kansas
67062

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 933945CE and is the answer not in the manual?

Questions and answers

Related Manuals for HUSTLER 933945CE

Summary of Contents for HUSTLER 933945CE

  • Page 1 Hustler Parts Manual ® ® 200 South Ridge Road Hesston, Kansas 67062...
  • Page 2 WARNING The engine exhaust from this product contains chemicals known to the state of California to cause cancer, birth defects or other reproductive harm. NOTICE OF REQUIREMENT OF SPARK ARRESTER MUFFLER This equipment may create sparks that can start fires around dry vegetation. California Public Resources Code Section 4442.6 provides that it is unlawful to use or operate an internal combustion engine on any forest-covered, brush-covered, or grass-covered land unless the engine is equipped with a spark arrester maintained in effective working order.

  • Page 3: Table Of Contents

    General Information Frame & Engine Guard Frame Engine Guard & Hitch Transmissions & Steering Transmission Assembly & Drive Belt Transmission Service Parts Steering & Brake (Multi-Page) Steering Assembly Steering Box Assembly Breakdown Wheels & Tires Wheel & Tire - 48" Mowers Front Tire Breakdown - 13 X 5 Tire - 48"...

  • Page 5: General Information

    Use of this manual in conjunction with other Hustler ® mower and component manuals will provide the information necessary to service and maintain Hustler mowers. This Parts Manual provides a complete parts listing for the unit. Use this manual when ordering parts. Illustrations used were current at the time of printing, but subsequent production changes may cause your machine to vary slightly in detail.
  • Page 6 The following codes are used throughout this parts manual. Refer to this list when ordering parts. ABBREVIATION DESCRIPTION ABBREVIATION DESCRIPTION CARRIAGE BOLT MACHINE BUSHING CLEVIS PIN MACHINE SCREW CLIP NUT COTTER PIN SELF TAPPING CAP SCREW CAP SCREW SOCKET HEAD CUP WASHER SHOULDER BOLT FDRW...

  • Page 7: Frame & Engine Guard

    Frame Hustler FasTrak SDX CE Parts Manual Frame & Engine Guard Thu Feb 18 06:50:49 UTC 2021...

  • Page 8: Frame

    Frame Hustler FasTrak SDX CE Parts Manual Item Part No. Name 553087 48 FRAME CE - SVC Not Shown 553088 54/60 FRAME CE - SVC 808493 RIVET NUT, 3/8-16 THREA SERIAL NUMBER / SPEC DECAL 776310 DECAL, CE MARK 789776CE...
  • Page 9 Engine Guard & Hitch Hustler FasTrak SDX CE Parts Manual Frame & Engine Guard Thu Feb 18 06:50:50 UTC 2021...

  • Page 10: Engine Guard & Hitch

    Engine Guard & Hitch Hustler FasTrak SDX CE Parts Manual Item Part No. Name 119977 HITCH PLATE 025395 CB .375-16X 1.00 G5 ZN 054502 NT .375-16HXG5 767954 FW 0.379X.82X.06 HD ZN 121134 GUARD, RH 553123 SVC PART, STAMPED BUMPER 604770 DECAL, "H"...

  • Page 11: Transmissions & Steering

    Transmission Assembly & Drive Belt Hustler FasTrak SDX CE Parts Manual Transmissions & Steering Thu Feb 18 06:50:51 UTC 2021...

  • Page 12: Transmission Assembly & Drive Belt

    Transmission Assembly & Drive Belt Hustler FasTrak SDX CE Parts Manual Item Part No. Name 710087 CS .312-18X2.500HXG5 768523 FW 0.343SAE 043067 CS .312-18X3.000HXG5 704791 FW .781X1.25X.02 ZN 781153 BUSHING, UHMW 605468 DRIVE BELT 025007 CS .62511X1.750HXG5 607525 PULLEY, IDLER...
  • Page 13 Transmission Assembly & Drive Belt Hustler FasTrak SDX CE Parts Manual 4. Left side transmission. 5. Right side transmission. 6. Reservoir (605217) includes the cap (600767). Thu Feb 18 06:50:51 UTC 2021...
  • Page 14 Transmission Service Parts Hustler FasTrak SDX CE Parts Manual This page intentionally left blank Thu Feb 18 06:50:51 UTC 2021...
  • Page 15 Transmission Service Parts Hustler FasTrak SDX CE Parts Manual Transmissions & Steering Thu Feb 18 06:50:51 UTC 2021...

  • Page 16: Transmission Service Parts

    Transmission Service Parts Hustler FasTrak SDX CE Parts Manual Item Part No. Name 603866 FAN/PULLEY KIT 607728 FAN - 7.0" (10 BLADE) 605608 FITTING, TRANSMISSION 605778 RTN, LEFT Not Shown 605779 RTN, RIGHT 604903 HG RTN SPRING 600976 HYDRAULIC OIL FILTER...
  • Page 17 Steering & Brake (Multi-Page) Hustler FasTrak SDX CE Parts Manual Transmissions & Steering Thu Feb 18 06:50:52 UTC 2021...

  • Page 18: Steering & Brake (Multi-Page)

    Steering & Brake (Multi-Page) Hustler FasTrak SDX CE Parts Manual Item Part No. Name 605383 STEERING BAR W/A, RH Not Shown 781260 GRIP, STEERING BAR 605384 STEERING BAR W/A, LH Not Shown 781260 GRIP, STEERING BAR 767954 FW 0.379X.82X.06 HD ZN 036244 CS .375-16X1.00 HX G5 ZN...
  • Page 19 Steering & Brake (Multi-Page) Hustler FasTrak SDX CE Parts Manual Thu Feb 18 06:50:52 UTC 2021...
  • Page 20 Steering & Brake (Multi-Page) Hustler FasTrak SDX CE Parts Manual Comments for Page: Steering & Brake (Multi-Page) 1. The steering bars include the grips.2. Part of the transmission. Thu Feb 18 06:50:52 UTC 2021...
  • Page 21 Steering Assembly Hustler FasTrak SDX CE Parts Manual Transmissions & Steering Thu Feb 18 06:50:53 UTC 2021...

  • Page 22: Steering Assembly

    Steering Assembly Hustler FasTrak SDX CE Parts Manual Item Part No. Name 064345 CS .312-18X2.000HXG5 768523 FW 0.343SAE 086660 NT .375-16NLG8 767954 FW 0.379X.82X.06 HD ZN 785220 DECAL, STEERING R.S. 042630 CS .500-13X6.500HXG5 704759 FW 0.500X1.25X.08 ZN 119811 SPACER, STEERING...
  • Page 23 Steering Box Assembly Breakdown Hustler FasTrak SDX CE Parts Manual Transmissions & Steering Thu Feb 18 06:50:53 UTC 2021...

  • Page 24: Steering Box Assembly Breakdown

    Steering Box Assembly Breakdown Hustler FasTrak SDX CE Parts Manual Item Part No. Name 119807 STEER LEVER W/A 119750 STEER PIVOT W/A, RS Not Shown 119749 STEER PIVOT W/A, LS 086660 NT .375-16NLG8 767954 FW 0.379X.82X.06 HD ZN 781153 BUSHING, UHMW 705178 CS .375-16X1.750HXG5...

  • Page 25: Wheels & Tires

    Wheel & Tire - 48" Mowers Hustler FasTrak SDX CE Parts Manual Wheels & Tires Thu Feb 18 06:50:54 UTC 2021...

  • Page 26: Wheel & Tire - 48" Mowers

    Wheel & Tire - 48" Mowers Hustler FasTrak SDX CE Parts Manual Item Part No. Name 605484 TIR/WHL 22X9.50-10 SLV 061077 WHEEL NUT 111875-3 BACKUP PLATE, WHEEL 705954 CS .500-13X1.25 HX G5 ZN 344267 FW .510X2.15X.19 ZN 712976 FW 0.531X1.38X.12 ZN...
  • Page 27 Front Tire Breakdown - 13 X 5 Tire - 48" Mowers Hustler FasTrak SDX CE Parts Manual Wheels & Tires Thu Feb 18 06:50:55 UTC 2021...

  • Page 28: Front Tire Breakdown - 13 X 5 Tire - 48" Mowers

    Front Tire Breakdown - 13 X 5 Tire - 48" Mowers Hustler FasTrak SDX CE Parts Manual Item Part No. Name 366625 FORK W/A 061101 NT .750-10 HX ZN NL GR B 025296 FW .760X1.63X0.08 ZN 786731 CS .750-10X8.000HXG5 605038 TIR/WHL 13X5.00-6 SLV...
  • Page 29 Wheel & Tire - 54" & 60" Mowers Hustler FasTrak SDX CE Parts Manual Wheels & Tires Thu Feb 18 06:50:55 UTC 2021...

  • Page 30: Wheel & Tire - 54" & 60" Mowers

    Wheel & Tire - 54" & 60" Mowers Hustler FasTrak SDX CE Parts Manual Item Part No. Name 605728 TIR/WHL 23X11.00-10 SLV 061077 WHEEL NUT 111875-3 BACKUP PLATE, WHEEL 705954 CS .500-13X1.25 HX G5 ZN 344267 FW .510X2.15X.19 ZN 712976 FW 0.531X1.38X.12 ZN...
  • Page 31 Front Tire Breakdown - 13 X 6.5 Tire - 54" & 60" Mowers Hustler FasTrak SDX CE Parts Manual Wheels & Tires Thu Feb 18 06:50:56 UTC 2021...

  • Page 32: Front Tire Breakdown - 13 X 6.5 Tire - 54" & 60" Mowers

    Front Tire Breakdown - 13 X 6.5 Tire - 54" & 60" Mowers Hustler FasTrak SDX CE Parts Manual Item Part No. Name 604691 FORK W/A 041475 CS .750-10X9.50 HX G5 ZN 025296 FW .760X1.63X0.08 ZN 061101 NT .750-10 HX ZN NL GR B 605197 TIR/WHL 13X6.50-6 SLV...
  • Page 33 Drive Wheel Breakdown - 20 X 10 Tire - 48" Mowers Hustler FasTrak SDX CE Parts Manual Wheels & Tires Thu Feb 18 06:50:57 UTC 2021...

  • Page 34: Drive Wheel Breakdown - 20 X 10 Tire - 48" Mowers

    Drive Wheel Breakdown - 20 X 10 Tire - 48" Mowers Hustler FasTrak SDX CE Parts Manual Item Part No. Name 605485 TIR 22X9.50-10 B4R LTFT 600700 WHL 10X7.00 4X4.0 SLV 019521 TIRE VALVE TR-412 GOODY Thu Feb 18 06:50:57 UTC 2021...
  • Page 35 Drive Wheel Breakdown - 23 X 11 Tire - 54" & 60" Mowers Hustler FasTrak SDX CE Parts Manual Wheels & Tires Thu Feb 18 06:50:57 UTC 2021...

  • Page 36: Drive Wheel Breakdown - 23 X 11 Tire - 54" & 60" Mowers

    Drive Wheel Breakdown - 23 X 11 Tire - 54" & 60" Mowers Hustler FasTrak SDX CE Parts Manual Item Part No. Name 601347 WHL 10X8.50 4X4.0 SLV 605727 TIR 23X11.00-10 B4R LTFT 019521 TIRE VALVE TR-412 GOODY Thu Feb 18 06:50:57 UTC 2021...

  • Page 37: Engine & Fuel System

    Engine, Muffler & Clutch Hustler FasTrak SDX CE Parts Manual Engine & Fuel System Thu Feb 18 06:50:58 UTC 2021...

  • Page 38: Engine, Muffler & Clutch

    Engine, Muffler & Clutch Hustler FasTrak SDX CE Parts Manual Item Part No. Name KAWASAKI FX691V ENGINE Not Shown KAWASAKI FX730V ENGINE 603524 CS M5-0.8 X 50 MM 604250 MUFFLER 767954 FW 0.379X.82X.06 HD ZN 602580 CS .375-16X1.25HXG8ZYP85 036236 CS .312-18X1.000HXG5 768523 FW 0.343SAE...
  • Page 39 Engine Service Parts Hustler FasTrak SDX CE Parts Manual Engine & Fuel System Thu Feb 18 06:50:59 UTC 2021...

  • Page 40: Engine Service Parts

    Engine Service Parts Hustler FasTrak SDX CE Parts Manual Item Part No. Name 785261 AIR FILTER - MAIN 785279 AIR FILTER - SAFETY 602581 ENGINE OIL FILTER 068478 FUEL FILTER - IN LINE 763318 VALVE, VACUATOR Thu Feb 18 06:50:59 UTC 2021...
  • Page 41 Fuel System (Multi-Page) Hustler FasTrak SDX CE Parts Manual Engine & Fuel System Thu Feb 18 06:51:00 UTC 2021...

  • Page 42: Fuel System (Multi-Page)

    Fuel System (Multi-Page) Hustler FasTrak SDX CE Parts Manual Item Part No. Name 605491 VAPOR LINE, 3/16 FORMED 605493 VAPOR LINE, 3/16 FORMED 605565 BOOT, 3/16 TO 3/16 605690 TEE, 3/16" PLASTIC 605535 VAPOR LINE, 3/16 FORMED 605425 CROSS, 3/16" PLASTIC...
  • Page 43 Fuel System (Multi-Page) Hustler FasTrak SDX CE Parts Manual Thu Feb 18 06:51:00 UTC 2021...
  • Page 44 Fuel System (Multi-Page) Hustler FasTrak SDX CE Parts Manual Item Part No. Name 016832 NT .312-18FLKG5 000430 WIRE TIE, SMALL/LONG Comments for Page: Fuel System (Multi-Page) FUEL & VAPOR LINE LENGTHS A— FRONT RIGHT SIDE PORT TO TEE (VAPOR) B— ENGINE TO CROSS (VAPOR) C—...
  • Page 45 Fuel Tank Service Parts - 606581 Hustler FasTrak SDX CE Parts Manual Engine & Fuel System Thu Feb 18 06:51:01 UTC 2021...

  • Page 46: Fuel Tank Service Parts - 606581

    Fuel Tank Service Parts - 606581 Hustler FasTrak SDX CE Parts Manual Item Part No. Name 605126K SUCTION HOSE SVC KIT 604200K GROMMET SVC KIT 604287K VENT FITTING SVC KIT 605482K FUEL SENDER SVC KIT 605648K TANK GROMMET SVC KIT...

  • Page 47: Electrical, Fenders & Instrument Panel

    Fenders & Battery Hustler FasTrak SDX CE Parts Manual Electrical, Fenders & Instrument Panel Thu Feb 18 06:51:03 UTC 2021...

  • Page 48: Fenders & Battery

    Fenders & Battery Hustler FasTrak SDX CE Parts Manual Item Part No. Name 605558 FENDER LID 605627 CS .250-20 X 1.25 HX 605628 FW 0.281X.63X.07 ZB 601815 DECAL, BATTERY WARNINGS 601982 CN .250-20X .150 MAX THK 552858 BATTERY HOLD DOWN...
  • Page 49 Instrument Panel Hustler FasTrak SDX CE Parts Manual Electrical, Fenders & Instrument Panel Thu Feb 18 06:51:05 UTC 2021...

  • Page 50: Instrument Panel

    Instrument Panel Hustler FasTrak SDX CE Parts Manual Item Part No. Name 786657 CABLE, CHOKE 776476 SWITCH, PTO 6201-321 605483 GAUGE, FUEL/HOURMETER 785808 KEY ASSEMBLY 045898 IGNITION SWITCH 808477 RIVET NUT, 1/4-20 THREA 601098 CB 10-24 X .500 ZYNC 552855...

  • Page 51: Deck

    48" Side Discharge Service Deck Hustler FasTrak SDX CE Parts Manual Deck Thu Feb 18 06:51:06 UTC 2021...

  • Page 52: 48" Side Discharge Service Deck

    48" Side Discharge Service Deck Hustler FasTrak SDX CE Parts Manual Item Part No. Name 552872 48" SERVICE DECK 601837 DECAL, DECK DANGERS 601892 DECAL, THROWN OBJECTS 793976 DECAL,48"DECK ID 781419 DECAL, BELT ROUTING 601624 DECAL, DISCHARGE CHUTE Comments for Page: 48" Side Discharge Service Deck 1.
  • Page 53 48" Side Discharge Deck Pulleys & Spindles Hustler FasTrak SDX CE Parts Manual Deck Thu Feb 18 06:51:08 UTC 2021...

  • Page 54: 48" Side Discharge Deck Pulleys & Spindles

    48" Side Discharge Deck Pulleys & Spindles Hustler FasTrak SDX CE Parts Manual Item Part No. Name 781567 NT .500-13NLG5 604486 FW .531X.812X.089 HD 605467 DUST SHIELD 605512 4" IDLER PULLEY 607616 SPRING, DECK IDLER 121052 SLED, TENSIONER 604790 IDLER SLIDE, EXTRUDED 604251 NT .312-18 HXNL JAM G2ZN...
  • Page 55 48" Side Discharge Deck Hustler FasTrak SDX CE Parts Manual Deck Thu Feb 18 06:51:10 UTC 2021...

  • Page 56: 48" Side Discharge Deck

    48" Side Discharge Deck Hustler FasTrak SDX CE Parts Manual Item Part No. Name 553531 SVC PULLEY COVER, 602562 DECAL, NO SERVICE 604324 CS .250-20 X .75 HX FLG 086660 NT .375-16NLG8 791335 DECK BELT 605469 DISCHARGE CHUTE 602435 SPRING, TORSION...
  • Page 57 48" Side Discharge Deck Hustler FasTrak SDX CE Parts Manual 796623 BLADE, 16.50"-MUL-F-CW 7. The pulley cover includes the decal. Thu Feb 18 06:51:10 UTC 2021...
  • Page 58 48" Rear Discharge Service Deck Hustler FasTrak SDX CE Parts Manual This page intentionally left blank Thu Feb 18 06:51:10 UTC 2021...
  • Page 59 48" Rear Discharge Service Deck Hustler FasTrak SDX CE Parts Manual Deck Thu Feb 18 06:51:10 UTC 2021...

  • Page 60: 48" Rear Discharge Service Deck

    48" Rear Discharge Service Deck Hustler FasTrak SDX CE Parts Manual Item Part No. Name 553017 48" RD SERVICE DECK 601837 DECAL, DECK DANGERS 601892 DECAL, THROWN OBJECTS 793976 DECAL,48"DECK ID 781419 DECAL, BELT ROUTING Comments for Page: 48" Rear Discharge Service Deck 1.
  • Page 61 48" Rear Discharge Deck Pulleys & Spindles Hustler FasTrak SDX CE Parts Manual Deck Thu Feb 18 06:51:11 UTC 2021...

  • Page 62: 48" Rear Discharge Deck Pulleys & Spindles

    48" Rear Discharge Deck Pulleys & Spindles Hustler FasTrak SDX CE Parts Manual Item Part No. Name 781567 NT .500-13NLG5 604486 FW .531X.812X.089 HD 605467 DUST SHIELD 605512 4" IDLER PULLEY 124488-4 BELT GUIDE 607616 SPRING, DECK IDLER 121052 SLED, TENSIONER 604251 NT .312-18 HXNL JAM G2ZN...
  • Page 63 48" Rear Discharge Debris Shield Hustler FasTrak SDX CE Parts Manual Deck Thu Feb 18 06:51:12 UTC 2021...

  • Page 64: 48" Rear Discharge Debris Shield

    48" Rear Discharge Debris Shield Hustler FasTrak SDX CE Parts Manual Item Part No. Name 036236 CS .312-18X1.000HXG5 604252 FW .340X.68X.04 ZN 058776 NT .312-18NLG5 122256 SHIELD, REAR DISCHARGE 122297 BRACKET, SHIELD MOUNT 034280 CS .312-18X0.750HXG5 Comments for Page: 48" Rear Discharge Debris Shield 1.
  • Page 65 48" Rear Discharge Deck Hustler FasTrak SDX CE Parts Manual Deck Thu Feb 18 06:51:13 UTC 2021...

  • Page 66: 48" Rear Discharge Deck

    48" Rear Discharge Deck Hustler FasTrak SDX CE Parts Manual Item Part No. Name 553531 SVC PULLEY COVER, 602562 DECAL, NO SERVICE 604324 CS .250-20 X .75 HX FLG 605507 DECK BELT 781567 NT .500-13NLG5 767962 FW .531 x 1.063 x .175 042630 CS .500-13X6.500HXG5...
  • Page 67 Rear Discharge CE Guard Kit (Multi-Page) Hustler FasTrak SDX CE Parts Manual Deck Thu Feb 18 06:51:13 UTC 2021...

  • Page 68: Rear Discharge Ce Guard Kit (Multi-Page)

    Rear Discharge CE Guard Kit (Multi-Page) Hustler FasTrak SDX CE Parts Manual Item Part No. Name 122774 CE GUARD, FRONT LS 122775 CE GUARD, FRONT RS 601069 CN .312-18x.200 MAX THK 122753 CE GUARD EXT LS 016832 NT .312-18FLKG5 553545...
  • Page 69 Rear Discharge CE Guard Kit (Multi-Page) Hustler FasTrak SDX CE Parts Manual Thu Feb 18 06:51:13 UTC 2021...
  • Page 70 Rear Discharge CE Guard Kit (Multi-Page) Hustler FasTrak SDX CE Parts Manual Comments for Page: Rear Discharge CE Guard Kit (Multi-Page) 1. Part of the Rear Discharge Deck Assembly. Thu Feb 18 06:51:13 UTC 2021...
  • Page 71 54" Service Deck Hustler FasTrak SDX CE Parts Manual Deck Thu Feb 18 06:51:14 UTC 2021...

  • Page 72: 54" Service Deck

    54" Service Deck Hustler FasTrak SDX CE Parts Manual Item Part No. Name 552873 54" SERVICE DECK 781419 DECAL, BELT ROUTING 604221 DECAL, DANGER / CHUTE 799171 DECAL, Z 54" Deck ID 604222 DECAL, DANGER / OBJECTS Comments for Page: 54" Service Deck 1.
  • Page 73 54" Deck Pulleys & Spindles Hustler FasTrak SDX CE Parts Manual Deck Thu Feb 18 06:51:15 UTC 2021 8-10...

  • Page 74: 54" Deck Pulleys & Spindles

    54" Deck Pulleys & Spindles Hustler FasTrak SDX CE Parts Manual Item Part No. Name 781567 NT .500-13NLG5 604486 FW .531X.812X.089 HD 605467 DUST SHIELD 605512 4" IDLER PULLEY 607616 SPRING, DECK IDLER 121052 SLED, TENSIONER 604790 IDLER SLIDE, EXTRUDED 604251 NT .312-18 HXNL JAM G2ZN...
  • Page 75 54" Deck Hustler FasTrak SDX CE Parts Manual Deck Thu Feb 18 06:51:16 UTC 2021 8-11...

  • Page 76: 54" Deck

    54" Deck Hustler FasTrak SDX CE Parts Manual Item Part No. Name 553064 SVC, PULLEY COVER RH 553065 SVC, PULLEY COVER LH 604324 CS .250-20 X .75 HX FLG 602562 DECAL, NO SERVICE 086660 NT .375-16NLG8 786483 DECK BELT 605469...
  • Page 77 54" Deck Hustler FasTrak SDX CE Parts Manual 797704 BLADE, 18.5"-MUL-F-CW 6. The pulley covers include the decals. Thu Feb 18 06:51:16 UTC 2021 8-11...
  • Page 78 60" Service Deck Hustler FasTrak SDX CE Parts Manual This page intentionally left blank Thu Feb 18 06:51:16 UTC 2021 8-12...
  • Page 79 60" Service Deck Hustler FasTrak SDX CE Parts Manual Deck Thu Feb 18 06:51:17 UTC 2021 8-12...

  • Page 80: 60" Service Deck

    60" Service Deck Hustler FasTrak SDX CE Parts Manual Item Part No. Name 552874 60" SERVICE DECK 781419 DECAL, BELT ROUTING 604222 DECAL, DANGER / OBJECTS 786277 DECAL, 60 DECK ID 604221 DECAL, DANGER / CHUTE Comments for Page: 60" Service Deck 1.
  • Page 81 60" Deck Pulleys & Spindles Hustler FasTrak SDX CE Parts Manual Deck Thu Feb 18 06:51:17 UTC 2021 8-13...

  • Page 82: 60" Deck Pulleys & Spindles

    60" Deck Pulleys & Spindles Hustler FasTrak SDX CE Parts Manual Item Part No. Name 781567 NT .500-13NLG5 604486 FW .531X.812X.089 HD 605467 DUST SHIELD 605512 4" IDLER PULLEY 607616 SPRING, DECK IDLER 121052 SLED, TENSIONER 604790 IDLER SLIDE, EXTRUDED 604251 NT .312-18 HXNL JAM G2ZN...
  • Page 83 60" Deck Hustler FasTrak SDX CE Parts Manual Deck Thu Feb 18 06:51:18 UTC 2021 8-14...

  • Page 84: 60" Deck

    60" Deck Hustler FasTrak SDX CE Parts Manual Item Part No. Name 553064 SVC, PULLEY COVER RH 604324 CS .250-20 X .75 HX FLG 553065 SVC, PULLEY COVER LH 602562 DECAL, NO SERVICE 605469 DISCHARGE CHUTE 602435 SPRING, TORSION 086660 NT .375-16NLG8...
  • Page 85 60" Deck Hustler FasTrak SDX CE Parts Manual 794214 BLADE, 20.5"-MUL-F-CW 793794 BLADE, 20.50"-L-F-CW 6. The pulley covers include the decals. Thu Feb 18 06:51:18 UTC 2021 8-14...
  • Page 86 Spindle Service Parts - 605380 Hustler FasTrak SDX CE Parts Manual This page intentionally left blank Thu Feb 18 06:51:19 UTC 2021 8-15...
  • Page 87 Spindle Service Parts - 605380 Hustler FasTrak SDX CE Parts Manual Deck Thu Feb 18 06:51:19 UTC 2021 8-15...

  • Page 88: Spindle Service Parts - 605380

    Spindle Service Parts - 605380 Hustler FasTrak SDX CE Parts Manual Item Part No. Name 783548 RING, BLADE SPINDLE RET 607275 BLADE SPINDLE BEARING 783530 SPACER, BLADE SPINDLE 783514 HOUSING, BLADE SPINDLE 605381 SHAFT, SPINDLE, CONSUMER Thu Feb 18 06:51:19 UTC 2021...
  • Page 89 Deck Lift (Multi-Page) Hustler FasTrak SDX CE Parts Manual Deck Thu Feb 18 06:51:20 UTC 2021 8-16...

  • Page 90: Deck Lift (Multi-Page)

    Deck Lift (Multi-Page) Hustler FasTrak SDX CE Parts Manual Item Part No. Name 605466 TRANSPORT LATCH 768259 BUSHING,IGUS#0810 (FS) 605470 CE .500X2.00X1.63 553089 INDICATOR PLATE CE 793059 CLIP E,(1/2").80X.396X. 710194 CB .375-16X 1.50 STD G5 601963 PIN, DECK HEIGHT STOP...
  • Page 91 Deck Lift (Multi-Page) Hustler FasTrak SDX CE Parts Manual Thu Feb 18 06:51:20 UTC 2021 8-16...
  • Page 92 Deck Lift (Multi-Page) Hustler FasTrak SDX CE Parts Manual Comments for Page: Deck Lift (Multi-Page) 1. 553089 (indicator plate) includes the decal. Thu Feb 18 06:51:20 UTC 2021 8-16...
  • Page 93 Side Discharge CE Guard Kit (Multi-Page) Hustler FasTrak SDX CE Parts Manual Deck Thu Feb 18 06:51:20 UTC 2021 8-17...

  • Page 94: Side Discharge Ce Guard Kit (Multi-Page)

    Side Discharge CE Guard Kit (Multi-Page) Hustler FasTrak SDX CE Parts Manual Item Part No. Name 552999 SVC GUARD, RHS DECK 122752 CE GUARD EXT RS 029710 CS .312-18X .750 HXFLK 768523 FW 0.343SAE 016832 NT .312-18FLKG5 064014 CS .312-18X0.875HXG5 079210 FW 0.344X1.0X0.06 ZN...
  • Page 95 Side Discharge CE Guard Kit (Multi-Page) Hustler FasTrak SDX CE Parts Manual Thu Feb 18 06:51:20 UTC 2021 8-17...
  • Page 96 Side Discharge CE Guard Kit (Multi-Page) Hustler FasTrak SDX CE Parts Manual Comments for Page: Side Discharge CE Guard Kit (Multi-Page) 1. Part of the Engine Guard Assembly. Thu Feb 18 06:51:20 UTC 2021 8-17...

  • Page 97: Seat & Rops

    Seat - S/N 16123305 & Higher Hustler FasTrak SDX CE Parts Manual Seat & ROPS Thu Feb 18 06:51:21 UTC 2021...

  • Page 98: Seat - S/N 16123305 & Higher

    Seat - S/N 16123305 & Higher Hustler FasTrak SDX CE Parts Manual Item Part No. Name 606474 SEAT 123688-1 HYDRO GUARD, RH 036244 CS .375-16X1.00 HX G5 ZN 767954 FW 0.379X.82X.06 HD ZN 604324 CS .250-20 X .75 HX FLG...
  • Page 99 Seat - S/N Prior to 16123305 Hustler FasTrak SDX CE Parts Manual Seat & ROPS Thu Feb 18 06:51:22 UTC 2021...

  • Page 100: Seat - S/N Prior To 16123305

    Seat - S/N Prior to 16123305 Hustler FasTrak SDX CE Parts Manual Item Part No. Name 605812 SEAT W/ ISOLATOR Not Shown 605566 SEAT, 2 PIECE 121069 HYDRO GUARD, RH 036244 CS .375-16X1.00 HX G5 ZN 767954 FW 0.379X.82X.06 HD ZN 604324 CS .250-20 X .75 HX FLG...
  • Page 101 Seat Service Parts - 606474 Hustler FasTrak SDX CE Parts Manual Seat & ROPS Thu Feb 18 06:51:23 UTC 2021...

  • Page 102: Seat Service Parts - 606474

    Seat Service Parts - 606474 Hustler FasTrak SDX CE Parts Manual Item Part No. Name Not Shown 606474 SEAT 606572 SVC, SEAT BACK COVER 605615 ARM REST (PAIR) 604945 SEAT BELT (SET) 606571 SVC, SEAT BOTTOM COVER 603148 N/O SEAT SWITCH...
  • Page 103 Seat Service Parts - 605812 Hustler FasTrak SDX CE Parts Manual Seat & ROPS Thu Feb 18 06:51:24 UTC 2021...

  • Page 104: Seat Service Parts - 605812

    Seat Service Parts - 605812 Hustler FasTrak SDX CE Parts Manual Item Part No. Name Not Shown 605812 SEAT W/ ISOLATOR 605614 SVC SELL 605566 SEAT 605613 SVC SELL 605566 SEAT 605615 ARM REST (PAIR) 604945 SEAT BELT (SET) 122166...

  • Page 105: Rops

    ROPS Hustler FasTrak SDX CE Parts Manual Seat & ROPS Thu Feb 18 06:51:25 UTC 2021...
  • Page 106 ROPS Hustler FasTrak SDX CE Parts Manual Item Part No. Name 605479 ROPS ASSY 605044 KIT, ROPS HARDWARE 605646 KIT, POLY STOP (PAIR) 023317 NT .500-13UNTG8 767962 FW .531 x 1.063 x .175 061812 CS .500-13X3.50 HX G5 ZN 605691...

This manual is also suitable for:

933952ce933960ce934869ce

Table of Contents
