Figure 1
Residential Optima™ Concealed Pendent (Non-Activated)
1" x 1/2" Reducing
Coupling
2 1/2" ±1/8"
Hole Diameter
3/8" (ref.)
Face of Reducing Coupling
2 9/16" to
3 1/16"
2" ±1/4"
3 1/4" Diameter
3/16"
Figure 2
Residential Optima™ Concealed Pendent (Activated)
1" x 1/2" Reducing
Coupling
2 1/2" ±1/8"
Hole Diameter
3/8" (ref.)
Face of Reducing Coupling
2" ±1/4"
