Vortex RADIAN Product Manual page 2

Quick-Release
Locking Knob
Ball Locking Knob
Base Panning Knob
2
Attaching/Removing the Radian
Bubble Level
To mount the ball head to the tripod:
1. Lift the Quick-Release Locking Latch on the tripod.
2. Press and hold the Platform Release Button and
Quick-Release Plate
3. Rotate the Quick-Release Locking Latch down to
Drag Tension Knob
4. To remove the ball head, follow these steps in
NOTE: If needed, the locking latch can be repositioned
by shifting the latch to the left and rotating the latch
up/down to reposition.
Counterweight Hook
To help stabilize the tripod in windy
conditions, hang a weight from the
Counterweight Hook.
Ball Head
™
fully seat ball head into the tripod. Once seated, the
ball head can be oriented in any direction.
the locked position.
reverse order.
Press the Quick-Release
Button on the tripod to seat
the ball head.
Radian
™ TRIPOD BALL HEAD
Quick-Release
Locking Latch
3
