- Page 1 PRODUCT MANUAL...
-
Page 2: Specifications
RIDGEVIEW ™ CARBON SPECIFICATIONS Quick-Release Locking Knob Center Column Height Adjustment Knob Tilt/Panning Locking Handle LEG MATERIAL Carbon Fiber 3-Angle Leg MAXIMUM OPERATING HEIGHT 73.8" (187.3cm) Pivot Locks MINIMUM OPERATING HEIGHT 8.3" (21cm) MAXIMUM CENTER COLUMN EXTENSION 9.3" (23.5cm) FOLDED DIMENSIONS (HxW) 29.0”... - Page 3 RIDGEVIEW ™ CARBON Adjusting Leg Section Length BASIC ADJUSTMENTS Each of the three tripod leg sections can be extended to adjust Rotate Leg Lock Tilt/Panning Action 1/4 turn to lock the tripod’s height. leg in place. To adjust the length of a leg section: •...
- Page 4 Quick-Release Locking Knob clockwise to securely Lifetime Warranty. lock the plate in the head. Note: To mount binoculars to the tripod, a binocular adapter is required. Purchase Vortex ® binocular adapters service@VortexOptics.com • 1-800-4VORTEX from your local dealers.
- Page 5 M-00300-1 © 2021 Vortex Optics ® Registered Trademark and TM Trademark of Vortex Optics. Patent Pending...
Need help?
Do you have a question about the Ridgeview and is the answer not in the manual?
Questions and answers
I have a Ridgeview with a Leupold pan head. I don’t know how to remove the pan head from the metal tube after removing it from the tripod legs
To remove the Leupold pan head from the metal tube of a Vortex Ridgeview after detaching it from the tripod legs, you need to unscrew the pan head from the center column (metal tube). This is typically done by rotating the pan head counter-clockwise while holding the center column steady.
This answer is automatically generated
