battery level.
The magic cable tie in the package helps to secure the
battery and prevents it from falling off when impacted or
used in environments prone to vibration.
Overview
1
2
1. Battery Shelf
Used to place a battery.
2. Power Switch
Power a battery on or
off.

Installation

Fixing the Magic Cable Tie and Buckle (Optional)
When used in environments prone to vibration or there is
a risk of impact, it is recommended to fix the magic cable
tie and buckle onto the Battery Rack before mounting the
Battery Rack and battery. When attached to a static surface
like a wall or the ground, there is no need to fix the magic
3. Battery Information Port
Used to monitor data such
as the current battery level.
4. Power Output Port
Connect to a robot or the
Referee System.
3
4
3
