dji ROBOMASTER User Manual
Dart trigger device
Hide thumbs
Also See for ROBOMASTER:
- User manual (5 pages) ,
- User manual (15 pages) ,
- User manual (21 pages)
Table of Contents
Advertisement
Quick Links
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for dji ROBOMASTER
Summary of Contents for dji ROBOMASTER
- Page 1 ROBOMASTER Dart Trigger Device User Manual v1.0 2020.05...
- Page 2 Failure to read and follow instructions and warnings may result in serious injury to yourself or others, damage to your DJI product, or damage to other objects in the vicinity. By using this product, you hereby signify that you have read this disclaimer carefully and that you understand and agree to abide by all terms and conditions of this document and all relevant documents of this product.
- Page 3 RoboMaster Dart Trigger Device User Manual 1. Logo (install the trigger device with this side facing upward) 2. Mounting Bracket 3. 3-pin 2.54mm Cable a. GND b. +5V Dimensions Refer to the dimensions in the figure below to mount the trigger device correctly.
- Page 4 RoboMaster Dart Trigger Device User Manual Installation Instructions 1. Use at least four M2.5 screws (two for each mounting plate) to secure the trigger device to the tip of the dart. It is recommended to use washers with the screws.
- Page 5 RoboMaster Dart Trigger Device User Manual Usage Status Descriptions Configuration Status The trigger device enters configuration status within 3 seconds after powering on. In this status, users can configure the light color or switch modes. Work Status The trigger device automatically enters the work status after being powered on for 3 seconds or when configuration is completed.
- Page 6 RoboMaster Dart Trigger Device User Manual Specifications Input Voltage Input Power* 1.5 W Light Color Red or blue Structure Material Weight 20 g Operating Temperature 0° to 55° C (32° to 131° F) * Tested in a well-ventilated laboratory environment at room temperature.
