SAFETY INSTRUCTIONS
1. Please read these safety instructions carefully.
2. Please keep this User's Manual for later reference.
3. Please disconnect this equipment from AC outlet before cleaning. Don't use liquid or
sprayed detergent for cleaning. Use moisture sheet or clothe for cleaning.
4. For pluggable equipment, the socked-outlet shall be installed near the equipment and shall
be easily accessible.
5. Please keep this equipment from humidity.
6. Lay this equipment on a reliable surface when install. A drop or fall could cause injury.
7. Do not leave this equipment in an environment unconditioned, storage temperature above
0
60
C, it may damage the equipment.
8. The opening on the enclosure is for air convection hence the equipment from overheating.
DO NOT COVER THE OPENING.
9. Make sure the voltage of the power source connect the equipment to the power outlet.
10. Please keep the power cord such a way that people can not step on it. Do not place anything
over power cord. The power cord must rate for the voltage and current marked on the
product's electrical ratings label. The voltage and current rating of the cord should be
greater than the voltage and the current rating marked on the product.
11. All cautions and warning on the equipment should be noted.
12. If the equipment is not in use for long time, disconnect the equipment from mains to avoid
being damaged by transient over-voltage.
13. Never pour any liquid into ventilation openings; this could cause fire or electrical shock.
14. Never open the equipment. For safety reason, qualified service personnel should only
open the equipment.
15. If one of the following situations arises, get the equipment checked by service personnel.
The Power Cord or plug is damaged.
Liquid has penetrated into the equipment.
The equipment has been exposed to moisture.
The equipment has not worked well or you can not get it work according to User's
Manual.
The equipment has dropped and damaged.
If the equipment has obvious signs or breakage.
2
Console user
s manual
'
Advertisement
Related Manuals for I-Tech DKP-115 Series
Summary of Contents for I-Tech DKP-115 Series
- Page 1 Console user s manual ’ SAFETY INSTRUCTIONS 1. Please read these safety instructions carefully. 2. Please keep this User’s Manual for later reference. 3. Please disconnect this equipment from AC outlet before cleaning. Don’t use liquid or sprayed detergent for cleaning. Use moisture sheet or clothe for cleaning. 4.
-
Page 4: Table Of Contents
Console user s manual ’ 4.6 Product Details....................32 4.7 Hardware Installation ................... 32 4.8 Usage ........................33 4.9 Daisy Chain Connection Diagram................. 36 4.10 Hot Plug......................37 4.11 On Screen Display Operation................38 4.12 Troubleshooting ....................41... - Page 5 Console user s manual ’ CHAPTER 1 GENERAL INFORMATION 1.1 Overview The KVM Console is an ideal solution for network administration with multiple servers / platforms. Their 15-inch and 17-inch 19-inch large size TFT LCD color display and ultra-low-profile compact industrial keyboard / touchpad provide the user-friendliest and most reliable environment for network administrators.
- Page 18 Console user s manual ’ CHAPTER 2 PANEL CONTROLS AND OSD FUNCTIONS Controls Description Soft power on/off button. Adjacent LED is lit when on. Auto-synchronize and scale down display to any valid Auto factory preset timings. Press to scroll the function you want to adjust. Down Press to scroll the function you want to adjust.
- Page 19 Console user s manual ’ 2.3 Brightness 1. Press the “menu” bottom. 2. Use the “Down” and “Up” bottom to scroll. Auto tune. Input Source Brightness Contrast Color Position Language Recall Exit 3. Press the “menu＂ bottom to enter. 4. Use the “Down＂ and “Up＂ bottom to adjust the brightness of the display. 5.
- Page 20 Console user s manual ’ Position Language Recall Exit 3. Press the “menu” bottom to enter. And you will see: Icon Description 9300°K To set CIE coordinates at 9300°K color 7500°K To set CIE coordinates at 7500°K color 6500°K To set CIE coordinates at 6500°K color User To set user defined CIE Auto color...
- Page 21 Console user s manual ’ Auto tune. Input Source Brightness Contrast Color Position Language Recall Exit 3. Press the “menu” bottom to enter. And you will see: English German French Italian Spanish 4. Use the “Down” and “Up” bottom to scroll. 5.
- Page 22 Console user s manual ’ STANDBY SUSPEND Note: OSD – On Screen Display...
- Page 23 Console user s manual ’ CHAPTER 3 INSTALLATION 3.1 Install Console to Cabinet 3.1.1 Notes 1. Please check all peripherals according the list before installation. To make sure that the whole unit was not damaged and lost during shipping process. If you encounter any problem, please contact your dealer.
- Page 24 Console user s manual ’ 3.1.3 Installation Step 1. Loose (Not release) four rear screws then adjust rear bracket to fit your cabinet. 2. Install front and rear bracket on cabinet. 3. Tight-up four rear screws. 4. Repeat step 1~3 for the other side. 5.
- Page 25 Console user s manual ’ 7. Install three screws in rear of the console. (Both sides) 8. Finish installation as below. 3.1.4 Replace longer bracket Step (For rack depth 828~1000mm) Release six screws. 2. Take rear bracket out. Original bracket Input rear long bracket to rear of the rail then adjust rear bracket to fit your cabinet.
- Page 26 Console user s manual ’ 3.1.5 Unload Step 1. Make sure the console is lock. 2. Release three screws in rear of the console. (Both sides) 3. Unlock. 4. Pull console out until console lock. 5. Pull rail-release switch and pull console out.(Both sides. Be careful when pull out console.) rail-release switch...
- Page 27 Console user s manual ’ 3.2 Installing the Video Card and Video Driver Before connecting the LCD console, make sure your computer has a video card already installed for the monitor. After you connect the drawer, install the video software driver. The video driver is supplied by the video card manufacturer and may be found on the CDROM that came with your computer.
- Page 28 Console User s Manual ’ 3.2.2 Connecting the Drawer To connect an LCD console to a computer, perform the following steps AC INPUT 100~240VAC MOUSE KEYBOARD 50~60Hz The rear view of LCD console 1. Turn off your computer. You should always turn off your computer before connecting or disconnecting a device.
- Page 29 Console User s Manual ’ make sure that all the devices on the installation are properly grounded. Consult your direct vendor for any technical issues if necessary.
- Page 30 Console User s Manual ’ CHAPTER 4 KVM SWITCH 4.1 Introduction Controlling multiple computers from One Keyboard, Mouse and VGA Monitor. Rack Mount Console is loaded with features such as 19” Rack Mount Size, Daisy Chain up to Eight units, On Screen Display Menu, Password security, Searching PC server name, Hot key Control (Include Auto Scan Control function).
- Page 31 Console User s Manual ’ 4.3 Technical Specifications Model No. 8 port Rack Mount KVM 16 port Rack Mount KVM Switch Switch PC Port PC Port Connector VGA HDDB 15pin (All Female Types) Daisy Chain Port Connector 1 x VGA HDDB 15pin and 2 x Mini Din 6Pin special cable (3 (All Female Types) to 3 cable) On Screen Display Control...
-
Page 32: Product Details
Console User s Manual ’ Daisy Chain Cable: PS/2 Cable: Mini Din 6 pin Male to Male VGA Cable: HDB 15 pin Male to Male 4.6 Product Details Rear Panel of 8 port Rack Mount KVM Console: Rear Panel of 16 port Rack Mount KVM Console: 4.7 Hardware Installation Before installation, please make sure all of peripherals and computers have been turned off. -
Page 33: Usage
Console User s Manual ’ of console unit. The other end of input cable will have three connector; a HDDB-15 pin male type for PC video, a Mini Din 6 pin female type for keyboard and Mini Din 6 pin female type for mouse. - Page 34 Console User s Manual ’ Note: Before you are not familiar with the operation of OSD menu, please don’t change the password – i.e. keep default eight zero (00000000) value. Otherwise, if you have set the password and unfortunately forget the password, you need contact to your distributor for maintaining the password.
- Page 35 Console User s Manual ’ To select PC port: Port No. Scroll Scroll Bank Port No 1~8 (8 port) Lock Lock 0 or 1 1~16 (16 port) Scroll Scroll Beeper Lock Lock (Note: The default Beeper function is ON and beeper control is only for available for Scan Mode ) Scroll Scroll...
-
Page 36: Daisy Chain Connection Diagram
Console User s Manual ’ Scroll lock + Scroll lock + １ + 04 B. To access a computer attached from Bank 3 to Bank 4, You can press through hot key as below: Scroll lock + Scroll lock + Page Down Note: Bank no. -
Page 37: Hot Plug
Console User s Manual ’ 4.10 Hot Plug The Console supports “Hot Plug“ function for easy addition or removal of PCs. The user can arrange or maintain PCs as follows: a. A PC can be disconnected and reconnected to the same or different port of the KVM unit without having to power it off as long as it is not the Daisy-chain port or pass through port. -
Page 38: On Screen Display Operation
Console User s Manual ’ 4.11 On Screen Display Operation 1. OSD menu can be popped up in powered on PC port or non-powered on PC port or empty PC port. The resolution of OSD menu is fixed to 1024X768 for non-powered on PC port or empty PC port. - Page 39 Console User s Manual ’ To use up arrow key “ ” or down arrow key “ ” to select port for destination PC name. After you have selected the PC port already, you can press the ENTER key to switch the PC port you want immediately.
- Page 40 Console User s Manual ’ ENTER NEW PASSWORD : ESC : QUIT ENTER : COMPLETE RETYPE NEW PASSWORD : ESC : QUIT ENTER : COMPLETE You need to retype the password again for rechecking your previous key-in password is matched or not. NEW PASSWORD COMPLETE ESC : QUIT ENTER : COMPLETE...
-
Page 41: Troubleshooting
Console User s Manual ’ 4.12 Troubleshooting 1. Ensure that all cables are well seated. Label all of cables with the number for each respective computer to avoid confusion. 2. The recommended VGA cable distance is 5 meters maximum without ghosting and degradation.
