INSTRUCTION MANUAL
Time/Date
PID/Autotunning
Comunication.
Reject change
Validate change
J
.P. SELECTA s.a.
CODE 80305 REV 0

7.2 Setting screen

Icons meaning:
½

7.2.1 Set time and date

Press on the time/date icon. Press successively on the box to select the day,
month, year, minute, second adjustment.
Adjust by pressing on the icons for increase and decrease.
7.2.2 Set parameters of temperature control and
«Autotunning»
For an optimal use of the oven, P, I, D. parameters of temperature control
should be the appropriate value.
With a value of the appropriate P, I, D parameters, the furnace will reach
the temperature in the shortest possible time and without exceeding the set
temperature. However, those values can be quite different at high and low
temperatures.
The oven comes with the following values: P=10; I=100; D=25 which are
appropriate for most jobs.
These values can be modifi ed, but it's advisable to perform an «Autotun-
ning» when you need a better accuracy.
The «Autotunning» automatically adjusts the optimal parameters for a given
temperature and load.
Press on the PID/Autotunning icon. Press successively on the box to select
the P, I, D values adjustment and modify the value by pressing on the In-
crease and Decrease icons.
Attention: It is not reccommended to change these parameters. Use the
«Autotunning» option to automatically adjust these values.
Press on the PID/Autotunning icon.
Select the «Autotunning» temperature with:
(for example, the temperature most used)
Start «Autotunning» by pressing on the icon
If for some reason you want to stop, press on:
Autovía A-2 Km 585.1 Abrera 08630 (Barcelona) España
e-mail: selecta@jpselecta.es - website: http://www.jpselecta.es
Feb/2015 (It can be modifi ed without notice)
á á
ºC/ºF
Tel 34 937 700 877 Fax 34 937 702 362
Page: 16
Alarms and temp. offset
Temperature units.
Language (Spanish, English,
French)
Up/Down
