Uwatec G260 Maintenance Procedure page 4

MAINTENANCE PROCEDURE FOR G260
This maintenance procedure is based upon the attached schematic.
WARNING
This maintenance procedure is only for appointed Scubapro technicians that fol-
lowed a complete course on equipment repair and in no case can replace a technic-
al repair course delivered by a SCUBAPRO/ UWATEC appointed staff.
This procedure is a generic description for the G260. The attached schematic is an
overview for the maintenance procedure. The dedicated regulator schematic must
be used for parts replacements.
TOOLS
Blow gun
2 Stage adjustment tool
nd
Grease Christo Lube MCG111
Screwdriver bowl end
Universal tool regulator (new model)
G260 cover tool
O-ring extractor
VIVA flow vane extractor
Regulator hose tool (on 2
Countermat
Digi-Mag 6000 Digital Magnehelic incl. Magnehelic mouthpiece
Allen key, 4 mm
Cutter small model
Pliers small model
Screwdriver flat blade small model
Wooden chopstick or soft polymer stick
DISASSEMBLY
1. Slide the sleeve(s) back and unscrew the L.P. hose from the 1
2. Remove the o-rings from the L.P. hose with the o-ring extractor.
3. Remove the mouthpiece clip or strap and remove the mouthpiece.
4. Remove the pin with the screwdriver from the case.
/ "
3
32
stage)
nd
MAINTENANCE PROCEDURE G260 – REVISION 03 - 2013-04
4 13 ! - !
40.978.000
41.043.010
41.493.125
43.002.101
43.040.000
43.300.020C
43.300.107
43.300.225
43.300.235
43.900.999
and 2 stage.
st nd
