Solo TOC-1 Owner's Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
OWNER'S MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TOC-1 and is the answer not in the manual?

Questions and answers

Related Manuals for Solo TOC-1

Summary of Contents for Solo TOC-1

  • Page 1 OWNER’S MANUAL...

  • Page 3: Table Of Contents

    On Vehicle References ............1-2 Pre-Drive Inspections ............2-5 Safety Information..........1-3 Pre-Drive Inspection Checklist ........2-5 Know How the SOLO is Different ........1-3 Driver Requirements ............1-4 SECTION 3: SEAT AND SEAT BELT Warning Labels ..............1-5 Seat................3-1 Vehicle Modifications and Accessories ......
  • Page 4 Table of Contents SECTION 4: CONTROLS AND FEATURES Wiper and Washer..........4-25 Windshield Wiper/Washer Lever ........4-25 Interior Overview ............ 4-1 Locking and Unlocking the Vehicle ....4-26 Controls Overview .............4-2 Remote Keyless Entry (RKE) System ......4-26 Steering Wheel............4-4 Remote Transmitter ............
  • Page 5 Table of Contents SECTION 5: BATTERY AND CHARGING SECTION 7: MAINTENANCE High-Voltage Battery Information......5-1 Maintenance Requirements ........7-1 High-Voltage Components ..........5-1 General Information ............7-1 About the High-Voltage Battery ........5-2 Owner Maintenance ............7-1 Battery Care ..............5-2 Initial Required Maintenance ..........7-2 Charging Instructions ..........
  • Page 6 Table of Contents Drive Belt .............. 7-13 Vehicle Lifting Points ........... 7-41 Checking Drive Belt Tension ...........7-13 Jacking and Lifting the Vehicle ........7-41 Wheels and Tires ........... 7-14 Vehicle Recovery..........7-42 Inspection and Maintenance ........... 7-14 Transporting the Vehicle ..........7-42 Tire Pressures ..............7-17 Using the Recovery Eye ..........

  • Page 7: Information About This Manual

    Note: If you choose to sell your SOLO, please remember to hand This symbol indicates risk of electric shock. Obey all over this manual; it is, by law, an important part of the vehicle.

  • Page 8: On Vehicle References

    Information About This Manual On Vehicle References LEFT SIDE RIGHT SIDE The terms Left or Right refer to the driver’s left or right when sitting in the vehicle.

  • Page 9: Safety Information

    What kind of vehicle is the SOLO? The SOLO is not designed or tested to meet all motor vehicle The SOLO is a three-wheeled, single-occupant passenger safety standards. While it does meet some requirements (such electric vehicle with an enclosed cabin.

  • Page 10: Driver Requirements

    Driver Requirements Crash avoidance starts with the basic maneuverability of your vehicle: how well can it brake, steer, and accelerate. The SOLO Drivers who cannot comfortably reach the controls and adjust provides the ability to maneuver nimbly. In addition, it has the seat or seat belt properly should not operate the SOLO.

  • Page 11: Warning Labels

    SOLO New Vehicle Limited Warranties. SOLO accessories are designed to complement and function with other systems on your vehicle. Go to store.electrameccanica.com to see the list of approved accessories.

  • Page 12: Information About Your Vehicle

     EVs operate with no engine noise; you may hear a soft factors defines your trip profile. In addition, tire pressure and whirring sound and tire noise. The SOLO does not generate payload are important considerations. a pedestrian-alerting sound.

  • Page 13: Vehicle Telematics

    ElectraMeccanica’s telematics system wirelessly transmits vehicle information to ElectraMeccanica on a periodic basis. Your SOLO is equipped with electronic modules that monitor The data is used as described above and helps ensure the proper and record data from various vehicle systems, including the maintenance of your vehicle.

  • Page 14: Vehicle Identification Number (Vin)

    Information About Your Vehicle Vehicle Identification Number (VIN) This legal identifier is in the front corner of the instrument panel. It can be viewed from outside the vehicle. The VIN is also printed on the Tire and Loading Information label. See “Vehicle Load Limits”, page 2-3.

  • Page 15: Specifications

    Specifications Vehicle Specifications Specifications Tires Front: 135/70R15 All-Season Range Up to 100 mi (160 km) range Rear: 215/40R16 All-Season Charging Time 220V: 2.5 hrs 0-80%, 4 hrs 0-100% est* Safety 3-Wheel Power Disc Brakes 120V: 12 hrs 0-80%, 15 hrs 0-100% est* Electronic Parking Brake Acceleration 0-60 mph (0-100 km/h): 12 seconds est*...
  • Page 16 Specifications Vehicle dimensions Length 10.18 ft 3103 mm Overall Width 5.10 ft 1553 mm Overall Height 4.38 ft 1334 mm Wheel Base 6.64 ft 2024 mm Front Overhang 24.57 in 624 mm Rear Overhang 17.91 in 455 mm Approach Angle 20.5°...

  • Page 17: Consumer Information

    Consumer Information California Proposition 65 Warning Consumer In formation Certain vehicle components contain or WARNING emit chemicals known to the State of California to cause cancer and birth defects or other reproductive harm. In addition, certain fluids contained in vehicles and certain products of component wear contain or emit chemicals known to the State of California to cause cancer and birth defects or other reproductive harm.

  • Page 18: Frequently Asked Questions

    Attempting to do so could cause severe damage to your vehicle, which would not be covered by the Will I get less range at higher speed? warranty. Faster speed = reduced range Yes. It takes more energy to push a SOLO faster because you 1-12...

  • Page 19: General Information

    Familiarize yourself with all of the controls, such as the wiper, Tire failure exterior lights, and climate controls. If your SOLO has a tire failure or a blowout, firmly grip the steering wheel, gradually slow down, and carefully steer to a Lane positioning safe place to stop.
  • Page 20 As with other vehicles (particularly those with a single rear wheel), your SOLO can hydroplane if you drive too fast over water that has accumulated on the road. When hydroplaning occurs, one or more wheels rise up on a layer of water, losing contact with the road.

  • Page 21: Vehicle Load Limits

    General Information Vehicle Load Limits Sudden power loss If you experience a sudden loss of power while driving, review The combined weight of the driver, cargo, the instrument cluster display for any system message WARNING and any non-factory-installed equipment warnings. See “System messages”, page 4-11.
  • Page 22 General Information MFD BY: CHONQING ZONGSHEN AUTOMOBILE INDUSTRY CO. LTD. DATE OF MFG: GVWR: 933 KG FOR: ELECTRAMECCANICA VEHICLES CORP. MM/YY (2056 LB) FRONT GAWR WITH TIRES RIMS AT COLD 499 KG (1100 LB) 135/70R15 70T 15X4.5J 228 KPA (33 PSI) REAR GAWR WITH TIRES RIMS AT...

  • Page 23: Pre-Drive Inspections

    “Maintenance”, page 7-1. replacement, or repair. To keep your SOLO in safe operating condition, always Item Inspection Procedure See Page perform the recommended pre-drive inspections before each...
  • Page 24 Pre-Drive Inspections Electrical inspections Item Inspection Procedure See Page Turn the key switch to the ON position before performing the Horn Press the center of the steering wheel electrical pre-drive inspections. See “Key Switch”, page 4-6. and verify that the horn sounds loudly. If inspection of any item reveals component failure, have the Front Lights Verify that the front inner, outer, and...

  • Page 25: Seat

    Seat Correct Seating Position  Select a seat position that allows you to wear the seat belt Seat an d Seat Belt Seat correctly. Use the seat, head restraint, and seat belt WARNING  Sit in an upright position, with both feet on the floor and correctly for proper protection in the the seat back reclined no more than 30 degrees.

  • Page 26: Seat Adjustment

    Seat Seat Adjustment Seat forward/rearward position Do not adjust any part of the seat while WARNING the vehicle is in motion. Vehicle movement may cause the seat to shift suddenly, potentially causing injury or loss of control. The seat has two controls that are used to adjust: ...
  • Page 27 Seat Seat backrest angle If the seat backrest is not securely locked WARNING in position, it could move forward in a sudden stop or collision, causing injury to the seated person. Always push and pull on the seat backrest to ensure it is locked.

  • Page 28: Seat Belt

    Seat Belt Using the Seat Belt chest. Avoid wearing the lap section of the belt across the Seat Belt abdominal area. The seat belt should be worn for every WARNING Always adjust the belt to remove slack. trip, no matter how short. Failure to do so WARNING Seat belts worn too loosely can result in greatly increases the risk of death or serious injury in the...

  • Page 29: Fastening And Releasing The Seat Belt

    Seat Belt Fastening and Releasing the Seat Belt Fastening the belt 1. Make sure that your seat is correctly positioned. See “Seat”, page 3-1. 3. Push the latch plate into the buckle until it clicks. Pull up on the latch plate to ensure it is secure. Position the release button on the buckle so that the seat belt can be quickly unbuckled if necessary.

  • Page 30: Wearing The Seat Belt When Pregnant

    Seat Belt Wearing the Seat Belt when Pregnant Releasing the belt A pregnant woman should always wear a WARNING seat belt to protect herself and her unborn child. To unlatch the belt, push the release button on the buckle. The belt should retract to its stowed position.

  • Page 31: Caring For The Seat Belt

    Seat Belt Caring for the Seat Belt Cleaning Do not allow any water, cleaners, or fabric Periodically check the seat belt indicator, seat belt, buckle, WARNING from clothes to enter the seat belt latch plate, retractor, and seat belt anchorages to make sure mechanism.
  • Page 32 Seat Belt...

  • Page 33: Interior Overview

    Interior Overview Controls and Features Interior Overview This page intentionally left blank.

  • Page 34: Controls Overview

    Interior Overview Controls Overview 1 2 3 MIRROR 9 10...
  • Page 35 Interior Overview 1. Hazard warning lights switch (page 4-23) 2. Trunk release (page 4-34) 3. Mirror adjustment controls (page 4-5) 4. Electronic Parking Brake switch (page 4-18) 5. Drive Mode Selector (page 4-7) 6. Climate controls (page 4-29) 7. Turn signals/high-beam headlight control (page 4-22) 8.

  • Page 36: Steering Wheel

    Steering Wheel Steering Wheel Position Horn Steering Wheel Never adjust the steering wheel position The SOLO runs quietly. Watch for WARNING WARNING while the vehicle is in motion. Doing so pedestrians and other road users who may will reduce control of the vehicle, and may cause not be aware of your presence, and use the horn to alert them unpredictable steering movements.

  • Page 37: Mirrors

    You can adjust Note: Because the body of the SOLO is tapered in the rear, little the mirror position as follows: to none of the sides of the vehicle should be visible in the mirrors 1.

  • Page 38: Starting And Drive Selection

    Starting and Drive Selection Key Switch OFF position Starting and Drive Selection Used to turn the vehicle OFF, disabling the electrical system. Take the key from the vehicle when parked to prevent theft. Note: If a door is opened and the key is in the key switch while in the OFF position, an audible warning will activate to remind the operator to remove the key.

  • Page 39: Drive Mode Selector

    Starting and Drive Selection Drive Mode Selector  N - Neutral In this position, the drive system does not drive the rear Shifting to R (Reverse) or D (Drive) when CAUTION wheel. the vehicle is moving in the opposite  D - Drive direction could damage the drive system.
  • Page 40 Starting and Drive Selection Abnormal shift condition In the event that the drive mode is shifted while the vehicle is traveling at a speed higher than 2 mph (3 km/h), the following will occur:  The vehicle will shift into N (Neutral) and remain in N (Neutral) unless the driver selects the original gear that was in use ...

  • Page 41: Instrument Panel

    Instrument Panel Instrument Cluster Display 4. Drive status message (page 4-10) Instrument Panel 5. Turn signal/hazard indicators (page 4-10) 6. System messages (page 4-11) 7. External ambient temperature (page 4-11) 8. SWITCH button (page 4-11) 9. SET button (page 4-12) 15:09 82˚...
  • Page 42 Instrument Panel Indicator and warning lights Always signal your turns and other maneuvers as required by law. These lights may illuminate to advise you of a specific vehicle status or condition. See “Indicator Lights”, page 4-14 When the hazard flashers are activated, both turn signal “Warning Lights”, page 4-15.
  • Page 43 Instrument Panel System messages High-voltage battery state of charge Always heed the instructions and This displays the percentage of charge remaining in the CAUTION warnings displayed in system messages. high-voltage battery pack. Failure to do so could cause damage to the vehicle, which As the charge level decreases, the instrument panel will display would not be covered under the warranty.
  • Page 44 Instrument Panel Clock Trip meter/odometer 15:09 15:09 READY READY miles miles TRIP TRIP Charge Power Charge Power miles miles Power Regen Charge Power Regen Charge To adjust the time: To reset the trip meter, press and hold the SET button until the current trip distance (top number) resets to zero 1.
  • Page 45 Instrument Panel Power/Regen gauge The bars on the Regen gauge indicate the current amount of energy being fed back into the battery through regenerative This gauge indicates the current amount of power in kilowatts braking. See “Regenerative Braking”, page 6-6. (kW) that the vehicle is using or generating.

  • Page 46: Indicator Lights

    Instrument Panel Indicator Lights Fasten seat belt indicator This indicator illuminates when the seat belt is not Daytime running lights indicator buckled. See “Seat Belt”, page 3-4. This indicator illuminates when the Daytime Running Note: If the seat belt is not buckled when the vehicle is Lights are activated.

  • Page 47: Warning Lights

    Instrument Panel Warning Lights Electronic Parking Brake (EPB) warning indicator If the EPB warning indicator illuminates continuously Brake warning indicators or flashes, there is a problem with the EPB. Have the If a brake warning indicator illuminates EPB system inspected immediately by an WARNING while driving, slow down and pull off the ElectraMeccanica Authorized Service Provider.

  • Page 48: Warning Light Combinations

    Instrument Panel Warning Light Combinations The SOLO is programmed so that if a functional error occurs with the vehicle, it will go into Limited Power mode. In this EPS and Fault indicators on key-on mode, the performance of the vehicle is significantly reduced, If the steering wheel is moved while turning the key switch to but it is still drivable.

  • Page 49: Back-Up Camera

    When the Drive Mode Selector is in R (Reverse), the instrument cluster display switches to the rear camera view. If your video display is cloudy or otherwise obscured, the Your SOLO utilizes a camera mounted to the trunk cover, camera lens may require cleaning. See “Cleaning the back-up giving you a live video on the instrument cluster display of what camera”, page...

  • Page 50: Brakes

    Brakes Electronic Parking Brake (EPB) The EPB will disengage automatically when the vehicle is in Brakes READY mode, the Drive Mode Selector is in D (Drive) or R When parking on a hill or slope, ensure (Reverse), and the accelerator is pressed. WARNING that you set your wheels in accordance Note: If the vehicle is stopped on a slope when the EPB is...
  • Page 51 Brakes  To engage the EPB: Once the vehicle is moving at less than 2 mph (3 km/h), pull the EPB switch.  To disengage the EPB in READY mode: Press the brake 15:09 82˚ pedal and then push in the EPB switch. ...

  • Page 52: Lights

    Lights Exterior Lights Lights 1. Auxiliary low beams (page 4-21) 1. Center high-mounted brake light 2. Turn signals (page 4-22) 2. Daytime Running Lights, turn signals, brake lights 3. Daytime Running Lights (page 4-21) 3. Reverse lights 4. High beams (page 4-22) 4.

  • Page 53: Exterior Light Control

    Lights Exterior Light Control Side marker lights The side marker lights make it easier for others to see your vehicle in low-visibility conditions (e.g. fog and rain). To activate the side marker lights, turn the collar to the side marker lights position, and the side marker lights and rear tail lights will turn on.
  • Page 54 Lights High beams Turn signals The high-beam headlights can be activated manually when needed to improve visibility in low-light conditions. The lever has three positions: Upward (for right), downward (for left), and a neutral position for OFF. The corresponding turn signal lights on the front and rear of the vehicle will flash in With the low-beam headlights on, push the lever away from the direction indicated by the lever.
  • Page 55 Lights An arrow on the instrument cluster display Hazard flashers will flash in the direction of the lever Activating your hazard flashers warns others that you are in an position. See “Instrument Cluster Display”, emergency situation, or stopped or pulled over unexpectedly page 4-9.

  • Page 56: Interior Lights

    Lights Interior Lights Trunk light Both interior lights automatically illuminate when the doors or the trunk are opened, and turn off when they are closed. Cabin light This light is located in the trunk on the right-hand side of the trim, and can be used to manually turn the trunk light to the desired function: The cabin light is located above the right window.

  • Page 57: Wiper And Washer

    Wiper and Washer Windshield Wiper/Washer Lever Windshield wiper Wiper and Washer The lever located on the right side of the steering column controls the windshield washer and the wiper. Note: To prevent damage to the edge of the wiper blade, clear any ice from the windshield before turning on the wiper.

  • Page 58: Locking And Unlocking The Vehicle

    Locking and Unlocking the Vehicle Remote Keyless Entry (RKE) System Remote Transmitter Lockin g and Unlocking the Vehicle The remote transmitter contains a small Note: The remote transmitter functions are disabled when the key WARNING battery which, if swallowed, can cause switch is NOT in the OFF position.
  • Page 59 Locking and Unlocking the Vehicle Releasing the key blade Locking the vehicle Exit the vehicle, close both doors, and press the lock button on the transmitter once. The turn signal lights will flash once, indicating that the system has locked both doors.

  • Page 60: Hood

    Hood Hood Hood Only store the charge cable in its CAUTION designated space under the hood. Do not store any additional items in this area. This area is not watertight. Opening the hood Never pull the hood release when the WARNING vehicle is moving.

  • Page 61: Heating And Ventilation

    Heating and Ventilation Climate Controls Recirculation button Heating and Ventilation You should leave the system in fresh air The climate controls are located on the dashboard, left of the WARNING mode under most conditions. Keeping it steering wheel. These controls can be used to adjust the air in recirculation mode can cause the windows to fog up, which circulation, temperature, defroster, and fan speed within the can obscure vision and result in a collision.
  • Page 62 Heating and Ventilation Mode button Temperature control dial Use the mode button to select the direction of air Note: It is not recommended to activate the air conditioning flow through the vents. Each time the mode button is when the ambient temperature is less than 59°F (15°C). If the air pressed, the climate control display indicates the conditioning is activated when the ambient temperature is less than 32°F (0°C), the climate control system will show the current...

  • Page 63: Air Outlets

    Heating and Ventilation Air Outlets Power Windows MIRROR 1. Windshield defroster outlet The power window switches are located on both of the side door panels, and each switch controls its own window. To 2. Face vent outlets operate a window: ...

  • Page 64: Seat Heater

    Heating and Ventilation Seat Heater Do not use the seat heater if you are WARNING unable to feel elevated temperatures or pain in any body parts that contact the seat, as you risk burns or other serious injuries. To prevent inadvertent operation of the seat heater, remove the seat heater fuse.

  • Page 65: Storage

    Never exceed the recommended carrying WARNING The SOLO has limited storage and cargo capacity. Plan your capacities for the trunk, since this can affect vehicle handling and stability. See “Vehicle Load trip accordingly to ensure that you have room for any items you may wish to transport.
  • Page 66 Storage Trunk Emergency trunk release If the vehicle has no power, the trunk can be opened manually from the inside: Pressing the trunk release button on the dashboard will open the trunk. 1. Remove the cover at the base of the trunk latch. Note: The remote transmitter can also be used to open the trunk.

  • Page 67: Cup Holder

    Storage Cup Holder The right door panel has a cup holder that can be folded out when needed. 2. Pull the emergency release handle to unlatch the trunk. 1. Pull the handle down until the tray is level. 4-35...
  • Page 68 Storage 2. Fold the support ring upwards. 4-36...

  • Page 69: High-Voltage Battery Information

    High-Voltage Battery Information High-Voltage Components Battery and Ch argin g High-Vo ltage Battery Information The high-voltage system has no user-serviceable parts. Do WARNING not disassemble, remove or replace high-voltage components, cables or connectors. High-voltage cables are colored orange for easy identification. 1.

  • Page 70: About The High-Voltage Battery

    High-Voltage Battery Information About the High-Voltage Battery Battery Care The high-voltage battery has no parts that If the battery’s charge level falls to 0%, WARNING CAUTION an owner or a non-authorized technician you must plug it in. If you fail to do so can service.

  • Page 71: Charging Instructions

    Charging Instructions Charging the Vehicle Using the Charge Cable Charging Instructions There are two charging methods available for use with your Your vehicle is supplied with a portable charge cable that vehicle: Level 1 (portable charge cable) and Level 2 (EV Charge connects to most standard (110V) power outlets, allowing you Station).

  • Page 72: Connecting The Charge Cable

    Charging Instructions Connecting the Charge Cable  Use a properly-grounded, three-prong outlet.  Ensure that the outlet can provide 15A of continuous Always position the charge cable so that it current. A dedicated circuit with a 15A or higher breaker or WARNING will not be driven over, stepped on, fuse is preferable.
  • Page 73 Charging Instructions 5. The vehicle’s SAE J1772 charging port is located behind the 6. Pull the latch outward (to the right) to release the charging license plate and can be accessed by lifting up on the port cover, then pull the cover outward (to the left) to open spring-loaded rear license plate holder.
  • Page 74 Charging Instructions Note: When the charge cable is plugged into the vehicle, Drive Mode is inhibited to prevent the vehicle from being driven. 22:18 163v 8. Verify the charger status on the charge cable box. Note: During charging or in high ambient temperatures, the vehicle’s internal cooling fan may automatically switch on for On Connection a period of time to cool the cells in the high-voltage battery.

  • Page 75: Estimating Charging Time

    Charging Instructions Estimating Charging Time Disconnecting the Charge Cable To keep debris out of the charging port, The amount of time it takes to fully charge the vehicle is CAUTION dependent upon the remaining battery charge level and the ensure the charging port cover is closed available electrical supply (amperage and voltage).
  • Page 76 Charging Instructions...

  • Page 77: Driving Precautions

     Be aware of your surroundings while operating the vehicle. your hands on the steering wheel, and focus your attention on Because the SOLO is a small vehicle, other drivers may be driving. less likely to be aware of your presence. Before executing turns or lane changes, use your mirrors and turn your head ...

  • Page 78: Impaired Driving

    Driving Precautions Impaired Driving Carefully read all labels and warnings on WARNING any prescription or over-the-counter medication you take before driving. Ensure that it does not cause dizziness, drowsiness, or other side effects which may impair your driving and lead to a collision. NEVER drive while under the influence WARNING of illegal drugs.

  • Page 79: Operating The Vehicle

    3. Without moving the steering wheel, turn the key to the Operating the Vehicle ON position. The display will show the ElectraMeccanica Before entering the SOLO, visually check logo, then load the instrument cluster display. All indicators WARNING around and underneath the vehicle for will flash briefly.
  • Page 80 Operating the Vehicle 15:09 15:09 82˚ 82˚ READY Press Brake To Start miles miles TRIP TRIP Charge Charge Power Power miles miles Power Regen Charge Power Regen Charge 5. Turn the key clockwise past the ON position to the START 6.

  • Page 81: Braking

    Operating the Vehicle Braking Stopping on hills and slopes When stopping on a hill or slope while the vehicle is in D Pressing the brake pedal down will increase the amount of (Drive) or R (Reverse) (e.g. at a stoplight), you can engage the braking force.

  • Page 82: Regenerative Braking

    Operating the Vehicle Regenerative Braking Hill Start Assist system Do not rely exclusively on the Hill Start Regenerative braking does not replace the WARNING Assist system to keep your vehicle WARNING need to use the brake pedal to stop the stationary on a hill.

  • Page 83: Parking

    Operating the Vehicle Parking With the vehicle at a complete stop and your foot on the brake pedal: 1. Turn the Drive Mode Selector Switch to N (Neutral). See “Drive Mode Selector”, page 4-7. 2. Apply the Electronic Parking Brake (EPB). See “Electronic Parking Brake (EPB)”, page 4-18.
  • Page 84 Operating the Vehicle...

  • Page 85: Maintenance Requirements

    In addition to the scheduled maintenance, you should carry out recommendations specified by ElectraMeccanica. a pre-drive inspection before each trip to keep your SOLO in Regular maintenance can help protect against major repair safe operating condition. See “Pre-Drive Inspections”,...

  • Page 86: Initial Required Maintenance

    Maintenance Requirements Initial Required Maintenance Parts and Maintenance Items To maintain the warranty, the vehicle must be brought to an The proper replacement parts, fluids, and lubricants to use are approved ElectraMeccanica Authorized Service Provider for listed in the table below. initial servicing in the first 500–1,000 mi (750–1500 km) or Part/Usage Number/Requirement...

  • Page 87: Maintenance Safety Information

    Maintenance Safety Information General Maintenance Safety Information Damage to the high-voltage battery or Maintenance Safety Information WARNING high-voltage system can create a risk of For your personal safety, do not attempt electric shock, overheating, or fire. WARNING inspections or repairs not fully described High-voltage components are identified by labels.

  • Page 88: Maintenance Schedule

    Maintenance Schedule Maintenance Schedule Chart Mainten ance Schedule The scheduled maintenance or service must be performed in accordance with the chart below to keep your vehicle in top operating condition. The service intervals in this maintenance and service schedule are based on average driving conditions. Some items will need more frequent service if you drive in unique conditions, such as unusually wet or dusty areas.

  • Page 89: Full Inspection Service

     Inspect rear wheel for proper seating, lug nuts, tire wear, and tire pressure Your SOLO should be given a full inspection service every 5. Reinstall close-out panels and confirm no significant tire 10,000 miles (15,000 km) or every 12 months, whichever rubbing;...
  • Page 90 Maintenance Schedule 9. With liner removed and hood supported:  Inspect front wheels for proper seating, lug nuts, tire wear, and tire pressure  Inspect condition of brake lines, brake pads, and rotors  Inspect ball joints  Inspect steering rack boots for damage ...

  • Page 91: Under The Hood

    Under the Hood Maintenance Cover Component Locations Under the Hood To access some parts of the vehicle, the maintenance cover will need to be removed. 1. 12V battery positive (+) terminal (page 7-30) 2. Front brakes fluid reservoir (page 7-8) 3.

  • Page 92: Brakes

    The level of fluid can be seen through the body of the reservoir, Any proprietary brand of brake (or brake and clutch) fluid and should be between the MIN meeting DOT 4 specification can be used in your SOLO. and MAX marks.
  • Page 93 Brakes Topping up the brake fluid Only use new fluid from an airtight WARNING container. Fluid from open containers or fluid previously bled from the system will have absorbed moisture, which will adversely affect performance, and must not be used. Brake fluid will damage painted surfaces CAUTION and can cause body panels to crack.

  • Page 94: Windshield Washer And Wiper

    Any automotive windshield washer fluid that meets regional reservoir. freeze protection requirements can be used in your SOLO. 4. Position an absorbent cloth around the reservoir to absorb any washer fluid spillage.

  • Page 95: Checking The Wiper Blade

    Windshield Washer and Wiper Checking the Wiper Blade Removing the wiper blade Only use cleaning products that have CAUTION been approved for use on automotive glass and rubber. Inappropriate products may cause damage. Periodically check and clean the wiping edge of the wiper blade. Clean the blade edge by wiping with a soft cloth or sponge, using warm, soapy water.

  • Page 96: Coolant

    Coolant Battery and Drive Motor Coolant Coolant This vehicle uses a specific type of coolant CAUTION which should never be mixed with other coolant types. See “Parts and Maintenance Items”, page 7-2. Do not allow anyone except an ElectraMeccanica Authorized Service Provider to top off or change the coolant, as this could damage the system and void the warranty.

  • Page 97: Drive Belt

    Drive Belt Checking Drive Belt Tension Proper belt tension is essential for optimal operation of the Drive Belt drive system. Lack of belt tension can lead to “ratcheting,” which causes the teeth of the belt to slide over the teeth of the rear sprocket.

  • Page 98: Wheels And Tires

    Wheels and Tires Inspection and Maintenance  Do not run over curbs or hit the tire against the curb when Wheels an d Tires parking. Defective tires are dangerous. Do not WARNING drive if any tire is damaged, excessively Wheel alignment and tire balance worn, or inflated to an incorrect pressure.
  • Page 99 Wheels and Tires Tire wear Age degradation The tires should be regularly checked for Tires degrade over time due to the effects of ultraviolet light, WARNING wear and to make sure that there are no extreme temperatures, high loads, and environmental cuts, bulges or exposure of the ply/cord structure.
  • Page 100 Wheels and Tires Punctured tires Tire repair canister Do not drive the vehicle with a punctured Driving on a flat tire will cause permanent WARNING WARNING tire. Even if the punctured tire has not damage to the tire. Reinflating a tire after deflated, it is unsafe to use, since the tire may deflate it has been driven on while severely underinflated or flat may suddenly at any time.

  • Page 101: Tire Pressures

    Wheels and Tires Tire Pressures Checking and adjusting tire pressures This vehicle does not have a Tire Pressure Underinflation is the most common cause WARNING Monitoring System (TPMS). Tire WARNING of tire failure and may result in severe tire pressures should be checked with each pre-drive inspection, cracking and tread separation (i.e.

  • Page 102: Replacement Wheels And Tires

    5 psi (34 kPa). Return Ideally, you should replace tires in axle sets; in the case of your SOLO, this applies only to the front tires. When tires are tire pressure to the normal recommendations when ambient replaced, the wheels should always be balanced and the temperatures increase.

  • Page 103: Tire Markings

    Wheels and Tires Tire Markings safety standard certification and in case of a recall. 1. Tire category P indicates that the tire is for passenger vehicles. Note: Not all manufacturers show the tire category in the TIN. 2. Tire width This three-digit number gives the width in millimeters of the tire from sidewall edge to sidewall edge.
  • Page 104 Wheels and Tires 5. Wheel diameter 8. US DOT Tire Identification Number (TIN) This two-digit number is the diameter of the wheel rim in This begins with the letters “DOT” and indicates that the tire inches. meets all federal standards. The next two numbers or letters are the plant code where it was manufactured, and the last four 6.

  • Page 105: Uniform Tire Quality Grading

    Wheels and Tires Uniform Tire Quality Grading 12. Temperature grade This indicates the tire's heat-resistance grading. The tire’s The following information relates to the tire grading system resistance to heat is grade A, B, or C, with A indicating the developed by the National Highway Traffic Safety greatest resistance to heat.
  • Page 106 Wheels and Tires Traction The grade C corresponds to a level of test performance which all passenger car tires must meet under the Federal Motor The traction grade assigned to this tire is WARNING Safety Standard No. 109. based on straight-ahead braking traction tests, and does not include acceleration, cornering, Grades B and A represent higher levels of performance on the hydroplaning, or peak traction characteristics.

  • Page 107: Tires And Wheels Glossary

    Wheels and Tires Tires and Wheels Glossary kPa (kilo pascal) A metric unit used to measure pressure. One kilo pascal equals Accessory weight approximately 0.145 PSI. The combined weight (in excess of those items replaced) of Maximum inflation pressure items available as factory installed equipment. The maximum pressure to which the tire should be inflated.
  • Page 108 Wheels and Tires Recommended tire inflation pressure Tire inflation pressure, established by ElectraMeccanica, which is based on the type of tires that are mounted on the vehicle at the factory. This information can be found on the Tire and Loading Information label located on the frame of the right door.

  • Page 109: Lights And Fuses

    Lights and Fuses Headlight/Bulb Replacement Fuses L ights an d Fuses Always use the recommended fuse. A The lights on your vehicle are a mixture of long-life Light WARNING Emitting Diodes (LED) and halogen bulbs, which are not specification list can be found inside each repairable or user-replaceable.

  • Page 110: Accessing The Fuse Centers

    Lights and Fuses Accessing the Fuse Centers To access the interior fuse center: 1. Locate the access panel, which is in the wall of the footwell, Note: For your reference, a diagram of the fuse center layout is to the right of the accelerator pedal. printed on the inside of each cover.

  • Page 111: Under-Hood Fuse Center

    Lights and Fuses Under-Hood Fuse Center Note: A fuse-pulling tool is stored in the middle of the fuse center. Note: There are four spare fuses (SP) of varying ratings grouped together toward the upper left side of the fuse center. Fuse Rating Usage...
  • Page 112 Lights and Fuses Fuse Rating Usage IB01 Front Radiator Fan IB02 Remote Battery Terminal IB03 Electronic Parking Brake Motor IB04 Distribution 1 IB05 Distribution 2 Relay Usage Motor Controller Pump Relay Battery Cooling Pump Relay AC Wakeup Relay Low Beam Relay Auxiliary Low Beam Relay High Beam Relay Front Radiator Fan Relay...

  • Page 113: Interior Fuse Center

    Lights and Fuses Interior Fuse Center Fuse Rating Usage Power Window (Left) Display Radio/Mirror Control Thermal Management System Radio Display/OBDII Interior Lamp Wiper Note: There are spare fuses (SP) of varying ratings in the blank positions and the lower positions of the fuse center. Power Door Lock Power Window (Right) Mirror Defrost...

  • Page 114: Batteries

    Batteries Batteries “About the High-Voltage Battery”, page 5-2 for more Batteries information. 2. Low-voltage 12V The 12V accessory battery is located inside the vehicle, to the right of the accelerator pedal. About the 12V Battery Your vehicle is equipped with a maintenance-free 12V accessory battery, which powers all of the standard 12V on-board electronics and the built-in charging system for the high-voltage battery.

  • Page 115: Charging The 12V Battery

    Batteries Charging the 12V Battery severe damage to your vehicle, which would not be covered under the warranty. Never attempt to charge the 12V battery WARNING In certain circumstances (e.g. leaving the vehicle idle or in while the high-voltage battery is being storage for too long), the 12V battery may have an insufficient charged.
  • Page 116 Batteries Locating the 12V battery terminals Your vehicle’s 12V battery terminals are located under the hood as follows: 1. The positive (+) terminal is located behind the fluid reservoirs. Remove the cap to expose the terminal. 2. The negative (-) terminal is located near the base of the fuse box.
  • Page 117 Batteries Charging the 12V battery Some battery chargers (e.g. trickle chargers) can safely be left connected for months without harming your 12V battery, while Before connecting a charger, ensure that WARNING others may only be left connected for much shorter periods. your vehicle is powered OFF with the Read your charger's manual for details.
  • Page 118 Batteries 7. Check the charger's display to ensure it is charging properly. If the battery fails to begin charging after a few minutes:  Most chargers have an amp meter that reads higher on a dead battery, and lower to 0 on a fully-charged one. If the meter reads low, the battery may not need a charge.

  • Page 119: Remote Keyless Entry (Rke) Transmitter Battery Replacement

    Batteries Remote Keyless Entry (RKE) Transmitter Battery Replacement If swallowed, a battery can cause internal WARNING burns, severe injury, or death. Keep batteries out of reach of children. Seek medical attention immediately if a battery is swallowed. Environmental Notice: Refer to local regulations when disposing of batteries.
  • Page 120 Batteries 5. Slide the old battery sideways out of the holder, observing the +/- symbols on the battery, and replace with a new battery. 6. Reassemble the remote transmitter. 7. Test the operation of the remote transmitter. See “Remote Transmitter”, page 4-26.

  • Page 121: Cleaning And Care

    Cleaning and Care Washing the Vehicle Note: It is recommended to use a garden hose to wash your Clean ing and Care vehicle. High-pressure washers (like those at self-service car Improper cleaning can damage electrical washes) can damage certain parts. CAUTION components, cowlings, panels, and other plastic parts.

  • Page 122: Floor Mat

    Using a genuine SOLO floor mat can extend the life of the vehicle’s carpet and make it easier to clean. The mat should be cleaned regularly and replaced if it becomes worn or damaged.

  • Page 123: Parking And Long-Term Storage

    (see table). high-voltage battery is above 70% or below 30%.  Connect a trickle charger to the 12V battery terminals to Storing your SOLO requires certain maintenance procedures maintain battery health during storage. See “Charging the before, during, and after storage in order to maintain battery 12V Battery”, page...
  • Page 124 Cleaning and Care During storage The high-voltage battery will need to have its charge level checked monthly and maintained according to the previous table. To maintain the charge level during storage: 1. Disconnect the trickle charger from the 12V battery. 2.

  • Page 125: Vehicle Lifting Points

    Vehicle Lifting Points Jacking and Lifting the Vehicle Vehicle Lifting Poin ts Never raise the vehicle when the charge WARNING cable is connected, even if charging is not in progress. Always disconnect the charge cable before raising the vehicle. The illustrated lifting points are the only WARNING approved lifting points for your vehicle.

  • Page 126: Vehicle Recovery

    Vehicle Recovery Transporting the Vehicle Preparing the vehicle for loading Vehicle Recovery Before loading your vehicle, follow these steps: Never allow passengers to ride on a trailer WARNING 1. Turn the key switch to the ON position. See “Key Switch”, or flatbed transporter, or in a trailered page 4-6.
  • Page 127 Vehicle Recovery Loading the vehicle 5. Secure all cargo and other items, or remove them from the vehicle. 6. Ensure that the hood, trunk, and both doors are closed securely. 7. Block all wheels at the front and rear of each tire. Use the two lower control arms (illustrated) as the hook/ attaching points to pull the vehicle onto a trailer or transporter.

  • Page 128: Using The Recovery Eye

    Vehicle Recovery Using the Recovery Eye In the event that your vehicle needs to be pulled onto a flatbed trailer or transporter, a recovery eye assembly is supplied for A towing line under tension is hazardous; this purpose. Once assembled, a towing line (e.g. a strap, chain, WARNING if it fails, it can strike people and cause or cable) can be attached to the recovery eye and used to pull...
  • Page 129 Vehicle Recovery 4. Check the recovery eye to ensure it is securely fastened, then attach the towing line. 5. Release the Electronic Parking Brake (EPB) before pulling the vehicle. See “Electronic Parking Brake (EPB)”, page 4-18. 2. The mounting point for the recovery eye is behind a cover 10°...
  • Page 130 Vehicle Recovery 7-46...

  • Page 131: Customer Information

    Customer Assistance To find your local ElectraMeccanica Authorized Service Customer Information Customer Information Provider, please check the SOLO app or go to: Please have the following available when contacting https://electrameccanica.com/service ElectraMeccanica, as they are essential to effectively and efficiently answer your questions or resolve your concerns.

  • Page 132: Reporting Safety Defects

    Customer Information Reporting Safety Defects Canada If you believe that your vehicle has a defect which could cause a United States collision or could cause injury or death, you should immediately If you believe that your vehicle has a defect which could cause a inform Transport Canada, in addition to notifying collision or could cause injury or death, you should immediately ElectraMeccanica.

  • Page 133: Service History

    Service History Service History Maintenance Record Service History 20,000 miles (30,000 km) or 24 months After you have had your SOLO serviced, please ensure that Odometer reading: Date: the appropriate maintenance record has been completed. Notes: Use the space under Notes to record issues you want to remind yourself about or mention at the next service.
  • Page 134 Service History 50,000 miles (75,000 km) or 60 months 80,000 miles (120,000 km) or 96 months Odometer reading: Date: Odometer reading: Date: Notes: Notes: Performed by: Performed by: 60,000 miles (90,000 km) or 72 months 90,000 miles (135,000 km) or 108 months Odometer reading: Date: Odometer reading:...

  • Page 135: Component Replacement Record

    Component Replacement Record Replacement Record Component Replacemen t Record Use the following table to keep a record of any components replaced (e.g. drive belt, brake pads, etc.). Component(s) replaced Odometer reading Date replaced...
  • Page 136 Component Replacement Record...
  • Page 137 Index Index Accessories ................1-5 Cabin Air conditioning ............. 4-29 Conditioning ..............4-29 Heat ................4-29 Recirculation ..............4-29 Light ................4-24 Ventilation ..............4-29 Charge cable ................ 5-3 Charging Back-up camera ..............4-17 12V ..................7-31 Cleaning ................7-38 Estimating charging time ..........
  • Page 138 Index Hood ................... 4-28 Horn ..................4-4 Electric mirrors ..............4-5 Electric windows ..............4-31 Electronic Parking Brake (EPB) ........4-18 Indicator lights ..............4-14 Exterior lights ..............4-20 Daytime running lights ..........4-14 External ambient temperature .......... 4-9 Door ajar ................. 4-14 Electronic parking brake ..........
  • Page 139 Index Lifting the vehicle .............. 7-41 Radio ..................4-2 Lights Rear view camera ............... 4-17 Exterior ................4-20 Cleaning ................7-38 Interior ................4-24 Recovery eye ..............7-44 Locking the vehicle ............4-27 Remote Keyless Entry (RKE) ......... 4-26 Long-term storage ............. 7-39 Locking the vehicle ............
  • Page 140 Index Seat belts Replacement of ............... 7-18 Care ................... 3-7 Wear indicators ..............7-15 Fastening and releasing ............ 3-5 Transporting the vehicle ........... 7-42 Testing ................3-7 Trip distance reset .............. 4-12 Wearing seat belts correctly ..........3-4 Trunk .................. 4-34 Wearing when pregnant ...........
  • Page 141 Index Warning labels ..............1-5 Warning lights ..............4-15 Accessory battery ............4-15 Battery management system ........4-16 Brake warning ..............4-15 Charging fault ..............5-6 Combinations ..............4-16 Electronic power steering ..........4-16 EPB warning ..............4-15 Fault .................. 4-15 Washing the vehicle ............
  • Page 142 Index...
  • Page 144 EMV Automotive USA Inc. 11647 Ventura Boulevard Studio City, CA 91604 +1 888 457 7656 info@electrameccanica.com https://electrameccanica.com...

Table of Contents
