Mazda MX-30 2022 Owner's Manual Leaflet

Table of Contents

Quick Links

This leaﬂet contains revised information concerning the low battery charge

warning.

Please keep this leaﬂet with the owner's manual.

MAZDA MX-30 Feuillet du Manuel Conduite et Entretien

Ce feuillet contient des informations révisées concernant l'avertissement de

faible charge de la batterie.

Prière de conserver ce feuillet avec le Manuel Conduite et Entretien.

Form No. P023/21

MAZDA MX-30 Owner's Manual Leaﬂet

Printed in Japan

Table of Contents

Chapters

Table of Contents

Summary of Contents for Mazda MX-30 2022

Page 1 This leaﬂet contains revised information concerning the low battery charge warning. Please keep this leaﬂet with the owner's manual. MAZDA MX-30 Feuillet du Manuel Conduite et Entretien Ce feuillet contient des informations révisées concernant l'avertissement de faible charge de la batterie.
Page 2 Content This message is indicated when the power There is no need to contact an consumption exceeds a Authorized Mazda Dealer. certain amount such as by Battery Saving Mode. Drive Drive the vehicle for 5 minutes repeatedly opening/closing or longer to charge the 12V...
Page 3 électrique Il n'est pas nécessaire de dépasse une certaine contacter un concessionnaire quantité, par exemple lorsque agréé Mazda. Conduire le les portières ou le hayon sont véhicule pendant au moins 5 Mode économie de la ouverts/fermés de manière minutes pour charger la batterie.
Page 4 Mazda. Should you resell the vehicle, leave this manual with it for the next owner. All speciﬁcations and descriptions are accurate at the time of printing. Because improvement is a con- stant goal at Mazda, we reserve the right to make changes in speciﬁcations at any time without notice and without obligation.
Page 5 “Do not do this” or “Do not let the manual to best explain how to this happen”. enjoy your Mazda. By reading your manual, you can ﬁnd out about the features, important safety information, and driving under various road conditions.
Page 6 How to Use This Manual Please refer to the manual for a detailed explanation. Index: A good place to start is the Index, an alphabetical listing of all information in your manual.
Page 7 MEMO...
Page 8 Table of Contents Pictorial Index Interior, exterior views and part identiﬁcation of your Mazda. Essential Safety Equipment Important information about safety equipment, including seats, seat belt system, child-restraint systems and SRS air bags. Before Driving Use of various features, including keys, doors, mirrors and windows.
Page 9 Pictorial Index Interior, exterior views and part identiﬁcation of your Mazda. Interior Overview......1-2 Interior Equipment (View Interior Equipment (View D)........1-6 A)......... 1-2 Interior Equipment (View Interior Equipment (View E)......... 1-7 B)......... 1-4 Interior Equipment (View Exterior Overview..... 1-8 C).........1-5...
Page 10 ③ Turn and lane-change signals............. page 4-39 ④ Audio remote control switches............page 5-22 ⑤ INFO switch..................page 4-11 ⑥ Mazda Radar Cruise Control with Stop & Go function (MRCC with Stop & Go function) switches................page 4-114 ⑦ Traffic Jam Assist (TJA) switches............page 4-122 ⑧...
Page 11 Pictorial Index Interior Overview ▼ Interior Equipment (View A-type B) ① Door-lock knob................page 3-39 ② Door-lock switch................page 3-37 ③ Outside mirror switches..............page 3-44 ④ i-ACTIVSENSE OFF switch..............page 4-70 ⑤ 360° view monitor switch..............page 4-151 ⑥ Parking sensor OFF switch............... page 4-201 ⑦...
Page 12 Interior Equipment (View B) ▼ Interior Equipment (View B) ① Instrument cluster................page 4-9 ② Active driving display................. page 4-24 ③ Mazda Connect................page 5-14 ④ Climate control system................ page 5-2 ⑤ Rear window defogger switch............page 4-45 ⑥ Glove compartment................page 5-45 ⑦...
Page 13 Pictorial Index Interior Overview Interior Equipment (View C) ▼ Interior Equipment (View C) ① Head restraint................... page 2-18 ② Front seat................... page 2-4 ③ Seat belt................... page 2-26 ④ Bottle holder..................page 5-43 ⑤ Vanity mirror..................page 5-36 ⑥ Sunvisor................... page 5-36 ⑦...
Page 14 Pictorial Index Interior Overview Interior Equipment (View D) ▼ Interior Equipment (View D) ① Push knob..................page 2-15 ② Head restraint................... page 2-18 ③ Rear coat hook..................page 5-44 ④ Overhead light (rear)................. page 5-37 ⑤ Assist grip..................page 5-44 ⑥ Center console................. page 5-46 ⑦...
Page 15 Pictorial Index Interior Overview Interior Equipment (View E) ▼ Interior Equipment (View E) ① Luggage compartment cover.............. page 3-42 ② Anchor brackets................page 2-41 ③ Cargo sub-compartment..............page 5-46 ④ Cargo securing loops................. page 5-46 ⑤ Luggage compartment light..............page 5-37 The equipment and installation position varies by vehicle...
Page 16 Pictorial Index Exterior Overview ① Windshield wiper blades..............page 6-14 ② Moonroof..................page 3-51 ③ Door....................page 3-33 ④ Window................... page 3-49 ⑤ Touch sensor..................page 3-35 ⑥ Outside mirror.................. page 3-44 ⑦ Charge lid..................page 3-14 ⑧ Liftgate..................... page 3-41 ⑨ Electric liftgate opener............... page 3-41 ⑩...
Page 17 Essential Safety Equipment Important information about safety equipment, including seats, seat belt system, child-restraint systems and SRS air bags. Seats........2-2 Child-Restraint System Seat Precautions....2-2 Installation......2-39 Front Seat......2-4 Child-Restraint System Suitability Rear Seat......2-15 for Various Seat Positions..2-40 Head Restraints....2-18 Installing Child-Restraint Systems.......2-41 Seat Warmer/Heated Steering...
Page 18 Consult an Authorized Mazda Dealer if seatback. there is any need to remove or reinstall the front seats. Never allow children to adjust a seat:...
Page 19 Essential Safety Equipment Seats Do not place an object such as a Driving with a passenger on the folded cushion between the seatback and seatback is dangerous. Allowing a child your back: to sit up on the folded seatback while Putting an object such as a cushion the vehicle is moving is particularly between the seatback and your back is...
Page 20 To prevent the battery from  The adjustments for the driving running down, avoid using the position recommended by Mazda are power adjustment when the EV done using the following procedures. system is stopped. The adjuster 1. Moving the steering wheel and seat uses a large amount of electrical to their default positions.
Page 21 Essential Safety Equipment Seats Manual seat locked in place by attempting to push it forward and backward. Power seat 1. Seat Slide To move a seat forward or backward, raise the lever and slide the seat to the desired position and 1.
Page 22 Press the rear part of the switch to decrease ﬁrmness. Before making adjustments to the driving position recommended by Mazda Before making adjustments, move the steering wheel and seat to their default How to move a driver’s seat to its positions.
Page 23 Essential Safety Equipment Seats angle where your waist feels slightly any feeling of cramping in your cramped. waist. 1. Manual Seat 1. Manual Seat 2. Power Seat 2. Power Seat 2. Move the seatback backward to a Adjusting the seat position forward comfortable seated posture without and back (sliding) Adjust the seat to the position best for...
Page 24 Essential Safety Equipment Seats possible until you feel a slight until you no longer feel cramping in cramping in your ankle. your ankle. 1. Manual Seat 1. Manual Seat 2. Power Seat 2. Power Seat 4. With your heel set on the ﬂoor, make sure you can move your foot 3.
Page 25 Essential Safety Equipment Seats edge area of the hood surface from 2. Depress the accelerator pedal and the windshield. make sure that you no longer feel cramping in the back of your knees. 1. Manual Seat 2. Power Seat 1. Manual Seat 2.
Page 26 Essential Safety Equipment Seats towards you to the position of your Refer to Adjusting the Driver's Seat wrists. on page 2-4. Active driving display (display  position, brightness level, display information) Refer to Active Driving Display on page 4-24. Outside mirror angle ...
Page 27 Essential Safety Equipment Seats 6. Do the following operation within 5 The driving position adjustment is  seconds after the sound is activated canceled in the following cases: to program the driving position. The seat adjustment switch on the  Programming to a position driver's seat is operated.
Page 28 Essential Safety Equipment Seats adjusted active driving display is To change the seatback angle, lean activated.) forward slightly while raising the Outside mirrors lever. Then lean back to the desired  position and release the lever. A sound is activated when the Make sure the lever returns to its adjustment is completed.
Page 29 Essential Safety Equipment Seats When returning the operated seat to Refer to Freestyle Doors on page its sitting position, make sure that the 3-39. seat is ﬁrmly locked and the red indication on the walk in strap is not Before getting in or out of the rear seat, visible (Manual seat): open the rear door.
Page 30 Essential Safety Equipment Seats side of the front seat, or the walk in When getting out of the vehicle switch. Manual seat The seatback folds forward while the upper side of the angle switch is 1. The seatback can be folded forward pressed, and the seat slides forward and the seat can be slid forward by while the upper side of the slide...
Page 31 Essential Safety Equipment Seats 2. Angle switch Rear Seat 3. Slide switch NOTE ▼ Split Folding While an occupant is not seated  By lowering the rear seatbacks the on the driver’s seat, the seat can luggage compartment space can be be moved using the walk in expanded.
Page 32 Essential Safety Equipment Seats When transporting cargo, do not To return the seatback to its upright allow the cargo to exceed the height position: of the seatbacks. Transporting cargo stacked higher than WARNING the seatbacks is dangerous as visibility to the rear and sides of the vehicle is When returning a seatback to its reduced which could interfere with upright position, make sure the...
Page 33 Essential Safety Equipment Seats raise the seatback while preventing WARNING the seat belt from being caught in the seatback. Never put your hands and ﬁngers around the moving parts of the seat and armrest: Putting your hands and ﬁngers around the moving parts of the seat and armrest is dangerous as they could get injured.
Page 34 Essential Safety Equipment Seats Front seats Head Restraints ▼ Head Restraints Your vehicle is equipped with head restraints on all outboard seats and the rear center seat. The head restraints are intended to help protect you and the passengers from neck injury. WARNING Always drive with the head restraints installed when seats are being used...
Page 35 Essential Safety Equipment Seats WARNING WARNING Always drive with the head restraints Always drive with the head restraints installed when seats are being used in their upright positions when the and make sure they are properly rear seats are occupied, and make installed: sure they are securely locked in place: Driving with the head restraints not...
Page 36 Essential Safety Equipment Seats To fold the head restraint, pull the strap. To return the head restraint to its upright position, lift it upward. After lifting up the head restraint to its original position, make sure that it is secured by lightly moving it forward and back.
Page 37 Essential Safety Equipment Seat Warmer/Heated Steering Wheel Seat Warmer CAUTION Do not use organic solvents such as ▼ Seat Warmer benzene or gasoline to clean the seat. The front seats can be warmed up It may damage the seat surface and the while the EV system is operating.
Page 38 Auto mode operates when auto mode When each icon for the setting screen is enabled in the Mazda Connect is touched or swiped, the temperature settings. level can also be changed on the Refer to the Settings section in the setting screen.
Page 39 Essential Safety Equipment Seat Warmer/Heated Steering Wheel Heated Steering Wheel If the is operated during  auto mode, the seat warmer on the ▼ Heated Steering Wheel side where the icon was operated switches to manual mode. To return The grips on the left and right of the to auto mode, press the AUTO steering wheel can be warmed up switch.
Page 40 Auto mode operates when auto mode is enabled in the Mazda Connect When the is touched or swiped settings. downward, the setting screen of the Refer to the Settings section in the steering warmer can be displayed.
Page 41 Essential Safety Equipment Seat Warmer/Heated Steering Wheel NOTE When auto mode is enabled using  Mazda Connect and auto mode is not operating, the (gray) is displayed on the setting screen of the steering warmer. When the is operated during auto ...
Page 42 So, if your seat accidents and sudden stops. Mazda belt is twisted, you must straighten the recommends that the driver and all seat belt to remove any twists and to passengers always wear seat belts.
Page 43 In a collision, load limiter has been expended: this would concentrate the impact Always have an Authorized Mazda force directly on the abdominal area, Dealer immediately inspect the seat causing serious injury. Wear the lap...
Page 44 Essential Safety Equipment Seat Belt Systems Persons with serious medical convert it back to emergency locking conditions also should wear seat belts. mode and then extend it around you Check with your doctor for any special again. instructions regarding speciﬁc medical ▼...
Page 45 If a belt does not fully retract, inspect it for kinks and twists. If it is still not retracting properly, have it inspected at an Authorized Mazda Dealer. ▼ Front Shoulder Belt Adjuster 1. Keep low on hip bone 2. Take up slack The front seat belts have a front 3.
Page 46 Essential Safety Equipment Seat Belt Systems To raise Seat Belt Warning To heighten the seat belt, slide the Systems front shoulder belt adjuster upward. ▼ Seat Belt Warning Systems If it detects that the occupant seat belt is unfastened, the warning light or beep alerts the occupant.
Page 47 Even if the pretensioners have not ﬁred, the load limiting function must Pretensioners: be checked by an Authorized Mazda When a collision is detected, the Dealer. pretensioners deploy simultaneously WARNING with the air bags.
Page 48 The pretensioner system may not  load limiter has been expended: operate depending on the type of Always have an Authorized Mazda the collision. For details, refer to the Dealer immediately inspect the seat SRS Air Bag Deployment Criteria belt pretensioners and air bags after (page 2-61).
Page 49 Dealer. extender in a different vehicle or seat. This extender will be only for you and If you sell your Mazda, do not leave for the particular vehicle and seat. Even your seat belt extender in the vehicle. if it plugs into other seat belts, it may...
Page 50 Essential Safety Equipment Seat Belt Systems Do not leave a seat belt extender connected to the buckle: Leaving a seat belt extender connected to the buckle without using the seat belt is dangerous. When the seat belt extender is connected to the driver's seat belt buckle (or front passenger's seat belt buckle), the SRS driver's (or front passenger's) air bag system will...
Page 51 To reduce the chance of injuries ▼ Child-Restraint Precautions caused by deployment of the front passenger air bag, the front passenger Mazda strongly urges the use of seat weight sensors occupant child-restraint systems for children classiﬁcation sensor works as a part of small enough to use them.
Page 52 Essential Safety Equipment Child Restraint Never use a rear-facing child-restraint WARNING system in the front seat with an air bag that could deploy: Use the correct size child-restraint Rear-facing child-restraint systems on system: the front seat are particularly For effective protection in vehicle dangerous even though you may feel accidents and sudden stops, a child assured that a front passenger air bag...
Page 53 Essential Safety Equipment Child Restraint The seat is washed. Do not install a front-facing Liquids are spilled on the seat. child-restraint system on the front The front passenger seat is moved passenger seat unless it is unavoidable: backward, pushing into luggage or In a collision, the force of a deploying other items placed behind it.
Page 54 Child Restraint Do not allow a child or anyone to NOTE lean over to or against the side Your Mazda is equipped with LATCH window of a vehicle with side and lower anchors for attachment of curtain air bags: specially designed LATCH...
Page 55 Essential Safety Equipment Child Restraint Infant seat Child-Restraint System An infant seat provides restraint by Installation bracing the infant's head, neck and back against the seating surface. ▼ Categories of Child-Restraint Systems NOTE When purchasing, ask the manufacturer of the child-restraint system which type of child-restraint system is appropriate for your child and vehicle.
Page 56 ▼ Child-Restraint System Suitability for Various Seat Positions Regarding child-restraint systems  which can be installed to your Mazda, consult an Authorized Mazda Dealer. A child-restraint system with a  support leg cannot be installed on the rear center seat position.
Page 57 In your Mazda, tether. tethered child-restraint systems can only be accommodated in the three positions on the rear seat.
Page 58 Essential Safety Equipment Child Restraint Always install the head restraint and WARNING adjust it to the appropriate position after removing the child-restraint Always attach the tether strap to the system: correct tether anchor position: Driving with the head restraint Attaching the tether strap to the removed is dangerous as impact to the incorrect tether anchor position is occupant's head cannot be prevented...
Page 59 Essential Safety Equipment Child Restraint shoulder belt. See the NOTE manufacturer's instructions on the Inspect this function before each  child-restraint system for belt use of the child-restraint system. routing instructions. You should not be able to pull the 4. To get the retractor into the shoulder belt out of the retractor automatic locking mode, pull the while the system is in the...
Page 60 Essential Safety Equipment Child Restraint Always remove the head restraint and Always install the head restraint and install child-restraint system (except adjust it to the appropriate position when installing a backless booster after removing the child-restraint seat): system: Installing a child-restraint system Driving with the head restraint without removing the head restraint is removed is dangerous as impact to the...
Page 61 Mazda vehicles equipped with side death to the child. Even though you air bag will have a "SRS AIRBAG" tag may feel assured that the front...
Page 62 Essential Safety Equipment Child Restraint Always remove the head restraint and 4. Place the child-restraint system on install child-restraint system (except the seat without putting your when installing a backless booster weight on the seat and fasten the seat): seat belt. See the manufacturer's Installing a child-restraint system instructions on the child-restraint without removing the head restraint is...
Page 63 ▼ Using LATCH Lower Anchor deactivation indicator light does not illuminate: Your Mazda is equipped with LATCH lower anchors for attachment of specially designed LATCH child-restraint systems in the rear seats. Both anchors must be used, otherwise the seat will bounce around and put the child in danger.
Page 64 Essential Safety Equipment Child Restraint An unsecured child-restraint system is WARNING dangerous. In a sudden stop or a collision it could move causing serious Follow the manufacturer's injury or death to the child or other instructions for the use of the occupants.
Page 65 Essential Safety Equipment Child Restraint Refer to Adjusting the Front 6. If your child-restraint system came Passenger's Seat on page 2-12. equipped with a tether, that means 2. Make sure the seatback is securely it is very important to properly latched by pushing it back until it is secure the tether for child safety.
Page 66 Essential Safety Equipment Child Restraint Always attach the tether strap to the LATCH lower anchor. If your correct tether anchor position: child-restraint system has a tether, it Attaching the tether strap to the must also be used for your child's incorrect tether anchor position is optimum safety.
Page 67 Essential Safety Equipment Child Restraint 3. Forward Always attach the tether strap to the correct tether anchor position: Attaching the tether strap to the incorrect tether anchor position is dangerous. In a collision, the tether strap could come off and loosen the child-restraint system.
Page 68 Essential Safety Equipment SRS Air Bags designed for air bag inﬂation, such as Supplemental Restraint rear impact. System (SRS) Precautions Reduce the possibility of injuries in  frontal, near frontal or side collisions ▼ Supplemental Restraint System or roll-over accidents that are not (SRS) Precautions severe enough to activate the air bags.
Page 69 Essential Safety Equipment SRS Air Bags child-restraint system manufacturer's Rear-facing child-restraint systems on instructions. the front seat are particularly dangerous even though you may feel WARNING assured that a front passenger air bag will not deploy based on the fact that the front passenger air bag Seat belts must be worn in air bag deactivation indicator light illuminates.
Page 70 Do not use seat covers on the front Do not use tires or wheels other than seats and rear seats equipped with those speciﬁed for your Mazda: in-seat side air bags. Do not hang any backpacks, bags or pouches that cover the sides of the seats that block the side air bags.
Page 71 SRS Air Bags Use of any tire or wheel other than Modifying a front door or leaving any those speciﬁed for your Mazda (page damage unrepaired is dangerous. Each 9-5) is dangerous. Use of such front door has a side crash sensor as a...
Page 72 Should you sell your Mazda, we urge  which could result in serious injury or you to tell the new owner of its air death.
Page 73 Essential Safety Equipment SRS Air Bags Supplemental Restraint System Components ▼ Supplemental Restraint System Components 1. Side and curtain inﬂators and air bags 2. Side crash sensors 3. Roll-over sensor, crash sensors, and diagnostic module (SAS unit) 4. Driver/Front passenger inﬂators and air bags 5.
Page 74 Work impacts, it deploys with more energy. ▼ How the SRS Air Bags Work Your Mazda is equipped with the following types of SRS air bags. SRS air bags are designed to work together with the seat belts to help to reduce injuries during an accident.
Page 75 Essential Safety Equipment SRS Air Bags If the air bag crash sensors receive a passenger occupant classiﬁcation frontal impact of greater than system (page 2-64). moderate force, the knee air bags deploy immediately to reduce impact to the driver and front passenger's legs.
Page 76 Essential Safety Equipment SRS Air Bags In a roll-over: In response to a vehicle roll-over, both curtain air bags inﬂate. Both curtain air bags will deploy after the roll-over accident is detected. ▼ Warning Light/Beep A system malfunction or operation conditions are indicated by a warning.
Page 77 Essential Safety Equipment SRS Air Bags SRS Air Bag Deployment Criteria ▼ SRS Air Bag Deployment Criteria This chart indicates the applicable SRS equipment that will deploy depending on the type of collision. (The illustrations are the representative cases of collisions.) Types of collision SRS equip- A roll-over/near...
Page 78 Essential Safety Equipment SRS Air Bags Types of collision SRS equip- A roll-over/near A severe frontal/near frontal A severe side col- ment A rear collision collision lision roll-over Front seat belt preten- sioner Driver air ― ― No air bag and Front pas- front seat belt ―...
Page 79 Essential Safety Equipment SRS Air Bags enough to deploy the SRS air bag Limitations to SRS Air Bag equipment. ▼ Limitations to SRS Air Bag Impacts involving trees or poles In severe collisions such as those described previously in "SRS Air Bag Deployment Criteria", the applicable SRS air bag equipment will deploy.
Page 80 Essential Safety Equipment SRS Air Bags not be detected as severe enough to Driver and Front deploy the SRS air bag equipment. Passenger Occupant Classiﬁcation System Side impacts involving trees or poles ▼ Driver and Front Passenger Occupant Classiﬁcation System First, please read "Supplemental Restraint System (SRS) Precautions"...
Page 81 Essential Safety Equipment SRS Air Bags the front passenger air bag bags, and seat belt pretensioners will deactivation indicator light illuminates. not deploy during a collision. To reduce the chance of injuries caused by deployment of the front passenger air bag, the system deactivates the front passenger front and side air bags and knee air bags, and also the seat belt pretensioner...
Page 82 Authorized Mazda Dealer as soon as possible. The system may not work properly in an accident. WARNING...
Page 83 Essential Safety Equipment SRS Air Bags Luggage or other items placed under A rear passenger or luggage push or the front passenger seat or between pull down on the front passenger the front passenger seat and driver seatback. A rear passenger steps on the front seat that push up the front passenger seat bottom.
Page 84 The front passenger air bag  possible. Consult an Authorized deactivation indicator light may Mazda Dealer as soon as possible. illuminate repeatedly if luggage or ▼ Driver and Front Passenger Buckle other items are put on the front passenger seat, or if the temperature...
Page 85 Essential Safety Equipment SRS Air Bags Constant Monitoring ▼ Constant Monitoring The following components of the air bag systems are monitored by a diagnostic system: Front air bag sensors  Crash sensors, and diagnostic  module (SAS unit) Side crash sensors ...
Page 86 MEMO 2-70...
Page 87: Table Of Contents
Before Driving Use of various features, including keys, doors, mirrors and windows. Electric Vehicles......3-2 Windows....... 3-49 Electric Vehicles..... 3-2 Power Windows....3-49 Charging......3-10 Moonroof ......3-51 Keys........3-25 Security System.......3-54 Keys........3-25 Modiﬁcation and Add- Keyless Entry System.....3-27 On Equipment.....3-54 Immobilizer System....3-54 Advanced Keyless Entry System........3-31...
Page 88: Electric Vehicles
Before Driving Electric Vehicles Electric Vehicles ▼ Electric Vehicles Electric vehicles are driven by motor power using the electrical power stored in the high voltage battery. This vehicle is an eco-friendly vehicle which emits no exhaust gas because fuel is not used. 1.
Page 89 Before Driving Electric Vehicles Approaching vehicle audible system The approaching vehicle audible system notiﬁes pedestrians of the vehicle approaching using a warning sound while driving at low speeds. Refer to Approaching Vehicle Audible System on page 3-9. ▼ Cautions on Use An electric vehicle has high voltage areas and high temperature areas.
Page 90 If the high voltage battery is used on a vehicle other than one equipped For vehicle maintenance or repairs, (including modiﬁed vehicles) with a consult an Authorized Mazda Dealer. high voltage battery, an electrical Technical knowledge and skill are shock accident, heat generation,...
Page 91 EV system may not start. problem. Contact an Authorized Mazda Dealer Motor operation sound. immediately.  Operation sound of coolant pump ...
Page 92 Before Driving Electric Vehicles Vibration of the brake pedal might perform smooth starts, be felt under the following acceleration, and deceleration. conditions: Try to drive maintaining a constant  speed and avoid speeding. The power switch is switched ON.  Inspect the tire pressures regularly ...
Page 93 Before Driving Electric Vehicles ▼ Steering Wheel Paddle The steering wheel paddle is a function that makes it easy to adjust the vehicle speed according to the accelerator pedal operation. Acceleration/deceleration is possible according to the various driving conditions such as on an up or down slope, during traffic jams, or high-speed driving. WARNING Avoid using the steering wheel paddles when driving on wet roads, snow-covered roads, or icy roads:...
Page 94 Before Driving Electric Vehicles NOTE When the cruise control and the Mazda Radar Cruise Control with Stop & Go  function (MRCC with Stop & Go function), or the Traffic Jam Assist (TJA) is operating, the steering wheel paddle setting cannot be changed.
Page 95 Before Driving Electric Vehicles Particular driving situation 1. Driving on a downward slope or during traffic jams 2. Driving on an upward slope or expressways NOTE If the high voltage battery level is high or the high voltage battery temperature is ...
Page 96: Charging
Before Driving Electric Vehicles Charging ▼ Cautions Concerning Charging Otherwise, it could lead to an electrical shock resulting in an accident. WARNING Do not charge the high voltage battery outside if there is the For occupants who use any medical possibility of heavy rain, strong device such as an implanted-type winds, or lightning.
Page 97 Authorized Mazda Dealer. If the charge connector is removed ▼ Preparation Before Charging after the charging is ﬁnished, close the charge port cap immediately. If...
Page 98 Before Driving Electric Vehicles 1. Mazda Connect bag is facing toward the center of the luggage compartment. 1. Charge cable CAUTION Be careful when handling the storage bag because the hooks on the storage bag have sharp areas. If your hands or ﬁngers touch the sharp areas, your...
Page 99 1. Charge indicator though the driver’s door is unlocked, 2. Normal charge port consult an Authorized Mazda Dealer. 3. Normal charge port cap 4. Charge lid The conditions for locking the system 5. Quick charge port cap on the vehicle side can be changed.
Page 100 [Settings] in Mazda Connect. time. When the battery heater operates,  the charging time could take longer.
Page 101 Before Driving Electric Vehicles conditions, both the battery and situations, this may lead to a signiﬁcant ambient temperature will affect the increase in the charging time. required charging time and, in certain WARNING situations, this may lead to a signiﬁcant increase in the charging time.
Page 102 Before Driving Electric Vehicles 5. Connect the charge plug to the 3. Press the location shown in the outlet. ﬁgure to open the charge lid. 6. Connect the charge connector to the normal charge port. Charging starts after connection is completed.
Page 103 Before Driving Electric Vehicles CAUTION When operating a quick charger, always use the charger according to its instructions. If the quick charger is operated incorrectly, the quick charger or vehicle could be damaged. Make sure to lock all the doors before leaving the vehicle while charging.
Page 104 Turns on if there is a problem with the charging system and the charging port lid is opened or the charging connector is connected. (Red) Have your vehicle inspected by an Authorized Mazda Dealer. Multi-information Display When the driver's door is opened with the charge connector connected, the charging status is displayed on the multi-information display.
Page 105 Before Driving Electric Vehicles Power switch OFF 1. High voltage battery indication 2. Charging completion time Power switch ON 1. High voltage battery indication 2. Charging completion time Indication Content Displays while the charging timer is being canceled — Preparing to Charge and when the charging connector is connected.
Page 106 Before Driving Electric Vehicles ▼ Convenient Functions You can also select the lock conditions for the charging connector according Timer Charging to locations and situations. For the setting method, refer to Timer charging is a function which Charging Settings on page 3-21. charges the battery automatically according to a preset time.
Page 107 Selects desired vehicle charging days charging, and operate the air and times. conditioner remotely by using a Function Available setting changes Smartphone. Please refer to local Mazda website for 1 ---- more Connected Service information. 2 ---- ▼ Charging Settings 3 ---- Enable, Disa-...
Page 108 Before Driving Electric Vehicles Immediately after switching to surrounding environment. Check the actual  daylight savings, charging may occur remaining distance-to-full discharge. at the charging timer time set before If you change the distance unit after setting the switch to daylight savings until the Estimated Range, the Estimated Range the power switch is switched ON.
Page 109 Before Driving Electric Vehicles Setting example (if settings below are In this case, charging is done from made at 13 : 00 hours) the next day at 1 : 00 hours to 8 : 00 hours. However, if the Battery Available setting Charge Level reaches 100% is Function...
Page 110 Before Driving Electric Vehicles Available setting changes Charge connector remains unlocked at all times. High Voltage Battery Heater Conﬁgures the high voltage battery heater operation. Available setting changes Automatic, Off 3-24...
Page 111: Keys
The key (transmitter) contacts or is covered by a metal object. The key (transmitter) is near electronic devices such as personal computers. Non-Mazda genuine electronic equipment is installed in the vehicle. There is equipment which discharges radio waves near the vehicle.
Page 112 If your key (auxiliary key) is lost, consult an Authorized Mazda Dealer and have your code number ready. 1. Key code number plate Installing the auxiliary key 1.
Page 113: Keyless Entry System
Off (STOP) Warning Beep on page Additional keys can be obtained at 7-37.  an Authorized Mazda Dealer. Up to Key Removed from Vehicle Warning  6 keys can be used with the keyless Beep functions per vehicle. Bring all keys...
Page 114 A beep sound will be heard twice. Refer to the Settings section in the Mazda Connect Owner's Manual. To unlock the other doors and liftgate, press the unlock button again within 5 The operation indicator light ﬂashes seconds and two more beep sounds when the buttons are pressed.
Page 115 Refer to the Settings section in the Power saving function Mazda Connect Owner's Manual. By turning on the transmitter power (Auto re-lock function)  saving function, the advanced keyless After unlocking with the key, all the...
Page 116 Before Driving Keys 1. Press any of the buttons on the 1. Interior antenna transmitter to make sure that the 2. Operational range operation indicator light does not turn on/ﬂash. Without the advanced keyless 2. Press the lock button on the function transmitter 4 times within 3 seconds to turn on the operation...
Page 117: Advanced Keyless Entry System
If the system is deactivated, you will be unable to start WARNING the EV system by carrying the key. Consult an Authorized Mazda Dealer Radio waves from the key may affect for details. If the advanced keyless medical devices such as pacemakers:...
Page 118: Operational Range
Before Driving Advanced Keyless Entry System Next to a communication device Operational Range  such as a mobile phone ▼ Operational Range ▼ Locking Using Door-Lock Switch/ Unlocking Using Electric Liftgate The system operates only when the Opener driver is in the vehicle or within operational range while the key is being carried.
Page 119: Doors And Locks
Before Driving Doors and Locks After closing the doors and the Door Locks liftgate, always verify that they are securely closed: ▼ Door Locks Doors and the liftgate not securely closed are dangerous, if the vehicle is WARNING driven with a door and the liftgate not securely closed, the door and the Always take all children and pets with liftgate could open unexpectedly...
Page 120 Before Driving Doors and Locks In the storage compartments such This system automatically unlocks the  as the glove compartment or the doors, charge lid, and liftgate in the center console event the vehicle is involved in an Next to a communication device accident to allow passengers to get ...
Page 121 Before Driving Doors and Locks Unlocking NOTE If you attempt to open the driver’s door using an unauthorized auxiliary key, the key cylinder will spin around but the door will not unlock. ▼ Locking, Unlocking with Touch Sensor, Door Handle (With the advanced keyless function) The system may not operate normally ...
Page 122 The volume of the beep sound can  also be changed. Refer to the (Unlocking from the driver's door) Settings section in the Mazda The following locations are unlocked Connect Owner's Manual. by touching the sensing area of the The setting can be changed so that ...
Page 123  position other than off. The time required for the doors to lock automatically can be changed. Refer to the Settings section in the Mazda Connect Owner's Manual. ▼ Locking, Unlocking with 1. Unlock Transmitter 2. Lock The following locations can be locked/...
Page 124 The auto lock/unlock function settings can be changed. Refer to the Settings section in the Mazda Connect Owner's Manual. When locking using the door-lock switch, press the door-lock switch with all of the following conditions met and then close the liftgate.
Page 125 Before Driving Doors and Locks ▼ Locking, Unlocking with This does not operate the other door Door-Lock Knob locks. Operation from inside To lock any door from the inside, press the door-lock knob. To unlock, pull it outward. This does not operate the other door locks.
Page 126 Before Driving Doors and Locks 2. Pull the rear door handle and open CAUTION the rear door. Do not close the front door ﬁrst. Closing the rear door with the front door closed ﬁrst could damage or scratch the front door. When opening the rear door, do not close the front door.
Page 127: Liftgate
Do not modify or replace the liftgate unsecured in the luggage damper stay. Consult an Authorized compartment: Mazda Dealer if a liftgate damper Otherwise, the luggage may move or stay is deformed or damaged for collapse, resulting in injury or an reasons such as a collision or if there accident.
Page 128 Before Driving Doors and Locks A locked liftgate can also be opened Do not slam it. Pull up on the liftgate  while the key is being carried. to make sure it is secure. When opening the liftgate with the ...
Page 129 Before Driving Doors and Locks Make sure luggage and cargo are and remove the luggage secured before driving: compartment cover from the pins. Not securing cargo while driving is dangerous as it could move or be crushed during sudden braking or a collision and cause injury.
Page 130: Mirrors
Before Driving Mirrors 2. Press the adjustment switch to Mirrors adjust the angle of the outside mirror. ▼ Mirrors Before driving, adjust the inside and outside mirrors. ▼ Outside Mirrors WARNING Be sure to look over your shoulder before changing lanes: Changing lanes without taking into account the actual distance of the vehicle in the convex mirror is...
Page 131 Before Driving Mirrors 2. Press the select switch for the WARNING outside mirror to be tilted downward to turn on the indicator Do not touch a power folding outside light of the select switch. mirror while it is moving: 3. Shift the selector lever to the R Touching the power folding outside position to tilt the outer mirror on mirror when it is moving is dangerous.
Page 132 Cargo stacked higher than the Refer to the Settings section in the seatbacks is dangerous. It can block Mazda Connect Owner's Manual. your view in the rearview mirror, which In the following cases, the outside ...
Page 133 Before Driving Mirrors To reactivate the auto-dimming NOTE For the manual day/night mirror, function, press the ON/OFF button perform the adjustment with the day/ ( ). The indicator light will illuminate. night lever in the day position. Reducing glare from headlights Manual day/night mirror Push the day/night lever forward for day driving.
Page 134 Before Driving Mirrors The auto-dimming function is  canceled when the power switch is switched ON and the selector lever is in the R position. 3-48...
Page 135: Windows
Before Driving Windows If the person's hand or head hits Power Windows something outside the vehicle, or sudden braking is applied, it could ▼ Power Windows result in serious injury or death. The windows can be opened/closed ▼ Opening/Closing Windows by operating the power window switches.
Page 136 Before Driving Windows 7. Unlocked position NOTE Power window system initialization Passenger's window switch procedure If you operate the switch any number of times with the power window not fully closed, the window may no longer fully open/close automatically. The power window auto function will only resume on a power window that has been reset.
Page 137: Moonroof
Before Driving Windows If there is no foreign object around Moonroof the window frame, forcibly close a window using the following ▼ Moonroof procedure. The moonroof can be opened or 1. After switching the power switch closed when operating the overhead OFF, wait for 45 seconds or tilt/slide switch at the front seats.
Page 138 Mazda, make sure the moonroof is completely closed so that water does not get inside the cabin area. After washing your Mazda or after it  rains, wipe the water off the moonroof before operating it to avoid water penetration which could 1.
Page 139 Before Driving Windows 2. Close (Tilt down) the moonroof will stop and move in the open direction. Slide Operation NOTE The jam-safe function may operate To fully open automatically,  under the following conditions: momentarily press the tilt/slide switch in the backward direction. A strong impact is detected while ...
Page 140: Security System
The immobilizer system allows the EV Equipment system to start only with a key the system recognizes. Mazda cannot guarantee the immobilizer system's operation if the If someone attempts to start the EV system has been modiﬁed or if any system with an unrecognized key, the add-on equipment has been installed.
Page 141 Always keep a spare key in case one  is lost. If a key is lost, consult an The system is disarmed when the Authorized Mazda Dealer as soon as power switch is switched ON with the possible. correct programmed key. The security If you lose a key, an Authorized ...
Page 142: Driving Tips
Before Driving Driving Tips Break-In Period Hazardous Driving ▼ Break-In Period ▼ Hazardous Driving No special break-in is necessary, but if WARNING unnecessary hard stops are avoided in the ﬁrst 1,000 km (600 miles), it may add to the performance, economy, Be careful when applying sudden and life of the vehicle.
Page 143: Floor Mat
▼ Floor Mat ▼ Rocking the Vehicle We recommend the use of Genuine WARNING Mazda ﬂoor mats. WARNING Do not spin the wheels at more than 56 km/h (35 mph), and do not allow Make sure the ﬂoor mats are hooked...
Page 144: Winter Driving
4.3 psi) more than recommended on of sand or salt. the tire pressure label (rear door on the Ask an Authorized Mazda Dealer to driver's side), but never more than the check the following: maximum cold-tire pressure shown on the tires.
Page 145: Overloading
Install the chains on the front tires only. Do not use chains on the rear tires. Please consult an Authorized Mazda Dealer. Installing the chains 1. Secure the chains on the front tires as tightly as possible.
Page 146: Driving On Uneven Road
Before Driving Driving Tips Driving on Uneven Road ▼ Driving on Uneven Road Your vehicle's suspension and underbody can be damaged if driven on rough/uneven roads or over speed bumps at excessive speeds. Use care and reduce speed when traveling on rough/uneven roads or over speed bumps.
Page 147: Towing
Towing Trailer Towing Recreational Towing ▼ Trailer Towing ▼ Recreational Towing Your Mazda is not designed for towing. An example of "recreational towing" is Never tow a trailer with your Mazda. towing your vehicle behind a motorhome. The EV Transaxle is not designed for towing this vehicle on all 4 wheels.
Page 148 MEMO 3-62...
Page 149 When Driving Information concerning safer driving and stopping. Starting and Stopping the EV Brake........4-52 System........4-4 Brake System....... 4-52 Power Switch Position.... 4-4 AUTOHOLD......4-57 Starting the EV System....4-5 Emergency Stop Signal Stopping the EV System..4-8 System........ 4-61 Hill Launch Assist (HLA)..4-61 Instrument Cluster and Display........
Page 150 ......4-104 (TPMS)......4-180 Rear Cross Traffic Alert (RCTA) ..........4-107 Rear View Monitor....4-183 Mazda Radar Cruise Control with Rear View Monitor ... 4-183 Stop & Go function (MRCC with Stop & Go function) ..4-111 Parking Sensor System... 4-198 Traffic Jam Assist (TJA) ..
Page 151 MEMO...
Page 152: Starting And Stopping The Ev System
When Driving Starting and Stopping the EV System NOTE Power Switch Position The READY indication is displayed in  ▼ Function of Each Power Switch the instrument cluster when the EV Position system is activated. The READY indication remains displayed while The power switch is switched in the the EV system is operating.
Page 153: Starting The Ev System
(green) The key must be carried by the  turned on. driver. If this function is disabled, the EV  system cannot be started even if the key is carried. Consult an Authorized Mazda Dealer for details.
Page 154 EV system could be started, the P position. however, consult an Authorized Shift the selector lever to the P Mazda Dealer as soon as possible. position and then start the EV system. NOTE The function to start the EV ...
Page 155 Devices for electronic purchases, or started, however, have the vehicle inspected by an Authorized security passage touch or come near Mazda Dealer as soon as the key. possible. If the EV system cannot be started If the power switch indicator light ...
Page 156: Stopping The Ev System
When Driving Starting and Stopping the EV System Because the AUTO P (parking lock) Stopping the EV System  function operates, the power switch can be switched OFF even ▼ When Stopping the EV System with the selector lever in a position 1.
Page 157: Instrument Cluster And Display
When Driving Instrument Cluster and Display Instrument Cluster and Instrument Cluster Display ▼ Instrument Cluster ▼ Instrument Cluster and Display ① Power Meter.....page 4-9 ② Multi-information Display....① Instrument Cluster.... page 4-9 ........page 4-11 ② Active Driving Display..page 4-24 ③...
Page 158 When Driving Instrument Cluster and Display depressed, the more the power meter needle is in the POWER zone. 1. CHARGE zone 2. POWER zone The CHARGE indicators indicate the electrical power which can be generated by regenerative braking, and the POWER indicators indicate the motor output status.
Page 159 When Driving Instrument Cluster and Display ▼ Multi-information Display 1. Multi-information Display 2. INFO switch The multi-information display indicates the following information. Speedometer  Odometer  Trip meter  Outside temperature  Remaining high voltage battery power  Distance-to-full discharge ...
Page 160 When Driving Instrument Cluster and Display The screen content changes each time the INFO switch is pressed. 1. Basic display 2. Drive information display 3. i-ACTIVSENSE display 4. Charge status display 4-12...
Page 161 When Driving Instrument Cluster and Display 5. Message display Displays only while charge connector is connected. Displayed only when a warning occurs. ▼ Odometer, Trip Meter and Trip TRIP B) of interval distance can be Meter Selector measured. You can switch between the odometer For instance, trip meter A can record and trip meter display using the TRIP the distance from the point of origin,...
Page 162 When Driving Instrument Cluster and Display NOTE NOTE When the high voltage battery After charging, it may require some  temperature is high or low, the output time for the needle to stabilize. may be restricted to protect the EV arrow indicates that the ...
Page 163 Refer to the Settings section in the are turned on. Mazda Connect Owner's Manual. When the illumination dimmer is  canceled, the screen in the center display switches to constant display of the daytime screen.
Page 164 When Driving Instrument Cluster and Display ▼ Remaining High Voltage Battery NOTE Power Indication The indicated remaining  distance-to-full discharge is an The remaining amount of power in the estimate. The remaining high voltage battery is indicated by a distance-to-full discharge differs percentage.
Page 165 Refer to Front Cross Traffic Alert  from the electrical power consumption (FCTA) on page 4-104. and displayed. Refer to Mazda Radar Cruise Control  with Stop & Go function (MRCC with Stop & Go function) on page 4-112. Refer to Traffic Jam Assist (TJA) on ...
Page 166 When Driving Instrument Cluster and Display ▼ Compass Display Message only is indicated on display Follow the instructions indicated on The direction the vehicle is moving is the display. For the display content, displayed in one of eight directions refer to the next page. while the vehicle is being driven.
Page 167 When Driving Instrument Cluster and Display ▼ Warning Indication/Warning Lights These lights turn on or ﬂash to notify the user of the system operation status or a system malfunction. Signal Warning Refer to 7-21 Brake System Warning Indication/Warning Light Electronic Brake Force Distribution System Warn-...
Page 168 The light turns on when the power switch is switched ON for an operation check, and turns off a few seconds later or when the EV system is started. If the light does not turn on or remains on, have the vehicle inspected by an Authorized Mazda Dealer. 4-20...
Page 169 When Driving Instrument Cluster and Display ▼ Indication/Indicator Lights These lights turn on or ﬂash to notify the user of the system operation status or a system malfunction. Signal Indicator Refer to Seat Belt Indicator Light (Rear seat) 2-30 (Green) Front Passenger Air Bag Deactivation Indicator Light 2-64 Immobilizer...
Page 170 *1*2 7-26 Electric Parking Brake (EPB) Indication/Indicator Light 4-59 AUTOHOLD Active Indicator Light Mazda Radar Cruise Control with Stop & Go function (MRCC with 4-117 Stop & Go function) indicator Light 4-126 Traffic Jam Assist (TJA) Indicator Light Traction Con-...
Page 171 When Driving Instrument Cluster and Display Signal Indicator Refer to Mazda Radar Cruise Control with Stop & Go function (MRCC with 4-114 Stop & Go function) Standby Indication 4-122 Traffic Jam Assist (TJA) Standby Indication (White) Mazda Radar Cruise Control with Stop & Go function (MRCC with 4-114 Stop &...
Page 172: Active Driving Display
When Driving Instrument Cluster and Display Active Driving Display ▼ Active Driving Display 1. Display 2. Dust-proof sheet WARNING Always adjust the display brightness and position with the vehicle stopped: Adjusting the display brightness and position while driving the vehicle is dangerous as doing so could distract your attention from the road ahead and lead to an accident.
Page 173 Front Cross Traffic Alert (FCTA) Operation Conditions and Warning  Refer to Front Cross Traffic Alert (FCTA) on page 4-104. Mazda Radar Cruise Control with Stop & Go function (MRCC with Stop & Go  function) Operation Conditions and Warnings Refer to Mazda Radar Cruise Control with Stop &...
Page 174: Selector Lever Position Functions
When Driving Selector Lever Position Functions N (Neutral) Selector Lever Position Position where power generated by the Functions motor is not transmitted to the EV Transaxle. ▼ Selector Lever Position Functions WARNING Do not shift into N when driving the vehicle: If the selector lever is shifted to the N position while driving, deceleration...
Page 175 When Driving Selector Lever Position Functions 1. Shift position indication The selector lever is shifted to the D  position while driving in reverse When the power switch is switched (vehicle speed of about 10 km/h ON, the shift position is displayed in (6.3 mph) or faster) with the selector the instrument cluster.
Page 176: Selector Lever Operation
When Driving Selector Lever Position Functions Selector Lever Operation ▼ Selector Lever Operation Indication Various Lockouts Indicates that you must depress the brake pedal and hold in the lock-release button to shift (The power switch must be switched ON). Indicates the selector lever can be shifted freely into any position. Indicates that you must hold in the lock-release button to shift.
Page 177 When Driving Selector Lever Position Functions The driver’s seat belt is unfastened and the driver’s door is opened.  NOTE When the AUTO P (parking lock) function operates, only the shift position changes to the P position automatically. The shift position indication in the instrument cluster will differ from the selector lever position because the selector lever position does not change.
Page 178 When Driving Selector Lever Position Functions Switch the power switch ON.  The selector lever is shifted to the P position.  NOTE Neutral hold mode (automatic car wash mode) is canceled automatically after about 25 minutes have passed since it was operated, and the power switch is switched OFF.
Page 179 When Driving Selector Lever Position Functions Shift posi- Selector Shift posi- tion be- Operation/driving lever oper- tion after Action fore oper- conditions ation operation ation Method 1 for resolving problem Depress brake pedal so that vehicle speed is less than about 10 km/h (6.2 mph). While driving forward Shift position changes to R.
Page 180: Shift-Lock System
When Driving Selector Lever Position Functions Shift-Lock System Driving Tips ▼ Shift-Lock System ▼ Driving Tips The shift-lock system prevents shifting When starting to drive the vehicle or out of P unless the brake pedal is reversing the vehicle depressed. WARNING 1.
Page 181 When Driving Selector Lever Position Functions Regeneration braking is less effective There is the possibility of forgetting  that the selector lever is shifted to the closer the high voltage battery is the R position when only reversing to a full charge, and regeneration the vehicle a little.
Page 182 When Driving Selector Lever Position Functions Parking the vehicle 1. After completely stopping the vehicle, continue to depress the brake pedal ﬁrmly. 2. Shift the selector lever to the P position with the brake pedal depressed. 3. Make sure that the shift position is in the P position using the shift position indication in the instrument cluster.
Page 183: Switches And Controls
When Driving Switches and Controls Lighting Control ▼ Headlights Turn the headlight switch to turn the headlights and other exterior lights on or off. When the taillights, parking lights, and the license plate lights are turned on, the lights-on indicator light in the instrument cluster turns on. NOTE Do not leave the headlights and exterior lights on while the EV system is turned ...
Page 184 When Driving Switches and Controls During the daytime, the daytime running lights turn on automatically. During the nighttime, the headlights, parking lights, taillights, and the license plate lights turn on automatically. During the daytime, the daytime running lights, parking lights, taillights, and the license plate lights turn on automatically.
Page 185 When Driving Switches and Controls Refer to the Settings section in the Mazda Connect Owner's Manual. ▼ Headlight High-Low Beam will return to the normal position when released. The headlights switch between high and low beams by moving the lever forward or backward.
Page 186 (30 seconds). Manual type When adjusting the illumination angle of the headlights, refer to the Settings section in the Mazda Connect Owner's Manual. Select the proper headlight angle from the following chart. Front seat Illumi-...
Page 187: Turn And Lane-Change Signals
The signal will self-cancel Refer to the Settings section in the after the turn is completed. Mazda Connect Owner's Manual. If the indicator light continues to ﬂash after a turn, manually return the lever to its original position.
Page 188: Windshield Wipers And Washer
ﬂash ▼ Windshield Wipers and Washer abnormally. Have your vehicle The windshield wipers and washer can inspected by an Authorized Mazda be used when the power switch is Dealer. switched ON. A personalized function is available ...
Page 189 From the center position (normal), rotate the switch upward (+ direction) to a position other than OFF, consult an Authorized Mazda Dealer as soon for higher sensitivity (faster response) or rotate it downward (- direction) for as possible.
Page 190 When Driving Switches and Controls When removing ice or snow, or CAUTION cleaning the windshield, always Do not shade the rain sensor by make sure the wiper lever is in the OFF position. adhering a sticker or a label on the windshield.
Page 191 The auto-wiper control functions can  be turned off. Refer to the Settings section in the Mazda Connect Owner's Manual. ▼ Windshield Washer Pull the wiper lever toward you to spray washer ﬂuid and operate the windshield wipers several times. The washer ﬂuid is sprayed only while the...
Page 192: Rear Window Wiper And Washer
ﬂuid level (page 6-13). If the ﬂuid ▼ Rear Window Wiper level is normal and the washer still does not work, consult an Authorized Mazda Dealer. Turn the wiper on by turning the rear wiper/washer switch. Switch Posi- Wiper operation tion Spray washer ﬂuid and operate...
Page 193: Rear Window Defogger
OFF. automatically. Refer to the Settings section in the The indicator light illuminates when Mazda Connect Owner's Manual. the defogger is operating. ▼ Windshield Wiper De-icer To turn off the rear window defogger The thermal ﬁlaments at the following...
Page 194: Horn
When Driving Switches and Controls to operate the windshield wiper Horn de-icer (page 4-45). ▼ Horn To sound the horn, press the mark on the steering wheel. 1. Indicator light ▼ Mirror Defogger The mirror defoggers defrost the outside mirrors. The mirror defoggers operate in conjunction with the rear window defogger.
Page 195: Hazard Warning Flasher
When Driving Switches and Controls Hazard Warning Flasher HomeLink Wireless Control System ▼ Hazard Warning Flasher ▼ HomeLink Wireless Control The hazard warning lights should always be used when you stop on or System near a roadway in an emergency. NOTE HomeLink and HomeLink house are registered trademarks of Gentex...
Page 196 The indicator light ﬂashes slowly in HomeLink at www.homelink.com or amber when the button is pressed. www.youtube.com/HomeLinkGentex or an Authorized Mazda Dealer. Always check the areas surrounding garage doors and gates for people or obstructions before programming or during operation of the HomeLink system: 1.
Page 197 When Driving Switches and Controls If the indicator light ﬂashes 8. If the status indicator arrows are  rapidly in green, ﬁrmly press and ﬂashing, refer to Garage Door hold the Homelink button and Two-Way Communication. release it after two seconds have passed.
Page 198 When Driving Switches and Controls ▼ Erasing Programmed HomeLink the HomeLink System with the following: Buttons NOTE NOTE If programming a garage door opener or gate operator, it is advised to unplug All of the programmed HomeLink  the device during the “cycling” process buttons are reset.
Page 199 When Driving Switches and Controls Programming two-way Garage door Indicator light communication status Within ﬁve seconds after programming Amber ﬂashes a new HomeLink button, both of the Opening garage door status indicator lights will ﬂash rapidly in green indicating that Green turns on the garage door two-way Closed...
Page 200: Brake
When Driving Brake Driving with wet brakes is dangerous. Brake System Increased stopping distance or the vehicle pulling to one side when ▼ Foot Brake braking could result in a serious This vehicle has power-assisted brakes accident. Light braking will indicate that adjust automatically through whether the brakes have been normal use.
Page 201 When Driving Brake turns off when releasing the parking When the power switch is switched  brake. OFF while the charging system warning light in the instrument cluster turns on, the parking brake cannot be applied. Before switching the power switch OFF, apply the parking brake manually.
Page 202 When Driving Brake When using an automatic car wash instrument cluster and the EPB switch  which moves the vehicle with the indicator light turn off. front tires mounted, it is necessary to cancel the parking brake auto operation before the vehicle enters the automatic car wash.
Page 203 When Driving Brake Releasing the parking brake seconds after the sound was automatically activated. After the auto operation is If the accelerator pedal is depressed canceled, a sound is activated one with the parking brake applied and all time, and the EPB switch indicator of the following conditions met, the light switches from illumination to parking brake is released automatically.
Page 204 The brake assist equipment does not  supersede the functionality of the When you hear this noise, consult an vehicle's main braking system. Authorized Mazda Dealer as soon as ▼ Brake Override System possible. The brake override system applies the WARNING brake ﬁrst for safety if the brake pedal...
Page 205: Autohold
When Driving Brake AUTOHOLD ▼ AUTOHOLD The AUTOHOLD function automatically holds the vehicle stopped, even if you take your foot off the brake pedal. This function can be best used while stopped in traffic or at a traffic light. The brakes are released when you start driving the vehicle. WARNING Do not rely completely on the AUTOHOLD function: The AUTOHOLD function is only designed to assist the brake operation while the...
Page 206 NOTE Under the following conditions, a problem with the AUTOHOLD is occurring.  Have your vehicle inspected at an Authorized Mazda Dealer as soon as possible. A message is indicated on the multi-information display and a warning sound is ...
Page 207 When Driving Brake The brake pedal response may change, sound may occur from the brakes, or the  brake pedal could vibrate from the operation of the AUTOHOLD function. However, this does not indicate a malfunction. ▼ To Turn On AUTOHOLD System 2.
Page 208 When Driving Brake is turned off and the AUTOHOLD NOTE standby indicator light turns off. If the Electric Parking Brake (EPB)  switch is pulled while the AUTOHOLD is operating, the parking brake is applied and the AUTOHOLD is released. In addition, if the parking brake is released under this condition, the AUTOHOLD operates to hold the brakes.
Page 209: Emergency Stop Signal System
When Driving Brake Emergency Stop Signal Hill Launch Assist (HLA) System ▼ Hill Launch Assist (HLA) ▼ Emergency Stop Signal System The HLA functions to assist in accelerating the vehicle from a stop on If you apply the brakes suddenly while slopes.
Page 210 When Driving Brake HLA does not operate if the parking  brake is applied, or if the vehicle has not stopped completely. While HLA is operating, the brake  pedal may feel stiff and vibrate, however, this does not indicate a malfunction.
Page 211: Abs/Tcs/Dsc
When Driving ABS/TCS/DSC NOTE Antilock Brake System Braking distances may be longer on (ABS)  loose surfaces (snow or gravel, for example) which usually have a hard ▼ Antilock Brake System (ABS) foundation. A vehicle with a normal The ABS control unit continuously braking system may require less monitors the speed of each wheel.
Page 212: Traction Control System (Tcs)
7-27. malfunction and they may not operate correctly. Take your vehicle to an WARNING Authorized Mazda Dealer. NOTE Do not rely on the Traction Control System (TCS) as a substitute for safe When the TCS/DSC operation ...
Page 213 If the light remains illuminated and the TCS system activates automatically. TCS is not switched off, take your The TCS OFF indicator light turns off vehicle to an Authorized Mazda while the TCS system is operative. Dealer. The DSC may have a malfunction.
Page 214: Dynamic Stability Control (Dsc)
When Driving ABS/TCS/DSC Use tires of the correct size Dynamic Stability Control speciﬁed for your Mazda on all 4 (DSC) wheels. Use tires of the same ▼ Dynamic Stability Control (DSC) manufacturer, brand and tread pattern on all 4 wheels.
Page 215: Power Steering
If the steering feels stiffer than usual during normal driving or the steering vibrates, consult an Authorized Mazda Dealer. The malfunction indication/indicator  light notiﬁes the driver of system abnormalities and operation conditions.
Page 216: I-Activsense
Active Safety Technology supports safer Inter-vehicle distance driving by helping the driver to recognize potential hazards and avert Mazda Radar Cruise Control with Stop accidents. & Go function (MRCC with Stop & Go function)......page 4-111 Driver awareness support systems...
Page 217 When Driving i-ACTIVSENSE ▼ Camera and Sensors Refer to Front Camera/Side Cameras/Rear Camera on page i-ACTIVSENSE uses the following 4-81. detection systems. 2. Rear ultrasonic sensor Refer to Rear Ultrasonic Sensor on Vehicle front page 4-80. 3. Rear side radar sensor Refer to Rear Side Radar Sensor on page 4-79.
Page 218 (warning/risk avoidance System OFF status support system) (white) is displayed. If all the systems are canceled using i-ACTIVSENSE status symbol [Settings] in Mazda Connect or the (warning/risk avoidance support i-ACTIVSENSE OFF switch, the system) (green) i-ACTIVSENSE OFF symbol (Warning/ risk avoidance support system) is displayed.
Page 219: Forward Sensing Camera (Fsc)
Stop & Go function) switched ON. However, if the systems Traffic Jam Assist (TJA)  are canceled using [Settings] in Mazda Lane-keep Assist System (LAS)  Connect, the systems are not Emergency Lane Keeping (ELK) ...
Page 220 The Forward Sensing Camera (FSC) is road ahead. installed to the windshield. Consult When cleaning the windshield, do an Authorized Mazda Dealer for not allow glass cleaners or similar windshield repair and replacement. cleaning ﬂuids to get on the Forward Do not remove the Forward Sensing...
Page 221 If the Forward Sensing Camera (FSC)  rearview mirror, consult an detects that the windshield is dirty or Authorized Mazda Dealer. foggy, the system functions related to Always use tires for all wheels that the Forward Sensing Camera (FSC) are temporarily stopped and the are of the speciﬁed size, and the...
Page 222 When Driving i-ACTIVSENSE Detection of objects Front visibility is reduced (due to a  vehicle ahead casting off water, When any of the following conditions snow, or sand). is met, the Forward Sensing Camera Strong light is directed at the front of ...
Page 223: Front Radar Sensor
The road surface is shiny.  The following systems also use the front radar sensor. Distance & Speed Alert (DSA)  Mazda Radar Cruise Control with  Stop & Go function (MRCC with Stop & Go function) Traffic Jam Assist (TJA) ...
Page 224 For repairs, replacement or paint and a round-shaped vehicle). work around the front radar sensor, A vehicle ahead has limited areas consult an Authorized Mazda Dealer.  that can reﬂect radio waves (such as Always use tires for all wheels that a low proﬁle vehicle).
Page 225: Front Side Radar Sensor
Refer to Exterior Care on page 6-34. If the front bumper receives a severe impact, the system may no longer operate normally. Stop the system immediately and have the vehicle inspected at an Authorized Mazda Dealer. 4-77 *Some models.
Page 226 If the direction of the front side radar sensor has deviated for some reason, have the vehicle inspected at an Authorized Mazda Dealer. For repairs or replacement of the front side radar sensor, or bumper repairs, paintwork, and replacement near the radar sensors, consult an Authorized Mazda Dealer.
Page 227: Rear Side Radar Sensor
Stop the system ▼ Rear Side Radar Sensor immediately and have the vehicle Your vehicle is equipped with rear side inspected at an Authorized Mazda radar sensor. Dealer. Vehicles are shipped with the direction of the rear side radar...
Page 228: Rear Ultrasonic Sensor
When Driving i-ACTIVSENSE Bicycles  Rear Ultrasonic Sensor Pedestrians  Animals ▼ Rear Ultrasonic Sensor  Shopping carts  Your vehicle is equipped with rear Stationary objects on the road or  ultrasonic sensor. roadside Vehicles with shapes that may not ...
Page 229: Front Camera/Side Cameras/Rear Camera
When Driving i-ACTIVSENSE Front Camera/Side Driver Monitoring Cameras/Rear Camera Camera ▼ Front Camera/Side Cameras/Rear ▼ Driver Monitoring Camera Camera Your vehicle is equipped with a driver Your vehicle is equipped with a front monitoring camera. camera, side cameras, and a rear camera.
Page 230: Adaptive Front Lighting System (Afs)
Information about the (AFS) can be switched to on/off using licensing and source code is the personalization function. available at the following URL. Refer to the Settings section in the http:// Mazda Connect Owner's Manual. www.embedded-carmultimedia.jp /RTOS/License/oss/DMS_0201/ 4-82 *Some models.
Page 231: High Beam Control System (Hbc)
Refer to the Settings section in the Refer to Forward Sensing Camera Mazda Connect Owner's Manual. (FSC) on page 4-71. The system switches the headlights to low beams when one of the following occurs: 4-83 *Some models.
Page 232: Some Models
When Driving i-ACTIVSENSE ▼ Manual Switching Lane Departure Warning Switching to low beams System (LDWS) Switch the headlight switch to the ▼ Lane Departure Warning System position, or press the high beam (LDWS) control switch. The HBC indicator light (green) turns The LDWS notiﬁes the driver that the off.
Page 233 A condition under which the  i-ACTIVSENSE OFF switch or [Settings] Forward Sensing Camera (FSC) in the Mazda Connect. cannot detect a target object is met. Refer to Forward Sensing Camera Operation conditions (FSC) on page 4-71.
Page 234 The LDWS settings can be changed.  Refer to the Settings section in the If there is a problem with the system, Mazda Connect Owner's Manual. the i-ACTIVSENSE status symbol You may not be able to hear the  (warning/risk avoidance support...
Page 235: Blind Spot Monitoring (Bsm)
The BSM is designed to assist the driver ON. However, if the system is canceled in checking the area to the rear of the using [Settings] in Mazda Connect, the vehicle on both sides during lane system is not automatically enabled.
Page 236 Always check the surrounding area have the vehicle inspected at an visually before making an actual lane Authorized Mazda Dealer as soon as change: possible. The system is only designed to assist Some problem with the system you in checking for vehicles at your rear ...
Page 237 When Driving i-ACTIVSENSE The rear bumper around the rear When there is a difference in the   side radar sensor is deformed. height between your driving lane Radio wave interference from a and the adjacent lane.  radar sensor equipped on a nearby Directly after the BSM system ...
Page 238 When Driving i-ACTIVSENSE Objects such as guardrails and A BSM warning indicator light may  concrete walls running alongside ﬂash or the warning beep may be the vehicle. activated several times when making a turn at a city intersection. Turn off the BSM while pulling a ...
Page 239 (If only the BSM is turned off)  Refer to Dashboard Illumination on Refer to the Settings section in the page 4-14. Mazda Connect Owner's Manual. (If the BSM is turned off by  Display indicator operating the i-ACTIVSENSE OFF...
Page 240 OFF switch, the system is automatically enabled the next time the power switch is switched ON. However, if the system is canceled using [Settings] in Mazda Connect, the system is not automatically enabled. 4-92...
Page 241: Traffic Sign Recognition System (Tsr)
When Driving i-ACTIVSENSE Traffic Sign Recognition System (TSR) ▼ Traffic Sign Recognition System (TSR) The TSR helps prevent the driver from overlooking traffic signs, and provides support for safer driving by displaying traffic signs on the active driving display/instrument cluster which are recognized by the Forward Sensing Camera (FSC) or recorded in the navigation system while the vehicle is driven.
Page 242 The TSR is not supported in some countries or regions. For information concerning  the supported countries or regions, consult an Authorized Mazda Dealer. The TSR operates only if the navigation system SD card (Mazda genuine) is  inserted in the SD card slot. Consult an Authorized Mazda Dealer for details.
Page 243 The TSR can be set to invisible on the active driving display.  Refer to the Settings section in the Mazda Connect Owner's Manual. ▼ Traffic Sign Display Indication Stop signs The following traffic signs are displayed on the active driving display/ instrument cluster.
Page 244 When Driving i-ACTIVSENSE The Forward Sensing Camera (FSC) When the Forward Sensing Camera   recognizes a speed limit sign as a (FSC) recognizes the do not enter sign targeted for your vehicle and sign and a certain period of time has the vehicle passes it.
Page 245 In addition, the warning pattern and the warning activation timing differ depending on the setting contents. Refer to the Settings section in the Mazda Connect Owner's Manual. Speed Limit Sign Alert setting Off: The excessive speed warning is not activated.
Page 246 When Driving i-ACTIVSENSE stops ﬂashing and remains on. The warning sound is activated continuously until the vehicle speed decreases below the speed limit sign. Speed Limit Sign Threshold setting + 0 km/h (+ 0 mph): If the vehicle speed exceeds the speed limit sign displayed in ...
Page 247: Distance & Speed Alert (Dsa)
Refer to the Settings section in the ahead. If you neglect to operate the Mazda Connect Owner's Manual. accelerator and brake pedals correctly, Refer to i-ACTIVSENSE OFF Switch it could lead to an accident.
Page 248: Driver Attention Alert (Daa)
When Driving i-ACTIVSENSE Check the surrounding conditions and Driver Attention Alert keep a safe distance from the vehicle (DAA) ahead. ▼ Driver Attention Alert (DAA) The DAA is a system which detects driver fatigue and decreased attentiveness, and encourages the driver to take a rest.
Page 249 When Driving i-ACTIVSENSE White (yellow) lane lines are less WARNING  visible because of dirt or fading/ patchiness. Do not rely completely on DAA and The vehicle is jolted or swayed  always drive carefully: continuously by strong winds or The DAA detects driver fatigue and rough roads.
Page 250: Driver Monitoring (Dm)
The DAA can be set to inoperable. Refer to the Settings section in the The DM is a system which detects Mazda Connect Owner's Manual. driver fatigue and sleepiness, and encourages the driver to take a rest. While driving the vehicle at about 5...
Page 251 When Driving i-ACTIVSENSE After displaying the warning WARNING  pattern (caution), the next warning pattern (caution) is not displayed Do not rely completely on the DM until 45 minutes have passed. and always drive carefully: After displaying the warning  The DM is a system which detects pattern (warning), the next driver fatigue and sleepiness, and...
Page 252: Front Cross Traffic Alert (Fcta)
Front Cross Traffic Alert The DM can be set to inoperable. (FCTA) Refer to the Settings section in the Mazda Connect Owner's Manual. ▼ Front Cross Traffic Alert (FCTA) The FCTA is designed to assist the driver in checking both sides of the vehicle when the vehicle starts to drive at an intersection.
Page 253 When Driving i-ACTIVSENSE When your vehicle is driven at less display (amber arrow) and the warning  than about 10 km/h (6 mph). sound is activated at the same time. Multi-information display The selector lever is in the D  position.
Page 254 Authorized Mazda Dealer as soon as system may not operate normally. possible. The front side radar sensor Some problem with the system has ...
Page 255: Rear Cross Traffic Alert (Rcta)
ON. However, if the system is canceled of your vehicle while your vehicle is using [Settings] in Mazda Connect, the being reversed out of a parking space, system is not automatically enabled.
Page 256 When Driving i-ACTIVSENSE Monitoring (BSM) warning WARNING indicator light on the door mirrors. Always check the surrounding area visually before actually putting the vehicle in reverse: The system is only designed to assist you in checking for vehicles at the rear when putting the vehicle in reverse.
Page 257 If the i-ACTIVSENSE warning indication/ warning light remains illuminated, have the vehicle inspected at an Authorized Mazda Dealer as soon as 1. Your vehicle possible. A vehicle is approaching directly ...
Page 258 Snow or ice adheres to the door  ON. However, if the system is canceled mirrors. using [Settings] in Mazda Connect, the The front door glass is fogged or  system is not automatically enabled. covered in snow, frost or dirt.
Page 259: Mazda Radar Cruise Control With Stop & Go Function (Mrcc With Stop & Go Function)
(MRCC with ahead or a vehicle following behind Stop & Go function) you. ▼ Mazda Radar Cruise Control with Do not use the system under the Stop & Go function (MRCC with following conditions. Otherwise, it Stop & Go function) may result in an accident: The vehicle is driven on roads other...
Page 260 Refer to the Settings section in the Mazda Connect Owner's Manual. Active driving display ▼ Mazda Radar Cruise Control with Stop & Go function (MRCC with Stop & Go function) Display Indication The setting status and operation 1.
Page 261 ▼ Close Proximity Warning If your vehicle approaches a vehicle ahead while in headway control using the Mazda Radar Cruise Control with Stop & Go function (MRCC with Stop & Go function), a warning sound is activated and a brake warning is displayed on the multi-information display.
Page 262 In the following cases, the MRCC with Stop & Go function system is canceled  when the vehicle is traveling at 30 km/h (20 mph) or less and “Mazda Radar Cruise Control Disabled Under 30 km/h” is displayed in the multi-information display.
Page 263 When Driving i-ACTIVSENSE When the vehicle speed is set, the set vehicle speed is displayed on the displays  and the MRCC standby indication (white) changes to the MRCC set indication (green). The minimum speed setting is 30 km/h (19 mph). ...
Page 264 When Driving i-ACTIVSENSE Distance-between-vehicles Indication on active driving dis- guideline Indication on multi-information (at 80 km/h (50 mph) vehicle display play speed) Medium (about 40 m (131 ft)) Short (about 30 m (98 ft)) Extremely short (about 25 m (82 ft)) Displays a pop-up image in the active driving display only when the driver operates the switch.
Page 265 When Driving i-ACTIVSENSE The DSC has operated.  The Smart Brake Support (SBS) has operated.  The frequency of the braking operation by the MRCC with Stop & Go function is  high. There is a problem in the system. ...
Page 266: Traffic Jam Assist (Tja)
When Driving i-ACTIVSENSE Set a vehicle speed within the speed Traffic Jam Assist (TJA) limit according to the road conditions and the weather ▼ Traffic Jam Assist (TJA) conditions. The TJA is a system designed to reduce The TJA may not be able to detect a driver fatigue during traffic jams when vehicle ahead depending on the type driving on expressways or highways.
Page 267 When Driving i-ACTIVSENSE Under bad weather conditions (rain, A condition under which the  fog, and snow). Forward Sensing Camera (FSC) Tires other than the speciﬁed size are cannot detect a target object is met. used, such as when tire chains or Refer to Forward Sensing Camera temporary spare tires are used.
Page 268 When Driving i-ACTIVSENSE Multi-information display (Basic display on the display changes from display) white to green. 1. Steering assist operation display NOTE 1. Vehicle ahead display You can check if the steering assist 2. TJA set vehicle speed function is following the lane lines or it is following vehicles ahead, on the Multi-information display multi-information display.
Page 269 Check the details of the problem and then have your vehicle inspected by an 1. “Depress Brake Pedal” message is Authorized Mazda Dealer. displayed Refer to If a Warning Light Turns On or Flashes on page 7-21.
Page 270 When Driving i-ACTIVSENSE ▼ Setting the System Operation switch 1. CANCEL switch 2. RES switch 3. TJA switch Operation conditions Headway control function The headway control operates when all of the following conditions are met. The TJA is on.  The selector lever is in the D position.
Page 271 The minimum speed setting is 30 km/h (19 mph).  When the TJA switch is pressed while the Mazda Radar Cruise Control with Stop &  Go function (MRCC with Stop & Go function) system is operating, the MRCC with Stop &...
Page 272 When Driving i-ACTIVSENSE Distance-between-vehicles Indication on display guideline Indication on active driving dis- Indication on multi-information (at 80 km/h (50 mph) vehicle display play speed) Short (about 30 m (98 ft)) Extremely short (about 25 m (82 ft)) Displays a pop-up image when the CANCEL switch is operated. Changing the set vehicle speed How to change the set vehicle speed using the RES switch When the RES switch is pressed up (SET+), the vehicle accelerates, and when the...
Page 273 When Driving i-ACTIVSENSE Steering assist function If any of the following conditions is met, the steering assist function is temporarily canceled. The headway control function is canceled.  White (yellow) lane lines cannot be detected or a vehicle ahead cannot be ...
Page 274 When Driving i-ACTIVSENSE Resuming the control If the TJA is temporarily canceled, it will resume operation at the previously set speed by pressing the RES switch after all of the operation conditions have been met again. Turning off the system When the TJA switch is pressed while the TJA is operating, the TJA turns off.
Page 275: Lane-Keep Assist System (Las)
When Driving i-ACTIVSENSE The functions of the LAS have Lane-keep Assist System limitations. Always stay on course (LAS) using the steering wheel and drive with care. ▼ Lane-keep Assist System (LAS) Do not use the LAS under the following circumstances, otherwise it The LAS provides steering assistance to may result in an accident.
Page 276 When Driving i-ACTIVSENSE The vehicle is driven on a forked The windshield around the forward   road or junction. sensing camera (FSC) is foggy. The windshield around the forward  ▼ System Operation sensing camera (FSC) is blocked by an obstruction, causing poor forward Operation conditions visibility.
Page 277: Emergency Lane Keeping (Elk)
ON. However, if the system is canceled you in the driving lane. using [Settings] in Mazda Connect, the When the steering wheel operation LAS is not automatically enabled. assist operates, a warning sound and...
Page 278 When Driving i-ACTIVSENSE The detection area of the camera sound and display indications alert the driver of the danger. and sensors is limited. If the steering wheel operation assist is operated without detecting a two-wheeled vehicle near the detecting vehicle, it could result in an accident.
Page 279 When the ELK OFF indicator light is   on, the system is canceled according NOTE to a Mazda Connect setting. Refer to the Settings section in the The Blind Spot Assist function may  Mazda Connect Owner's Manual. not operate normally when any of the following conditions is met.
Page 280 When Driving i-ACTIVSENSE Snow, ice, or mud is adhering Multi-information display  (i-ACTIVSENSE display) around a rear side radar sensor. The temperature around a rear side  radar sensor is high. There is a problem with the system.  System problem If there is a problem with the system, the i-ACTIVSENSE warning indication/ warning light turns on and a message is...
Page 281 When Driving i-ACTIVSENSE Multi-information display WARNING Do not rely completely on the Road Keep Assist function and always drive carefully: The Road Keep Assist function has limitations. Do not rely completely on the system and always stay on course using the steering wheel. The Road Keep Assist function is not Active driving display an autonomous driving system.
Page 282 There is a problem with the system.  to a Mazda Connect setting. Refer to the Settings section in the System problem Mazda Connect Owner's Manual. If there is a problem with the system,...
Page 283 ▼ Stopping the Emergency Lane Keeping (ELK) System Operation The ELK can be set to inoperable. Refer to the Settings section in the Mazda Connect Owner's Manual. Active driving display When the ELK is canceled, the ELK OFF indicator light turns on.
Page 284: Smart Brake Support (Sbs)
When Driving i-ACTIVSENSE The vehicle is being towed. Smart Brake Support The vehicle is driven on rough roads (SBS) such as in areas where there is grass and foliage or off-road. ▼ Smart Brake Support (SBS) Refer to Stopping the Smart Brake Support (SBS) System Operation on The SBS is a system designed to detect page 4-143.
Page 285 When Driving i-ACTIVSENSE The vehicle speed is about 4 km/h When crossing a narrow bridge,  (3 mph) or higher. going under a low overhang, or (Object is a pedestrian or bicycle) passing through a narrow gate, a  The vehicle speed is between about car washing machine, or tunnel.
Page 286 Refer to Stopping the Smart Brake NOTE Support (SBS) System Operation on During brake control and brake assist page 4-143.  Consult an Authorized Mazda Dealer operation, the collision warning sound is activated intermittently. for rear bumper removal/ The operation distance and volume installation.
Page 287 When Driving i-ACTIVSENSE The vehicle is driven on rough WARNING roads such as in areas where there is grass and foliage or off-road. Always check the surrounding area Refer to Stopping the Smart Brake visually when reversing the vehicle: Support (SBS) System Operation The operation of the rearward on page 4-143.
Page 288 When Driving i-ACTIVSENSE The obstruction is soft such as a There is a hanging curtain or   hanging curtain or snow stuck to a railroad crossing gate. vehicle. Reversing near objects such as  The obstruction is shaped foliage, barriers, vehicles, walls, or ...
Page 289 If the i-ACTIVSENSE warning indication/warning light remains on, have the vehicle inspected by an Authorized Mazda Dealer as soon as possible. There is a problem with the  WARNING system.
Page 290 Directly after the EV system starts.  Just after the SBS operation has  been enabled using [Settings] in Mazda Connect. Radio wave interference from a  radar sensor equipped on a vehicle parked nearby. 1. Your vehicle When any of the following ...
Page 291 ▼ Stopping the Smart Brake Support (SBS) System Operation The SBS can be changed to inoperable. Refer to the Settings section in the Mazda Connect Owner's Manual. When the SBS is canceled, the SBS OFF indicator light turns on. 4-143...
Page 292: 360° View Monitor
When Driving i-ACTIVSENSE The image from the rear of the 360° View Monitor vehicle is displayed on the center display. ▼ 360° View Monitor The image from the rear assists the The 360°View Monitor consists of the driver in checking the rear of the following functions which assist the vehicle by displaying guide lines on driver in checking the area surrounding...
Page 293 When Driving i-ACTIVSENSE The Rear Cross Traffic Alert (RCTA) The shooting range of the cameras and uses rear side radar sensor to detect detection range of the sensors are vehicles approaching from the rear limited. For example, the areas in black left and right sides of the vehicle, at the front and rear of the vehicle and it assists the driver in checking...
Page 294 When Driving i-ACTIVSENSE Consult an Authorized Mazda Dealer If the camera lens is touched or there  for repair, painting, or replacement is any dirt on it, it could affect the of the front/rear camera, front screen image. Wipe the lens using a soft cloth.
Page 295 360° view monitor camera are reversed images (mirror images). Free/open source software  information This product includes free/open sources. Information about the licensing and source code is available at the following URL. https://www.denso.com/ global/en/opensource/svss/ mazda/ 4-147...
Page 296 When Driving i-ACTIVSENSE ▼ Types of Images Displayed on the Screen Top view/Front view Displays the image of the area around the vehicle and the vehicle front. 1. Top view screen 2. Front view screen 4-148...
Page 297 When Driving i-ACTIVSENSE 3. “Check surroundings for safety.” message is displayed Top view/Front wide view Displays the image of the area around the vehicle and the front of the vehicle (wide-area). 1. Top view screen 2. Front wide view screen 3.
Page 298 When Driving i-ACTIVSENSE 2. Right side view screen 3. “Check surroundings for safety.” message is displayed Top view/Rear view Displays the image of the area around the vehicle and the rear of the vehicle. 1. Top view screen 2. Rear view screen 4-150...
Page 299 When Driving i-ACTIVSENSE 3. “Check surroundings for safety.” message is displayed Top view/Rear wide view Displays the image of the area around the vehicle and the rear of the vehicle (wide-area). 1. Top view screen 2. Rear wide view screen 3.
Page 300 When Driving i-ACTIVSENSE The selector lever is in a position other than R.  Display switching The displayed screen can be changed each time the 360°view monitor switch is pressed. 1. Top view/Front view 2. Top view/Front wide view 3. Side view 4.
Page 301 15 km/h (9.3 mph) after 8 seconds have passed since pressing the 360°View Monitor switch. The 360°View Monitor settings can be changed as follows.  Refer to the Settings section in the Mazda Connect Owner's Manual. Automatic display of the 360°View Monitor when the ultrasonic sensor detects  an obstruction.
Page 302 When Driving i-ACTIVSENSE Screen operation/icon WARNING Always stop the vehicle when adjusting the 360°View Monitor image quality. Do not adjust the 360°View Monitor image quality while driving. If you adjust the 360°View Monitor image quality (such as brightness, contrast, tone, and color density) while driving, it could lead to an unexpected accident.
Page 303 When Driving i-ACTIVSENSE Display range 1. Target object NOTE In the top view screen, the areas in black at the front and rear of the vehicle image  and the seams where each of the camera images merge are blind spots. Because images displayed in the top view screen are processed from each camera, ...
Page 304 When Driving i-ACTIVSENSE Viewing the screen Display/Icon Content Tire icon Indicates the tire direction. Moves in conjunction with the steering wheel operation. Projected vehicle path lines (yellow Indicates the approximate projected path of the vehicle. & red) Moves in conjunction with the steering wheel operation. a) Indicates the path where the edge of the front bumper is expected to travel.
Page 305 NOTE The setting can be changed so that the projected vehicle path lines are not displayed. Refer to the Settings section in the Mazda Connect Owner's Manual. How to use the projected vehicle path line function 1. (Screen display) 2. (Actual condition) Make sure that there are no obstructions within the projected vehicle path lines.
Page 306 When Driving i-ACTIVSENSE Display range 1. Target object NOTE In the top view screen, the areas in black at the front and rear of the vehicle image  and the seams where each of the camera images merge are blind spots. Because images displayed in the top view screen are processed from each camera, ...
Page 307 When Driving i-ACTIVSENSE Viewing the screen Display/Icon Content Extended vehicle width lines and Indicates the approximate width of the vehicle and the distance guide lines (blue & red) distance (from front end of bumper) in front of the vehi- cle. The red lines indicate the points up to about 0.5 m (19 ...
Page 308 When Driving i-ACTIVSENSE Display range 1. Target object Viewing the screen Display/Icon Content Projected vehicle path lines (yellow) Indicates the approximate projected path of the vehicle. Moves in conjunction with the steering wheel operation. The projected vehicle path lines (yellow) indicate the path the inner side of the vehicle is expected to travel.
Page 309 NOTE The setting can be changed so that the projected vehicle path lines are not displayed. Refer to the Settings section in the Mazda Connect Owner's Manual. How to use the projected vehicle path line function 1. (Screen display) 2. (Actual condition) Make sure that there are no obstructions within the projected vehicle path lines.
Page 310 When Driving i-ACTIVSENSE CAUTION The parking sensor detection range has limitations. For example, obstructions closing in from the side and objects short in height may not be detected. Always conﬁrm the safety around the vehicle visually when driving. For details, refer to the parking sensor obstruction detection indication and warning sound.
Page 311 When Driving i-ACTIVSENSE Range of displayed screen image 1. Target object NOTE In the top view screen, the areas in black at the front and rear of the vehicle image  and the seams where each of the camera images merge are blind spots. Because images displayed in the top view screen are processed from each camera, ...
Page 312 2.0 m (78 in) from the rear end of the bumper. NOTE The setting can be changed so that the projected vehicle path lines are not displayed. Refer to the Settings section in the Mazda Connect Owner's Manual. How to use the projected vehicle path line function 4-164...
Page 313 When Driving i-ACTIVSENSE CAUTION The front of the vehicle swings out wide when turning the steering wheel while reversing. Maintain sufficient distance between the vehicle and an obstruction. The parking sensor detection range has limitations. For example, obstructions closing in from the side and objects short in height may not be detected. Always conﬁrm the safety around the vehicle visually when driving.
Page 314 When Driving i-ACTIVSENSE 1. Back the vehicle into the parking space by turning the steering wheel so that the vehicle enters the center of the parking space. 1. (Screen display) 2. (Actual condition) 2. After the vehicle starts entering the parking space, stop and adjust the steering wheel so that the distance between the vehicle width lines and the sides of the parking space on the left and right are roughly equal, and then continue backing up slowly.
Page 315 When Driving i-ACTIVSENSE vehicle in the best possible position. (If the parking space has division lines, check whether the vehicle width guide lines are parallel to them.) 1. (Screen display) 2. (Actual condition) ▼ Top View/Rear Wide View Use the top view/rear wide view to assist in checking the safety of the surrounding area when accelerating from a stop, parking, or stopping the vehicle.
Page 316 When Driving i-ACTIVSENSE Range of displayed screen image 1. Target object NOTE In the top view screen, the areas in black at the front and rear of the vehicle image  and the seams where each of the camera images merge are blind spots. Because images displayed in the top view screen are processed from each camera, ...
Page 317 When Driving i-ACTIVSENSE Viewing the screen Display/Icon Content Extended vehicle width lines and These guide lines indicate the approximate width of the distance guide lines (blue & red) vehicle and distance to a point measured from the rear of the vehicle (from the end of the bumper). The red lines indicate the points up to about 0.5 m ...
Page 318 When Driving i-ACTIVSENSE 1. Obstruction 2. Margin of error Side camera 1. Obstruction 2. Margin of error Rear camera 1. Obstruction 2. Margin of error There is a steep up or down grade in the road at the front or rear of the vehicle If there is a steep up or down grade in the road at the front or rear of the vehicle, obstructions picked up by the camera can appear farther or closer than the actual distance from the vehicle.
Page 319 When Driving i-ACTIVSENSE Front camera 1. Appears further than actual distance 2. Distance of obstruction being viewed on screen 3. Actual distance of obstruction from vehicle 4. Actual obstruction 5. Obstruction appearing on screen 6. Appears closer than actual distance 4-171...
Page 320 When Driving i-ACTIVSENSE Side camera 1. Appears further than actual distance 2. Distance of obstruction being viewed on screen 3. Actual distance of obstruction from vehicle 4. Actual obstruction 5. Obstruction appearing on screen 6. Appears closer than actual distance 4-172...
Page 321 When Driving i-ACTIVSENSE Rear camera 1. Appears further than actual distance 2. Distance of obstruction being viewed on screen 3. Actual distance of obstruction from vehicle 4. Obstruction appearing on screen 5. Actual obstruction 6. Appears closer than actual distance NOTE If the vehicle is on a slope, obstructions taken by the camera can appear farther or closer than the actual distance from the vehicle.
Page 322 When Driving i-ACTIVSENSE Side camera 1. (Screen display) 2. (Actual condition) 4-174...
Page 323 ▼ System Problem Indication Center display indication Cause Action to be taken “No camera signal.” is displayed The control unit might be damaged. Have your vehicle inspected by an Authorized Mazda Screen is pitch-black and blank The camera might be damaged. Dealer. 4-175...
Page 324: Cruise Control
Stop & Go function (MRCC with Stop & Go function) on page 4-111. Hilly terrain If the Mazda Radar Cruise Control with Steep inclines Stop & Go function (MRCC with Stop Heavy or unsteady traffic &...
Page 325 If the headway control function is Any of the doors is opened.  disabled using a Mazda Connect The driver's seat belt is unfastened.  setting, the system switches to cruise The brake pedal is depressed.
Page 326 When Driving Cruise Control Instrument cluster (Basic display) NOTE Even after releasing the RES switch, the cruise control accelerates/decelerates continuously until the set speed displayed in the instrument cluster and on the active driving display is reached. If you want to stop accelerating/ decelerating, change the set speed or cancel the system (such as by depressing the brake pedal).
Page 327 When Driving Cruise Control Slightly depress the brake pedal.  Press the CANCEL switch.  If the RES switch is pressed when the vehicle speed is 30 km/h (19 mph) or higher, the system reverts to the previously set speed. NOTE If any of the following conditions ...
Page 328: Tire Pressure Monitoring System
Refer to the Vehicle Status Monitor illuminates, you should stop and section in the Mazda Connect check your tires as soon as possible, Owner's Manual. and inﬂate them to the proper pressure. Driving on a signiﬁcantly NOTE under-inﬂated tire causes the tire to...
Page 329: (Tpms)
If the TPMS warning light ﬂashes, there pressure, even if under-inﬂation has may be a problem with the system. not reached the level to trigger Consult an Authorized Mazda Dealer illumination of the TPMS low tire to have the system inspected. pressure telltale.
Page 330 Do not install non-genuine wheels. If TPMS. wheels other than genuine ones are Have an Authorized Mazda Dealer do installed, it may not be possible to the registration or register the ID signal install the tire pressure sensors.
Page 331: Rear View Monitor
When the display is cold, images camera (location, installation angle) may have deviated. Always consult may course across the monitor or the an Authorized Mazda Dealer to have screen and may be dimmer than the vehicle inspected. usual, which could cause difficulty in If “No camera signal.”...
Page 332 When Driving Rear View Monitor If force is applied to the steering wheel, the guide lines may not display. Loosen your grip on the steering wheel to allow the guide lines to display. ▼ Rear View Parking Camera Location 1. Rear view parking camera 4-184...
Page 333 When Driving Rear View Monitor ▼ Switching to the Rear View Monitor Display The system switches to the rear view monitor when the power switch is switched ON and shifting the selector lever to the reverse (R) position. NOTE When the selector lever is shifted from reverse (R) position to another selector lever position, the screen returns to the previous display.
Page 334 When Driving Rear View Monitor Images displayed on the monitor from the rear view parking camera are reversed  images (mirror images). Some optionally installed vehicle accessories may be picked up by the camera. Do  not install any optional parts that can interfere with the camera view, such as illuminating parts or parts made of reﬂective material.
Page 335 When Driving Rear View Monitor These lines indicate the approximate distance to a point measured from the vehicle's rear (from the end of the bumper). The blue line indicates the point about 0.5 m (19 in) from the rear bumper. The red and yellow lines, which change position after you turn the steering wheel, indicate the points about 0.5 m (19 in) for the red line and 1.0 m (39 in) and 2.0 m (78 in) for the yellow lines from the rear bumper (at the center point of each of...
Page 336 When Driving Rear View Monitor CAUTION The guide lines on the screen are ﬁxed lines. They are not synced to the driver's turning of the steering wheel. Always be careful and check the area to the vehicle's rear and the surrounding area directly with your eyes while backing up. ▼...
Page 337 When Driving Rear View Monitor 2. Before backing the vehicle into the parking space, turn the steering wheel while referring to the projected vehicle path display so that the vehicle enters the center of the parking space. 1. (Display condition) 2.
Page 338 When Driving Rear View Monitor 3. After your vehicle begins entering the parking space, continue backing up slowly so that the distance between the vehicle width lines and the sides of the parking space on the left and right are roughly equal. 1.
Page 339 When Driving Rear View Monitor the vehicle in the best possible position. (If the parking space has division lines, check whether the vehicle width guide lines are parallel to them.) 1. (Display condition) 2. (Vehicle condition) 6. When the selector lever is shifted from reverse (R) position to another selector lever position, the screen returns to the previous display.
Page 340 When Driving Rear View Monitor When parking in a space with a division line on only one side of the parking space,  the division line and the vehicle width guide line appear aligned in the monitor, but they may not actually be aligned on the ground. Fixed assist lines display type NOTE Images displayed on the monitor from the rear view parking camera are reversed...
Page 341 When Driving Rear View Monitor 3. After your vehicle begins entering the parking space, continue backing up slowly so that the distance between the vehicle width lines and the sides of the parking space on the left and right are roughly equal. 1.
Page 342 When Driving Rear View Monitor the vehicle in the best possible position. (If the parking space has division lines, check whether the vehicle width guide lines are parallel to them.) 1. (Display condition) 2. (Vehicle condition) 6. When the selector lever is shifted from reverse (R) position to another selector lever position, the screen returns to the previous display.
Page 343 When Driving Rear View Monitor When parking in a space with a division line on only one side of the parking space,  the division line and the vehicle width guide line appear aligned in the monitor, but they may not actually be aligned on the ground. ▼...
Page 344 When Driving Rear View Monitor 4. Actual distance between the vehicle and object. 5. Object at actual position 6. Object on screen Three-dimensional object on vehicle rear Because the distance guide lines are displayed based on a ﬂat surface, the distance to the three-dimensional object displayed on the screen is different from the actual distance.
Page 345 When Driving Rear View Monitor surface. When backing up near an overhanging object, conﬁrm the rear and surrounding conditions directly with your eyes. 1. (Screen display) 2. (Actual view) 4-197...
Page 346: Parking Sensor System
When Driving Parking Sensor System Parking Sensor System ▼ Parking Sensor System The parking sensors use ultrasonic sensors which detect obstructions around the vehicle when the vehicle is driven at low speeds, such as during garage or parallel parking, and a buzzer sound and detection indicator notify the driver of the approximate distance from the vehicle to the surrounding obstruction.
Page 347 Very tall objects, and those which are wide at the top  Small, short objects  Always have the system inspected at an Authorized Mazda Dealer if any shock is  applied to the bumpers, even in a minor accident. If the sensors are deviated, they cannot detect obstructions.
Page 348 Parking Sensor System The system may have a malfunction if a message indicating a system malfunction is  displayed. Have your vehicle inspected by an Authorized Mazda Dealer. A message may be displayed even when the ambient temperature is extremely ...
Page 349 When Driving Parking Sensor System Distance between vehicle and obstruc- Display tion Without 360° view monitor Rear ultrasonic sen- Front ultrasonic sor/Rear corner ul- Without front ul- With front ultra- With 360° view sensor /Front cor- trasonic sensor/ trasonic sensor sonic sensor and monitor ner ultrasonic sen-...
Page 350 When Driving Parking Sensor System If the switch is pressed again, the Without 360°view monitor parking sensor becomes operational and the indicator light turns off. 1. Front ultrasonic sensor gauge 2. Right front corner ultrasonic sensor 1. Indicator light gauge NOTE 3.
Page 351 Refer to the Settings section in the Mazda Connect Owner's Manual. (Vehicles with 360° View Monitor) Check the reason for the indication When the detection indicator is set to displaying on the center display or “Display”, even with the 360°...
Page 352 When Driving Parking Sensor System ▼ Parking Sensor Warning Beep Informs the driver of the approximate distance from the vehicle to the obstruction using warning beeps depending on the distance. If multiple obstructions are detected at the same time, warning beeps are activated according to the distance to the nearest obstruction.
Page 353 The sound volume (each of front and rear) can be changed.  Refer to the Settings section in the Mazda Connect Owner's Manual. ▼ When Warning Indicator/Beep is Activated The system notiﬁes the driver of an abnormality by activating the beep sound and the indicator light.
Page 354 Remove any foreign matter from the sensor area. If the system does not sensor is dirty is displayed. recover, have the vehicle inspected by an Authorized Mazda Dealer. A certain obstruction detec- Foreign matter may have gotten on the sensor area corresponding to tion indication is continuous- the detection indicator.
Page 355 Convenient Ways to Use the Accessory Sockets....5-39 Climate Control System..5-10 AC Power Outlet ....5-40 Cup Holder......5-42 Mazda Connect...... 5-14 Bottle Holder.......5-43 What is Mazda Connect ?..5-14 Assist Grips......5-44 Mazda Connect Basic Rear Coat Hooks....5-44 Operations......5-18 Storage Compartments..5-45 *Some models.
Page 356: Climate Control System
Consult a professional, government certiﬁed repairer for the inspection or repair because a special device is required for the air conditioner maintenance. For details, consult an Authorized Mazda Dealer. 1. Sunlight sensor Interior temperature sensor 1. Label 1. Interior temperature sensor...
Page 357: Climate Control System Operation Area
Interior Features Climate Control System Climate Control System Operation Area ▼ List of Climate Control System Switches/Icons Climate control system information is displayed on the display. Auto operation screen ① AUTO switch..................page 5-4 ② Seat warmer icon ................page 2-21 ③...
Page 358 Mazda Connect settings. operation screen to the manual Refer to the Settings section in the Mazda operation screen. Press the AUTO Connect Owner's Manual. switch to switch from the manual...
Page 359 Interior Features Climate Control System To reduce power consumption by NOTE  the climate control system, warm AUTO switch indicator light airﬂow may not be supplied when the ambient temperature is 25 °C  (77 °F) or more. The indicator light turns on during auto operation.
Page 360 Interior Features Climate Control System ▼ Air Intake Selector Icon Auto/Day/Night, and adjust the operation volume (mute or 3 levels). Outside or recirculated air positions Touch the to close the screen. can be selected. Touch the NOTE select outside/recirculated air For safety reasons, the setting screen is positions.
Page 361: Basic Climate Control System Operation
Interior Features Climate Control System NOTE Basic Climate Control When on the auto operation screen, System Operation  touch the seat indication in the center of the screen to display the ▼ Air Conditioner Basic Operation , and icons. Operate the air conditioner (cooling, When swiping the ...
Page 362 Interior Features Climate Control System ▼ Adjusting the Vents 1. Knob Directing airﬂow Center Vents To adjust the direction of airﬂow, move Air vent open/close the adjustment knob. NOTE When using the air conditioner  under humid ambient temperature conditions, the system may blow fog from the vents.
Page 363 Interior Features Climate Control System Dashboard and Floor Vents NOTE The location airﬂow exits the air vents and the airﬂow amount may change depending on the open or close status of the air vents. ▼ Windshield Defrosting and Defogging WARNING Set the temperature control to the hot Floor Vents or warm position when defogging...
Page 364: Convenient Ways To Use The Climate Control System
Interior Features Climate Control System Operate the temperature setting Convenient Ways to Use  switch/ (red) to increase the the Climate Control airﬂow temperature System Only use the defroster when the  window glass needs to be defogged. The power consumption of the air ▼...
Page 365 Interior Features Climate Control System The high voltage battery or the Power switch position lead-acid battery charge is low The doors/liftgate are open Function The power switch is switched to a sys- sys- position other than OFF There is a problem with the vehicle off) If the operation conditions are not Cooling/heating...
Page 366 ) the battery is removed or installed, or function. when no GPS signal has been received. When GPS signals are 1. Select “Settings” from the Mazda received, the Climate Control Timer Connect home screen. becomes operational. 2. Select “EV Settings”.
Page 367 Smartphone while the remote climate control is operating. To operate the remote climate control, switch the power switch OFF. Please refer to local Mazda website for more Connected Service information. CAUTION To use the remote climate control, it is necessary to subscribe to Connected Service.
Page 368: Mazda Connect
What is Mazda Connect ? ▼ What is Mazda Connect ? This manual only indicates a part of the information for Mazda Connect. For details, check the Web owner's manual at the Mazda site for each country and region. 1. Radio ®...
Page 369 /Apple CarPlay /Android Auto Audio Off Displays text messages received by the mobile device paired to Mazda Connect and notiﬁcations from the vehicle. The number of notiﬁca- Notiﬁcations tions is displayed, and if they exceed 100, 99+ is displayed. If a serious problem occurs, the background color changes to amber or red.
Page 370 Interior Features Mazda Connect Menu Explanation You can change the settings for the Mazda Connect screen, sound set- tings, and the vehicle functions. EV Settings: Conﬁgures charging schedule, climate control timer, and more. In-Vehicle Displays: Conﬁgures settings and content for all in-vehicle displays.
Page 371 NOTE Do not use Mazda Connect for a long time with the EV system stopped.  Otherwise, the lead-acid battery power could be depleted. If a mobile phone or CB radio is used in or near the vehicle, it could cause noise to ...
Page 372: Mazda Connect Basic Operations
Interior Features Mazda Connect Mazda Connect Basic Operations ▼ Mazda Connect Basic Operations NOTE The explanation of functions described in this manual may differ from the actual operation, and the shapes of screens and buttons and the letters and characters displayed may also differ from the actual appearance.
Page 373 Interior Features Mazda Connect Item Explanation Commander knob (select): Depress the commander knob to select the desired on-screen function you want to use. Entertainment button: The audio source screen last used is displayed. (During Apple CarPlay™ or Android Auto™ music playback) Displays the Apple CarPlay™...
Page 374 Press the volume knob to mute/pause the audio. Press the knob again to resume. Power off/on Press and hold to turn off the Mazda Connect power and turn off the screen. Press and hold again to turn on the Mazda Connect power.
Page 375 Displays the Apple CarPlay™ or Android Auto™ home screen. (While Apple CarPlay™ or Android Auto™ is connected) Press and hold while the Mazda Connect screen is displayed to switch the screen from Mazda Connect to Apple CarPlay™ or Mazda Connect to Android Auto™.
Page 376 Interior Features Mazda Connect ▼ Audio Remote Control Switch Operation The audio remote control switch is on the left side of the steering wheel. You can operate basic audio functions, pick up/hang up the phone, or activate voice control using the switch.
Page 377 Interior Features Mazda Connect Item Explanation SOURCE button: The audio source can be switched each time the button is pressed. In addition, when the button is pressed and held, the current au- SOURCE dio source is muted and the audio source selection screen is displayed.
Page 378 When an Apple CarPlay™ or Android Auto™ compatible device is connected, the ® Mazda Connect voice recognition system is disabled to allow the use of Siri Android Auto™ voice recognition at any time with the talk/pick-up button. Commands usable at any time “Help”...
Page 379 When the Barge-In setting is on, voice commands can be made even while the  voice guidance is being announced. For details on Barge-In, refer to the System Settings section in the Mazda Connect Owner's Manual. For details on voice commands which can be used on the navigation screen, refer ...
Page 380 Interior Features Mazda Connect Cancel  Menu  Navigation  Entertainment  Communication  Setting Voice Recognition Settings  Display Off  Music Play Artist (You can also use “Play Artist {Artist name}”.)  Play Album (You can also use “Play Album {Album Name}”.) ...
Page 381 By using this weather service, you release and waive any claims against Sirius XM Radio Inc. and Mazda Motor Corporation and all of their respective affiliates with regard to this service.
Page 382 “safety for life”, but is merely supplemental and advisory in nature and, therefore, cannot be relied upon as safety critical. Neither SiriusXM nor Mazda is responsible for any errors in accuracies in the SiriusXM data services or its use in applications.
Page 383 TECHNOLOGY OR GOVERNMENT REGULATION MAY RENDER THE SERVICES AND/OR APPLICATIONS OBSOLETE AND/OR UNUSABLE. TO THE EXTENT NOT PROHIBITED BY LAW, IN NO EVENT SHALL MAZDA OR ITS AFFILIATES BE LIABLE FOR PERSONAL INJURY, OR ANY INCIDENTAL, SPECIAL, INDIRECT OR CONSEQUENTIAL DAMAGES WHATSOEVER, INCLUDING, WITHOUT...
Page 384 OTHER CONTENT PROVIDED BY GOOGLE, ITS AFFILIATES, OR THIRD PARTY PROVIDERS; MAZDA DOES NOT GUARANTEE AGAINST LOSS OF APPLICATION DATA, WHICH MAY BE LOST AT ANY TIME; MAZDA DOES NOT GUARANTEE THAT THE APPLICATION OR ANY SERVICES PROVIDED THROUGH THEM WILL BE PROVIDED AT ALL TIMES OR THAT ANY OR ALL SERVICES WILL BE AVAILABLE AT ANY PARTICULAR TIME OR LOCATION.
Page 385 TECHNOLOGY OR GOVERNMENT REGULATION MAY RENDER THE SERVICES AND/OR APPLICATIONS OBSOLETE AND/OR UNUSABLE. TO THE EXTENT NOT PROHIBITED BY LAW, IN NO EVENT SHALL MAZDA OR ITS AFFILIATES BE LIABLE FOR PERSONAL INJURY, OR ANY INCIDENTAL, SPECIAL, INDIRECT OR CONSEQUENTIAL DAMAGES WHATSOEVER, INCLUDING, WITHOUT...
Page 386 Interior Features Mazda Connect iPhone 11 iPhone XS Max iPhone XS iPhone XR iPhone X iPhone 8 Plus iPhone 8 iPhone 7 Plus iPhone 7 iPhone SE iPhone 6s Plus iPhone 6s iPhone 6 Plus iPhone 6 iPhone 5s iPod touch (7th generation)
Page 387 Interior Features Mazda Connect Gracenote, the Gracenote logo and logotype are either a registered trademark or a  trademark of Gracenote, Inc. in the United States and/or other countries. Regarding the license for the audio ampliﬁer (except vehicles with Bose audio)
Page 388: Connected Service (If Applicable)
Please refer to connected services terms and privacy policy available on the Mazda Canada website for more details. Connected Services owner’s manual:...
Page 389 (U.S.A. and Canada) Privacy Policy Mazda maintains a Privacy Statement which describes how we collect, use, share, store and secure data from your vehicle equipped with connected services. We provide you with connected services by collecting and using your personal information and vehicle location, health and driving data.
Page 390: Interior Equipment
Interior Features Interior Equipment If your vehicle is equipped with a Sunvisors vanity mirror light, it will illuminate when you open the cover. ▼ Sunvisors The vanity mirror will only illuminate in the tilt range shown in the ﬁgure. Lower the sunvisor to block sunlight from the front.
Page 391: Interior Lights
Interior Features Interior Equipment Interior Lights Switch Overhead Lights The door interlock can be switch- ▼ Interior Lights ed ON/OFF. When the door interlock is OFF, NOTE the indicator light in the switch Do not leave the lights on for long turns on.
Page 392 Interior Features Interior Equipment Map lights NOTE Once the rear map lights have been Front  turned off, they will turn on and off Press the switch to illuminate the front in conjunction with the overhead map lights, and then press the switch light operation.
Page 393: Accessory Sockets
The power switch is switched OFF Accessory Sockets  with all doors closed. ▼ Accessory Sockets NOTE Only use genuine Mazda accessories The illumination time differs  or the equivalent requiring no greater depending on the operation. than 120 W (DC 12 V, 10 A).
Page 394: Ac Power Outlet
Interior Features Interior Equipment Do not use accessories that are not AC Power Outlet genuine Mazda accessories or the equivalent. ▼ AC Power Outlet Close the cover when the The AC power outlet can be used as a accessory socket is not in use to...
Page 395 Interior Features Interior Equipment 2. Connect the plug to the AC power CAUTION outlet. Always close the cover when it is not in use. If foreign matter or liquid penetrates the AC power outlet, it may cause a problem. Insert electrical appliance plugs into the AC power outlet securely.
Page 396: Cup Holder
Interior Features Interior Equipment Cabin temperature is extremely hot Cup Holder  Noise may occur during radio  operation depending on the ▼ Cup Holder electrical appliance being used. WARNING Never use a cup holder to hold hot liquids while the vehicle is moving: Using a cup holder to hold hot liquids while the vehicle is moving is dangerous.
Page 397: Bottle Holder
Interior Features Interior Equipment ▼ Front Bottle Holder ▼ Bottle Holder Bottle holders are on the inside of the doors. 1. Bottle holder CAUTION Do not use the bottle holders for containers without caps. The contents ▼ Rear may spill when opening/closing the door or while driving the vehicle.
Page 398: Assist Grips
Interior Features Interior Equipment Assist Grips Rear Coat Hooks ▼ Assist Grips ▼ Rear Coat Hooks Always hang clothes on the coat hooks WARNING and the assist grips without hangers. Do not use the assist grips when getting in and out of the vehicle or getting out of a seat: An assist grip could break under a heavy load resulting in injury.
Page 399: Storage Compartments
Interior Features Interior Equipment Push and release to open. Storage Compartments ▼ Storage Compartments WARNING Keep storage boxes closed when driving: Driving with the storage boxes open is dangerous. To reduce the possibility of ▼ Storage Pocket injury in an accident or a sudden stop, keep the storage boxes closed when To use, open the lid.
Page 400 Interior Features Interior Equipment ▼ Center Console apply excessive force to the loops as it will damage them. To open the lid, slide it all the way back, pull the lever, and then lift the lid Cargo Sub-Compartment 1. Lift the luggage mat. CAUTION Do not put your hands or ﬁngers around the moving parts of the lid...
Page 401 Maintenance and Care How to keep your Mazda in top condition. Essential Information....6-2 Brake Fluid......6-12 Introduction......6-2 Washer Fluid....... 6-13 Lubrication system....6-14 Wiper Blades....... 6-14 Scheduled Maintenance.... 6-4 Lead-acid Battery....6-19 Scheduled Maintenance..6-4 Key Battery Replacement..6-21 Tires........6-23 Owner Maintenance....
Page 402: Essential Information
 that you completed the maintenance Factory-trained Mazda technicians and yourself, displaying mileage and the genuine Mazda parts are best for your date the work was performed. Also, vehicle. Without this expertise and the receipts for the replacement parts parts that have been designed and (ﬂuid, ﬁlters, etc.) indicating the date...
Page 403 Any auto repair shop using parts equivalent to your Mazda's original equipment may perform maintenance. But we recommend that it always be done by an Authorized Mazda Dealer using genuine Mazda parts. Selecting “Vehicle Status Monitor” enables the system to notify you of your vehicle's approaching inspection/ servicing period.
Page 404: Scheduled Maintenance
The display/wrench indication will come on before reaching the maximum interval of 16,000 km (10,000 miles), or 12 months (after the previous maintenance). Refer to the Information section in the Mazda Connect Owner's Manual. Please contact an Authorized Mazda Dealer if necessary.
Page 405 The display/wrench indication will come on before reaching the maximum interval of 16,000 km (10,000 miles), or 12 months (after the previous maintenance). Refer to the owner's manual section of mazda.ca for the Mazda Connect owner's manual or contact an Authorized Mazda Dealer if necessary.
Page 406 Maintenance and Care Scheduled Maintenance Number of months or kilometers (miles), whichever comes ﬁrst. Months Maintenance Interval ×1000 km ×1000 miles Body condition inspection for rust, corro- sion and perforation Cabin air ﬁlter Replace every 40,000 km (25,000 miles) or 24 months. Tire rotation Rotate every 16,000 km (10,000 miles).
Page 407: Owner Maintenance
If you are unsure about any servicing or Bring any problem to the attention of maintenance procedure, have it done an Authorized Mazda Dealer or by an Authorized Mazda Dealer. qualiﬁed service technician as soon as possible.
Page 408: Hood
Maintenance and Care Owner Maintenance If you must run the EV system while Hood working under the hood, make certain that you remove all jewelry ▼ Hood (especially rings, bracelets, watches, and necklaces) and all neckties, WARNING scarves, and similar loose clothing before getting near the cooling fan Always check that the hood is closed which may turn on unexpectedly:...
Page 409 Maintenance and Care Owner Maintenance 3. Grasp the support rod in the 3. Lower the hood slowly to a height padded area and secure it in the of about 20 cm (7.9 in) above its support rod hole indicated by the closed position and then let it drop.
Page 410: Motor Compartment Overview
Maintenance and Care Owner Maintenance Motor Compartment Overview ▼ Motor Compartment Overview 1. Brake ﬂuid reservoir 2. Lead-acid battery 3. Fuse block 4. Cooling system cap 5. Coolant reservoir 6. Windshield washer ﬂuid reservoir 6-10...
Page 411: Coolant
When the EV system and radiator are Rinse it off quickly if spilled. hot, scalding coolant and steam may shoot out under pressure and cause serious injury. NOTE Changing the coolant should be done by an Authorized Mazda Dealer. 6-11...
Page 412: Brake Fluid
If the coolant reservoir is empty or new Inspect the ﬂuid level in the reservoir coolant is required frequently, consult regularly. It should be kept between an Authorized Mazda Dealer. the MAX and MIN lines. The level normally drops with accumulated distance, a condition associated with wear of brake linings.
Page 413: Washer Fluid
Maintenance and Care Owner Maintenance Inspect ﬂuid level in the washer ﬂuid Washer Fluid reservoir; add ﬂuid if necessary. ▼ Inspecting Washer Fluid Level WARNING Use only windshield washer ﬂuid or plain water in the reservoir: Using radiator antifreeze as washer ﬂuid is dangerous.
Page 414: Lubrication System
Maintenance and Care Owner Maintenance Lubrication system Wiper Blades ▼ Lubrication system ▼ Wiper Blades All moving points on the vehicle body, CAUTION such as door and hood hinges and locks, should be lubricated to move Hot waxes applied by automatic car smoothly.
Page 415 3. Slide the blade component in the blades. If they are replaced with direction of the arrow while wiper blades other than a Mazda pressing the wiper arm tab to genuine product, they may not wipe with the same efficiency as the genuine product.
Page 416 Maintenance and Care Owner Maintenance remove the blade component from the blade rubber from the blade the wiper arm. holder. 4. Pull the blade rubber in the direction of the arrow and slide it to a position where the blade holder groove can be checked.
Page 417 Maintenance and Care Owner Maintenance 7. After pulling the blade rubber in the CAUTION direction of the arrow and sliding the blade rubber to a position to To prevent damage to the check the blade holder groove, windshield let the wiper arm down slide the blade rubber end in the easily, do not let it slap down on opposite direction.
Page 418 Maintenance and Care Owner Maintenance 2. Remove the stopper and raise the 4. Pull down the blade rubber and wiper arm. slide it out of the blade holder. 5. Remove the metal stiffeners from 3. Firmly rotate the wiper blade to the the blade rubber and install them in right until it unlocks, then remove the new blade.
Page 419: Lead-Acid Battery
Maintenance and Care Owner Maintenance Lead-acid Battery Always keep lead-acid batteries ▼ Lead-acid Battery out of the reach of children: Allowing children to play near WARNING lead-acid batteries is dangerous. Lead-acid battery ﬂuid could cause serious injuries if it gets in the eyes or on the skin.
Page 420 If the vehicle will not be used for an battery cover.  extended time, disconnect the lead-acid battery cables and charge the lead-acid battery every 6 weeks. ▼ Lead-acid Battery Replacement Contact an Authorized Mazda Dealer for lead-acid battery replacement. 6-20...
Page 421: Key Battery Replacement
ﬂash, the battery may be Replacing the battery at an Authorized dead. Mazda Dealer is recommended. If Replace with a new battery before the replacing the battery by yourself, transmitter becomes unusable.
Page 422 Maintenance and Care Owner Maintenance 3. Insert a tape-wrapped ﬂathead 7. Insert a new battery into the screwdriver into the gap and slide it transmitter so that the positive pole in the direction of the arrow. is facing up. 8. Install the cap. 4.
Page 423: Tires
Maintenance and Care Owner Maintenance Use only a Mazda-genuine tire valve Tires cap: Use of a non-genuine part is ▼ Tires dangerous as the correct tire air For reasons of proper performance, pressure cannot be maintained if the safety, and better energy efficiency, tire valve becomes damaged.
Page 424 Always use tires that are in good with your vehicle. Have an Authorized condition: Mazda Dealer perform tire rotation. Driving with worn tires is dangerous. Reduced braking, steering, and traction could result in an accident.
Page 425 You should replace the tire before the For details, contact an Authorized  band crosses the entire tread. Mazda Dealer. NOTE Tires degrade over time, even when Proper tire balancing provides the best they are not being used on the road. It...
Page 426: Light Bulbs
Maintenance and Care Owner Maintenance The LED bulb has to be replaced with Light Bulbs the unit. We recommend an Authorized Mazda Dealer when the ▼ Light Bulbs replacement is necessary. Front 1. Side turn signal lights 2. Front side-marker lights 3.
Page 427: Fuses
If the same fuse blows again, avoid 4. Inspect the fuse and replace it if it is using that system and consult an blown. Authorized Mazda Dealer as soon as possible. ▼ Fuse Replacement Replacing the fuses on the vehicle's...
Page 428 2. Remove the fuse block cover. Do not replace the main fuse by yourself. Have an Authorized Mazda Dealer perform the replacement: Replacing the fuse by yourself is dangerous because the MAIN fuse is a high current fuse. Incorrect...
Page 429 Maintenance and Care Owner Maintenance ▼ Fuse Panel Description Fuse block (Motor compartment) FUSE RAT- PROTECTED COMPONENT 30 A Accessory sockets 20 A Windshield wiper de-icer ― ― ― ― ― ― ― ― 20 A BEV control system 6-29 *Some models.
Page 430 Maintenance and Care Owner Maintenance FUSE RAT- PROTECTED COMPONENT 10 A Motor control system 15 A Charge control system 10 A BEV control system 7.5 A Air conditioner 10 A BEV control system ― ― ― ― ― 20 A 15 A For protection of various circuits 15 A...
Page 431 Maintenance and Care Owner Maintenance FUSE RAT- PROTECTED COMPONENT ― ― 20 A Windshield wiper ― ― 30 A Accessory sockets 10 A BEV control system 15 A Audio 15 A For protection of various circuits 7.5 A Air bag 15 A Instrument cluster 15 A...
Page 432 Maintenance and Care Owner Maintenance Fuse block (Left side) FUSE RAT- PROTECTED COMPONENT ― ― ― ― ― ― 15 A Power door locks (Driver) 15 A Power door locks (Passenger) ― ― ― ― ― ― 30 A Power windows (Driver) 30 A Power windows (Passenger) 30 A...
Page 433 Maintenance and Care Owner Maintenance FUSE RAT- PROTECTED COMPONENT 15 A Illumination 10 A Brake lights 10 A Reverse lights 10 A Rear turn signal lights 10 A Taillights 10 A Taillights 7.5 A Air Bag ― ― 6-33...
Page 434: Appearance Care
Here are some examples of possible with it. damage, with tips on how to prevent Prevention them. It is necessary to have your Mazda Etching Caused by Acid Rain or washed and waxed to preserve its Industrial Fallout ﬁnish according to the instructions in Occurrence this section.
Page 435 Otherwise, the windshield wipers Chipped paint can lead to rust  will operate automatically which forming on your Mazda. Before this could catch your ﬁngers or damage happens, repair the damage by using the windshield wipers. Mazda touch-up paint according to When removing ice or snow, or the instructions in this section.
Page 436 Maintenance and Care Appearance Care When washing and waxing the NOTE vehicle, be careful not to apply Mazda is not responsible for  excessive force to any single area of scratches caused by automatic car the vehicle roof. Otherwise, you washes or improper washing.
Page 437 Maintenance and Care Appearance Care with plain water is ineffective, use a available depending on the type of car mild soap made for use on vehicles. wash machine. If the car washer nozzle is put too close to the vehicle, the Thoroughly rinse off all soap with force of the spray could damage or lukewarm or cold water.
Page 438 Appearance Care ﬂoor pan, even though these parts may CAUTION be coated with anti-corrosive material. If your Mazda is damaged and needs Thoroughly ﬂush the underbody and metal parts repaired or replaced, make wheel housings with lukewarm or cold sure the body shop applies water at the end of each winter.
Page 439 Maintenance and Care Appearance Care Do not rub the camera cover or lens strongly alkaline detergents. forcefully, or clean them with an Otherwise, these chemical agents abrasive or hard brush. can discolor or damage the surfaces resulting in a signiﬁcant loss in functionality.
Page 440: Interior Care
If a seat belt appears frayed or has abrasions, have it replaced by an Do not spray water into the vehicle Authorized Mazda Dealer: cabin: If a seat belt is used under such a Spraying water into the vehicle cabin is...
Page 441 Maintenance and Care Appearance Care 2. Wipe off the remaining detergent Sand or dirt  using a cloth soaked in clean water Grease or oil, such as hand cream  and wrung out well. Alcohol, such as in cosmetic or ...
Page 442 ﬂoor mats: ▼ Glass and Mirror Maintenance Cleaning the rubber ﬂoor mats with rubber cleaning products makes the Use Mazda genuine glass cleaner to ﬂoor mats slippery. remove oil ﬁlm from the glass or mirror. 6-42...
Page 443 Maintenance and Care Appearance Care This may cause an accident when depressing the accelerator or brake pedal or when getting in or out of the vehicle. After removing the ﬂoor mats for cleaning, always reinstall them securely (page 3-57). 6-43...
Page 444 MEMO 6-44...
Page 445 If Trouble Arises Helpful information on what to do if a problem arises with the vehicle. Parking in an Emergency.... 7-2 Tiedown Hooks ....7-19 Parking in an Emergency..7-2 Warning/Indicator Lights and Flat Tire........7-3 Warning Sounds..... 7-21 Tool Storage......7-3 If a Warning Light Turns On or Emergency Flat Tire Repair Flashes........
Page 446: Parking In An Emergency
If Trouble Arises Parking in an Emergency Parking in an Emergency ▼ Parking in an Emergency The hazard warning lights should always be used when you stop on or near a roadway in an emergency. The hazard warning lights warn other drivers that your vehicle is a traffic hazard and that they must take extreme caution when near it.
Page 447: Flat Tire
When replacing NOTE the tire, use a jack. Consult an Your vehicle may or may not be Authorized Mazda Dealer for details. equipped with a spare tire. For details, consult an Authorized Mazda Dealer. Designated jack-up position Tools are stored in the locations illustrated in the diagram.
Page 448: Emergency Flat Tire Repair Kit
▼ Emergency Flat Tire Repair Kit includes the following items. The emergency ﬂat tire repair kit included with your Mazda is for a temporary repair of a slightly damaged ﬂat tire resulting from running over nails or similar sharp objects on the road surface.
Page 449 Authorized Mazda Dealer. The emergency ﬂat tire repair kit  cannot be used in the following cases. Consult an Authorized Mazda Dealer. The period of effective use for the  tire sealant has expired. (The period of effectiveness is indicated on the bottle label.)
Page 450 If Trouble Arises Flat Tire 6. Pull out the air compressor hose injection hose to the tire valve, turn and the air compressor plug from the sleeve to the right, and tighten the air compressor. 1. Compressor hose 7. Install the air compressor hose which was pulled out of the air 1.
Page 451 In this case, the repair the speciﬁed tire inﬂation pressure. using the emergency ﬂat tire repair kit was not successful. Contact an Authorized Mazda Dealer.
Page 452 If Trouble Arises Flat Tire 12.Adhere the speed restriction sticker the sleeve of the injection hose to to an area where it can be viewed the left, and pull it out of the tire easily by the driver. valve. 15.Remove the air compressor hose from the injection valve of the bottle.
Page 453 If Trouble Arises Flat Tire to the nearest Authorized Mazda NOTE If the tire is not properly inﬂated, Dealer immediately and have the the tire pressure monitoring system ﬂat tire replaced. Replacement with warning light will illuminate (page a new tire is recommended. If the 4-180).
Page 454: Changing A Flat Tire
▼ Locking Lug Nuts nut, and be sure to hold the key square to it. If you hold the key at If your Mazda is equipped with the an angle, you may damage both key optional antitheft wheel lug nuts, a and nut.
Page 455: Troubleshooting For Charging
Shift the selector lever to the P Cancel the charging timer using position position. Charging EV Settings in Mazda Connect, other than P. timer is set. or the charging timer cancella- The high tion function. voltage bat-...
Page 456: Depleted Lead-Acid Battery
If Trouble Arises Depleted Lead-acid Battery Jump-Starting ▼ Jump-Starting The lead-acid battery might be depleted if the following conditions occur. The EV system does not start.  The selector lever cannot be shifted to a position other than P.  The horn sound is weak or it does not sound.
Page 457 If Trouble Arises Depleted Lead-acid Battery Keep all ﬂames and sparks away from open lead-acid battery cells because hydrogen gas is produced from open lead-acid battery cells while charging the lead-acid battery or adding lead-acid battery ﬂuid: Flames and sparks near open lead-acid battery cells are dangerous. Hydrogen gas, produced during normal lead-acid battery operation, could ignite and cause the lead-acid battery to explode.
Page 458 If Trouble Arises Depleted Lead-acid Battery 3. Remove the lead-acid battery cover. 4. Turn off the booster vehicle's engine and connect the jumper cables in the following order. Make sure that the jumper cables are securely connected so that they do not disconnect due to the vibrations.
Page 459 6. Start the EV system of your vehicle. 7. Disconnect the booster cables in the reverse order of their connection after the EV system is started. 8. Install the lead-acid battery cover. 9. Have your vehicle inspected by an Authorized Mazda Dealer as soon as possible. 7-15...
Page 460: Fully Discharged High Voltage Battery
▼ Actions to take if the remaining high voltage battery power is completely depleted If the high voltage battery power is completely depleted, the EV system stops and the vehicle cannot be driven. Stop the vehicle in a safe place and contact an Authorized Mazda Dealer. 7-16...
Page 461: Emergency Starting
If Trouble Arises Emergency Starting Push-Starting ▼ Push-Starting Do not push-start your Mazda. 7-17...
Page 462: Emergency Towing
This may cause internal needs to be towed, we recommend damage to the vehicle. that towing be done only by an Authorized Mazda Dealer or a commercial tow-truck service. Proper lifting and towing are necessary to prevent damage to the vehicle.
Page 463: Tiedown Hooks
If Trouble Arises Emergency Towing When towing a vehicle, transport it Tiedown Hooks with both front wheels raised off the ground or with all front and rear ▼ Tiedown Hooks wheels raised off the ground. If the vehicle is towed with the front CAUTION wheels grounded, the EV system may be damaged.
Page 464 If Trouble Arises Emergency Towing Rear 2. Tiedown eyelet Rear CAUTION 1. Lug wrench Do not use excessive force as it may 2. Tiedown eyelet damage the cap or scratch the 4. Hook the tying rope to the tiedown painted bumper surface. eyelet.
Page 465: Warning/Indicator Lights And Warning Sounds
Center display Do not drive with the brake system warning light illuminated. Contact an 1. Select “Information” on the home Authorized Mazda Dealer to have the screen. brakes inspected as soon as possible: 2. Select “Vehicle Status Monitor”. Driving with the brake system warning 3.
Page 466 ▼ EV System Problem Warning distribution system. Indication/Warning Light WARNING Do not drive with both the brake system warning light and ABS warning light illuminated. Have the vehicle towed to an Authorized Mazda Dealer to have the brakes inspected as soon as possible: 7-22...
Page 467 The indication/light displays/turns on problem. Have the vehicle inspected if the system has a problem. by an Authorized Mazda Dealer. Park the vehicle in a safe place immediately and contact an “High Voltage Battery Temperature Is Authorized Mazda Dealer.
Page 468 Have your vehicle inspected by an lever in the D or R position, the Authorized Mazda Dealer as soon as indication/light may display/turn on. possible. Otherwise, the charging If necessary, park the vehicle in a safe system may not charge the battery.
Page 469 Stop the Vehicle in a Safe Location” after the EV systems is restarted, displays/turns on contact an Authorized Mazda Dealer. There is a serious malfunction with the NOTE shift control system. Park the vehicle in a safe place If the message is displayed, the ...
Page 470 If this occurs, your brakes will function normally as if the vehicle had no ABS. Should this happen, consult an This warning has the following Authorized Mazda Dealer as soon as functions: possible. Parking brake warning/Indicator light NOTE...
Page 471 Gradually apply the brakes to lower the switched ON. If any of these vehicle's speed. conditions occurs, consult an Authorized Mazda Dealer as soon as Do not ignore the TPMS warning light possible. The system may not operate when it is turned on or ﬂashing: in an accident.
Page 472 EV system (leave it operating) and have Light (Red) the vehicle inspected at an Authorized Mazda Dealer. If the EV system is stopped, it may not be restarted. If the EV system cannot be started, switch the power switch OFF, place the...
Page 473 (except license plate lights). Have your passenger's seat belt warning vehicle inspected by an Authorized function to operate depending on Mazda Dealer. the weight of the item. CAUTION To allow the front passenger ...
Page 474 If Trouble Arises Warning/Indicator Lights and Warning Sounds ▼ Seat Belt Warning Light (Rear seat) Action to be taken (Red) Close the door/liftgate securely. ▼ Tire Pressure Monitoring System (TPMS) Warning Indication/ If the rear seat belts are not fastened Warning Light (Turns on) while the power switch is switched ON , the driver and the passenger are...
Page 475 If Trouble Arises Warning/Indicator Lights and Warning Sounds Do not ignore the TPMS warning light CAUTION when it is turned on or ﬂashing: Adjust the tire pressures while the Continuing to drive the vehicle while ignoring the illumination/ﬂashing of tires are cool. Because the air the TPMS warning light is dangerous pressure in the tires ﬂuctuates because a tire may burst which could...
Page 476 If Trouble Arises Warning/Indicator Lights and Warning Sounds “Low Key Fob Battery. Replace Battery” is displayed/When the light is ﬂashing When the key battery is low, the indication is displayed when the power switch is switched OFF. Action to be taken Replace the key battery.
Page 477 AUTOHOLD function. This message is indicated when the Mazda Radar Cruise Mazda Radar Cruise Control with Have your vehicle inspected by an Control Canceled. Drive Stop & Go function (MRCC with Stop Authorized Mazda Dealer.
Page 478 This message is indicated when the Have your vehicle inspected by an tion Canceled Drive Traffic Jam Assist (TJA) have been can- Authorized Mazda Dealer. Safely celed other than by the driver. This message is indicated when the Distance & Speed Alert Distance &...
Page 479 If Trouble Arises Warning/Indicator Lights and Warning Sounds *1*2*3 Content Action to be taken Display Anti Roll Away Engaged. This message is indicated when the Shift the selector lever to the P posi- Move Gear Selector Lev- AUTO P (parking lock) function oper- tion.
Page 480 There is no need to contact an Au- tain amount such as by repeatedly thorized Mazda Dealer. Drive the ve- Battery Saving Mode. opening/closing the doors or the lift- hicle for 5 minutes or longer to...
Page 481: Warning Sound Is Activated
Rear seat Refer to the Settings section in the Mazda Connect Owner's Manual. The warning beep only sounds if a seat belt is unfastened after being fastened. NOTE ▼ Power Switch Not Switched OFF When the power switch is switched ...
Page 482 If Trouble Arises Warning/Indicator Lights and Warning Sounds outside of the vehicle and a sound is Make sure that none of the above activated 1 time in the vehicle. conditions are present, and then press the door-lock switch again. Vehicles without advanced keyless ▼...
Page 483 Message is displayed and beep sound place. After stopping the vehicle, is activated simultaneously for about 5 contact an Authorized Mazda Dealer. seconds when using AUTOHOLD ▼ Brake Override Warning Beep function or when AUTOHOLD switch is operated.
Page 484 If there is a possibility of a collision deviated from the driving lane/road. with a vehicle ahead, a warning sound ▼ Mazda Radar Cruise Control with is activated at the same time as the Stop & Go function (MRCC with warning indications are displayed in Stop &...
Page 485 If Trouble Arises Warning/Indicator Lights and Warning Sounds ▼ Battery Saving Mode Warning Sound A warning sound is activated when the vehicle goes into Battery Saving Mode. Refer to Message Indicated on Multi-information Display on page 7-33. The warning sound will stop just after starting the EV system.
Page 486: When Liftgate Cannot Be Opened
If Trouble Arises When Liftgate Cannot be Opened an Authorized Mazda Dealer as soon When Liftgate Cannot be as possible. Opened ▼ When Liftgate Cannot be Opened If the lead-acid battery is dead, the liftgate cannot be unlocked and opened.
Page 487: Active Driving Display Does Not Operate
If the active driving display does not operate, switch the power switch off and then restart the EV system. If the active driving display does not operate even with the EV system restarted, have the vehicle inspected at an Authorized Mazda Dealer. 7-43...
Page 488: Windshield Wipers Operate At High Speed
The windshield wipers may operate at high speed if there is a problem with the wiper control. If the windshield wipers operate at high speed regardless of the wiper switch operation, have your vehicle inspected by an Authorized Mazda Dealer. 7-44...
Page 489 Tire Information (U.S.A.)..8-21 (Canada)......8-12 Tire Labeling......8-21 Location of the Tire Label Warranty........8-13 (Placard)......8-24 Warranties for Your Mazda ..Tire Maintenance....8-26 .......... 8-13 Vehicle Loading....8-28 Outside the United States/ Steps for Determining the Correct Canada....... 8-13 Load Limit......
Page 490: Customer Assistance
If it becomes necessary to have the components or wiring system for the Answers to many questions, including supplementary restraint system how to locate or contact a local Mazda modiﬁed to accommodate a person dealership in the U.S., can be found with certain medical conditions in here.
Page 491 5. Your dealer's name and location days or less. The arbitration decision is 6. Your question(s) not binding on you or Mazda unless you accept the decision. For more If you live outside the U.S.A., please information about BBB AUTO LINE,...
Page 492 You will also be asked to 7. California Civil Code Section provide: the approximate date of 1793.2 (d) requires that, if Mazda your acquisition of the vehicle, the or its representative is unable to vehicle's current mileage, the...
Page 493 Mazda or its agents 11.If you accept the arbitrator's AND the buyer has notiﬁed decision, Mazda will be bound by Mazda of the need for the repair the decision, and will comply with of the nonconformity; OR the decision within a reasonable...
Page 494 Mazda. All Authorized Mazda Dealers 2. Year and model of vehicle have both the knowledge and tools to 3. Vehicle Identiﬁcation Number keep your Mazda in top condition. In (VIN). Refer to the Vehicle our experience, any questions, Identiﬁcation Number on page problems, or complaints regarding the 9-2 for the location of the VIN.
Page 495 M2J 4Y8 binding arbitration. http://camvap.ca Provincial Administrators may be Your complete satisfaction is the goal reached locally: of Mazda Canada Inc. and our dealers. Province/Territory CAMVAP Number Mazda's participation in CAMVAP makes a valuable contribution to our British Columbia & Yu- 1 (800) 207-0685 achieving that goal.
Page 496 ▼ STEP 1 Discuss the matter with an Authorized Mazda Dealer. This is the quickest and best way to address the issue. If your concern has not been resolved by the CUSTOMER RELATIONS, SALES,...
Page 497 Customer Information and Reporting Safety Defects Customer Assistance 4. Purchase date and current mileage 5. Your dealer's name and location 6. Your question(s)
Page 498: Importer/Distributor
Ontario, L4B 3K5 Canada TEL: 1 (800) 263-4680 (in Canada) (905) 787-7000 (outside Canada) ▼ PUERTO RICO/U.S. Virgin Island International Automotive Distributor Group, LLC. (Mazda de Puerto Rico) P.O. Box 191850, San Juan, Puerto Rico 00919-1850 TEL: (787) 641-1777 ▼ GUAM...
Page 499: Reporting Safety Defects
You can also obtain other information about motor vehicle safety from http:// www.safercar.gov. NOTE If you live in the U.S.A., all correspondence to Mazda Motor Corporation should be forwarded to: Mazda North American Operations 200 Spectrum Center Drive Suite 100 Irvine, California 92618 P.O.
Page 500: Reporting Safety Defects (Canada)
Customer Information and Reporting Safety Defects Reporting Safety Defects Reporting Safety Defects (Canada) ▼ Reporting Safety Defects Canadian customers who wish to report a safety-related defect and concern to Transport Canada, Defect Investigations and Recalls, may telephone the toll free hotline 1-800-333-0510, or go to the Road Safety website at: https://www.tc.gc.ca/en/services/road.html 8-12...
Page 501: Warranty
Emission Control Warranty  receive satisfactory servicing in other Replacement Parts and Accessories  countries. We strongly recommend Limited Warranty that you NOT take your Mazda outside Tire Warranty  the United States/Canada. NOTE United States Warranty information varies depending However, in the event that you are on the country.
Page 502: Registering Your Vehicle In A Foreign Country (Except United States And Canada)
Parts, servicing techniques, and tools necessary to maintain and repair your vehicle may be unavailable. There might not be an Authorized Mazda Dealer in the country you plan to take your vehicle. The Mazda warranty is valid only in certain countries.
Page 503: Add-On Non-Genuine Parts And Accessories
Parts and Accessories ▼ Add-On Non-Genuine Parts and Accessories Non-genuine parts and accessories for Mazda vehicles can be found in stores. These may ﬁt your vehicle, but they are not approved by Mazda for use with Mazda vehicles. When you install...
Page 504: Cell Phones
Customer Information and Reporting Safety Defects Cell Phones Cell Phones Warning ▼ Cell Phones Warning WARNING Please comply with the legal regulations concerning the use of communication equipment in vehicles in your country: Use of any electrical devices such as cell phones, computers, portable radios, vehicle navigation or other devices by the driver while the vehicle...
Page 505: Event Data Recorder
EDR. certain crash or near crash-like situations, such as an air bag Mazda will not disclose any of the data deployment or hitting a road obstacle, recorded in an EDR to a third party data that will assist in understanding unless: how a vehicle’s systems performed.
Page 506: Recording Of Vehicle Data
Mazda and its subcontracting parties may obtain and use the recorded data for vehicle malfunction diagnosis, research and development, and quality improvement. Mazda will not disclose or provide any of the obtained data to a third party unless: An agreement from the vehicle ...
Page 507: Uniform Tire Quality Grading System (Utqgs)
Customer Information and Reporting Safety Defects Uniform Tire Quality Grading System (UTQGS) Uniform Tire Quality WARNING Grading System (UTQGS) The traction grade assigned to this tire is based on braking (straight ahead) ▼ Uniform Tire Quality Grading traction tests and does not include System (UTQGS) acceleration cornering (turning), hydroplaning, or peak traction...
Page 508 NHTSA and the tire manufacturers. The grade of tires available as standard or optional equipment on Mazda vehicles may vary with respect to grade. ALL PASSENGER VEHICLE TIRES MUST...
Page 509: Tire Information (U.s.a.)
Customer Information and Reporting Safety Defects Tire Information (U.S.A.) 14.Max. permissible inﬂation pressure Tire Labeling P215/65R15 95H is an example of a ▼ Tire Labeling tire size and load index rating. Here is Federal law requires tire manufacturers an explanation of the various to place standardized information on components of that tire size and load the sidewall of all tires.
Page 510 Customer Information and Reporting Safety Defects Tire Information (U.S.A.) the 45st week of 1997. After 2000 the numbers go to four digits. For “95” is the Load Index. This two-or example, the number 2102 means the three-digit number indicates how 21th week of 2002.
Page 511 Customer Information and Reporting Safety Defects Tire Information (U.S.A.) ▼ Information on Temporary Tires The grades represent the tire's ability to stop on wet pavement as measured Please refer to the sample below. under controlled conditions on speciﬁed government test surfaces of asphalt and concrete.
Page 512: Location Of The Tire Label (Placard)
Customer Information and Reporting Safety Defects Tire Information (U.S.A.) Location of the Tire Label “70” is the aspect ratio. This two-digit (Placard) number indicates the tire's ratio of height to width. ▼ Location of the Tire Label (Placard) You will ﬁnd the tire label containing tire inﬂation pressure by tire size and “D”...
Page 513 Customer Information and Reporting Safety Defects Tire Information (U.S.A.) NOTE WARNING Some spare tires require higher inﬂation pressure. Always check the tire inﬂation 8. Visually inspect the tires to make pressures on a regular basis according sure there are no nails or other to the recommended tire inﬂation objects embedded that could poke pressure on the tire label and in...
Page 514: Tire Maintenance
To equalize tread wear, rotate the tires which the tire beads are seated. every 16,000 km (10,000 miles) at the latest or sooner if irregular wear develops. Mazda recommends to rotate every 8,000 km (5,000 miles) to help increase tire life and distribute wear more evenly.
Page 515 Customer Information and Reporting Safety Defects Tire Information (U.S.A.) Improper wheel alignment NOTE  Out-of-balance wheel Tires degrade over time, even when  Severe braking they are not being used on the road. It  is recommended that tires generally be After rotation, inﬂate all tire pressures replaced when they are 6 years or to speciﬁcation on page 9-5 and...
Page 516: Vehicle Loading
Customer Information and Reporting Safety Defects Tire Information (U.S.A.) Overloading makes a vehicle harder to Vehicle Loading drive and control. It also increases the distance required for stopping. In cases ▼ Vehicle Loading of serious overloading, brakes can fail completely, particularly on steep WARNING grades.
Page 517 Customer Information and Reporting Safety Defects Tire Information (U.S.A.) from the payload listed on the tire If the weight of the occupant increases, label in order to be accurate. the cargo weight limit decreases by that much. SAMPLE GAW (Gross Axle Weight) is the total weight placed on each axle (front and rear) - including vehicle curb weight and all payload.
Page 518 Customer Information and Reporting Safety Defects Tire Information (U.S.A.) Do not use replacement tires with WARNING lower load carrying capacities than the originals because they may lower the Never Exceed Axle Weight Rating vehicle's GVWR and GAWR Limits: limitations. Replacement tires with a Exceeding the Safety Certiﬁcation higher limit than the originals do not Label axle weight rating limits is...
Page 519: Steps For Determining The Correct Load Limit
Customer Information and Reporting Safety Defects Tire Information (U.S.A.) Steps for Determining the Correct Load Limit ▼ Steps for Determining the Correct Load Limit Steps for Determining Correct Load Limit- (1) Locate the statement “The combined weight of occupants and cargo should never exceed XXX kg or XXX lbs.”...
Page 520: Declaration Of Conformity
Customer Information and Reporting Safety Defects Declaration of Conformity Declaration of Conformity ▼ Keyless Entry System/Immobilizer System ▼ Tire Pressure Monitoring System 8-32...
Page 521 Customer Information and Reporting Safety Defects Declaration of Conformity ▼ HomeLink Wireless Control System 8-33...
Page 522 Customer Information and Reporting Safety Defects Declaration of Conformity ▼ Radio System 8-34...
Page 523 Customer Information and Reporting Safety Defects Declaration of Conformity ▼ Audio System 8-35...
Page 524 Customer Information and Reporting Safety Defects Declaration of Conformity 8-36...
Page 525 Customer Information and Reporting Safety Defects Declaration of Conformity ▼ Data Communication System U.S.A. 8-37...
Page 526 Customer Information and Reporting Safety Defects Declaration of Conformity Canada 8-38...
Page 527 Customer Information and Reporting Safety Defects Declaration of Conformity 8-39...
Page 528 Customer Information and Reporting Safety Defects Declaration of Conformity ▼ Front Radar Sensor System 8-40...
Page 529 Customer Information and Reporting Safety Defects Declaration of Conformity ▼ Front Side Radar Sensor System/Rear Side Radar Sensor System 8-41...
Page 530 Customer Information and Reporting Safety Defects Declaration of Conformity ▼ Charging 8-42...
Page 531 Speciﬁcations Technical information about your Mazda. Identiﬁcation Numbers....9-2 Speciﬁcations......9-3 Vehicle Information Labels... Speciﬁcations......9-3 ..........9-2...
Page 532 Speciﬁcations Identiﬁcation Numbers ▼ Chassis Number Vehicle Information Open the cover shown in the ﬁgure to Labels check the chassis number. ▼ Vehicle Identiﬁcation Number The vehicle identiﬁcation number legally identiﬁes your vehicle. The number is on a plate attached to the cowl panel located on the left corner of the dashboard.
Page 533 Speciﬁcations Speciﬁcations Speciﬁcations ▼ Charge System Item Servicing data Input power 110 - 240 V AC (single phase) Rated frequency 60 Hz Maximum rated electrical current 32 A (normal charge) Maximum power consumption 7.68 kVA (normal charge) Maximum charging current 100 A (quick charge) Electrical leakage detection current for control box including genuine...
Page 534 1 Check the battery installed on the vehicle and use a battery with an equal or higher performance. However, the performance of the battery may vary even among the same battery types, consult an Authorized Mazda Dealer for replacement. ▼ Lubricant Quality Lubricant Classiﬁcation...
Page 535 NOTE The tires have been optimally matched with the chassis of your vehicle. When replacing tires, Mazda recommends that you replace tires of the same type originally ﬁtted to your vehicle. For details, contact an Authorized Mazda Dealer. Check the tire pressure label for tire size and inﬂation pressure.
Page 536 MEMO...
Page 537 Index 10-1...
Page 538 Index Pad wear indicator....4-56 Parking brake....... 4-52 Accessory Socket....... 5-39 Warning light......4-55 Actions to take if the remaining high Brake Override System....4-56 voltage battery power is completely Brake Override Warning Beep..7-39 depleted........7-16 Brake System Warning Beep..7-39 Active Driving Display....4-24 Break-In Period......
Page 539 Index Climate Control System Operation Door-ajar Warning Beep....7-40 Area Driver Attention Alert (DAA)..4-100 Air Intake Selector Icon...5-6 Driver Monitoring Camera..4-81 AUTO Switch......5-4 Driver Monitoring (DM)...4-102 Power Switch (System On/ Driving on Uneven Road....3-60 Off)........5-5 Driving Tips.......3-56 Temperature Control Switch/ Break-in period....
Page 540 Index Starting the EV System.... 4-5 Panel description....6-29 Starting the EV System When the Replacement......6-27 Key Battery is Dead....4-6 When Stopping the EV System........4-8 Gauges........4-9 Excessive Speed Warning... 7-40 Glove Compartment....5-45 Exterior Care......6-34 Aluminum wheel maintenance......
Page 541 Index Compass display....4-18 Vinyl upholstery Dashboard illumination..4-14 maintenance......6-40 Distance-to-full Discharge..4-16 Interior Lights......5-37 High Voltage Battery Power Luggage compartment light... 5-37 Gauge........4-14 Map lights......5-37 High Voltage Battery Temperature Overhead lights....5-37 Gauge........4-13 i-ACTIVSENSE......4-68 Indication/indicator lights..4-21 Active safety technology..4-68 Instantaneous Energy Efficiency ..
Page 542 Index Mazda Radar Cruise Control with Vehicle identiﬁcation Stop & Go function (MRCC with number........9-2 Stop & Go function)... 4-111 Lane Departure Warning sound.. 7-40 Pre-crash safety technology... 4-68 Lane Departure Warning System Rear Cross Traffic Alert (LDWS)........4-84 (RCTA)....... 4-107 Lane-change Signals....
Page 543 Index Mazda Radar Cruise Control with Stop & Go function (MRCC with Stop Parking Brake......4-52 & Go function)......4-111 Parking Sensor System..... 4-198 Close proximity warning..4-113 Parking Sensor OFF Switch...4-201 Display indication....4-112 Sensor detection range..4-200 Setting the system....4-114 Power Steering......4-67 Stop hold control....
Page 544 Index Registering Your Vehicle in A Foreign Selector lever not in P reminder Country........8-14 warning beep......7-39 Remaining High Voltage Battery Shift Control System Power Warning Beep....7-38 Driving tips......4-32 Replacement Selector lever operation..4-28 Fuse........6-27 Selector lever position Key battery......6-21 functions......4-26 Light bulbs......
Page 545 Index Luggage compartment..5-46 Trailer towing....... 3-61 Overhead console....5-45 Towing Description....7-18 Storage pocket..... 5-45 Traction Control System (TCS)..4-64 Storage Pocket......5-45 TCS OFF Indicator Light..4-64 Sunshade........3-53 TCS OFF switch....4-65 Sunvisors........5-36 TCS/DSC indicator light..4-64 Traffic Sign Recognition System (TSR)........
Page 546 Blade........6-17 Liftgate Door-lock Switch Replacing windshield wiper Inoperable Warning Beep..7-38 blades........6-15 Lights-on reminder....7-37 Mazda Radar Cruise Control with Stop & Go function (MRCC with 360°View Monitor....4-144 Stop & Go function) system How to use the system..4-151 warnings......7-40...

Mazda MX-30 2022 Owner's Manual Leaflet

3 Before Driving

Electric Vehicles

Keys

Advanced Keyless Entry System

System

Doors and Locks

Mirrors

Windows

Security System

Driving Tips

Towing

4 When Driving

Starting and Stopping the EV System

Instrument Cluster and Display

Selector Lever Position Functions

Switches and Controls

Brake

Abs/Tcs/Dsc

Power Steering

I-ACTIVSENSE

Cruise Control

Tire Pressure Monitoring System

(Tpms)

Rear View Monitor

Parking Sensor System

5 Interior Features

Climate Control System

Mazda Connect

Interior Equipment

6 Maintenance and Care

Essential Information

Scheduled Maintenance

Owner Maintenance

Appearance Care

7 If Trouble Arises

Parking in an Emergency

Flat Tire

Troubleshooting for Charging

Depleted Lead-Acid Battery

Fully Discharged High Voltage Battery

Emergency Starting

Emergency Towing

Warning/Indicator Lights and Warning Sounds

When Liftgate Cannot be Opened

Active Driving Display Does Not Operate

Windshield Wipers Operate at High Speed

Customer Information and Reporting 8

Customer Assistance

Mazda Importer/Distributors

Reporting Safety Defects

Warranty

Cell Phones

Event Data Recorder

Recording of Vehicle Data

Uniform Tire Quality Grading System (UTQGS)

Tire Information (U.S.A.)

Declaration of Conformity

Quick Links

Chapters

Related Manuals for Mazda MX-30 2022

Summary of Contents for Mazda MX-30 2022
