AV2000/3000/4000/5000
Large effective area (mm²)
AV2000/ 20 (Body size: 1/4)
AV3000/ 37 (Body size: 3/8)
AV4000/ 61 (Body size: 1/2)
AV5000/113 (Body size: 3/4)
AV5000/122 (Body size: 1 )
F.R.L. combinations
F.R.L. combination
AC2000 AC2500 AC3000 ∗AC4000
Soft start-up valve
AV2000
AV3000
AV4000
∗ Except AC4000-06
AV5000
New
New
AV5000
Series introduced!
A start-up valve that gradually increases supply pressure
during start up and rapidly exhausts system air when the
supply air is shut off
Manual supply/exhaust function
Modular with F.R.L. combinations
AC5000 AC6000
Soft Start-up Valve
Low power consumption
SMC
F.R.L. combination
CAT.ES40-39 B
Soft start-up
valve
