1.

GENERAL INSTRUCTIONS

The C-LOGIC 95 is a non-contact-type digital tachometer with stable
perfor-mance, high reliability and high safety performance. The core
component of the meter is a compact high-speed integrated chip. The meter
calculates the exact rotation speed value through a reflected light sampling
process. With a compact design, it is a meter with superior performance. The
meter will display rotation speeds from 50RPM---99999RPM. The LCD is
backlit to allow making and reading measurements in low light conditions.
2. PANEL DIAGRAM (SEE FRONT VIEW)
(1) Laser emission and receiving window
(2) LCD display
(3) Instrument case
(4) Instrument power switch key
(5) Maximum and minimum switch key
(6) Hold key
(7) Measurement key
(8) Data storage key
(9) Data storage read key
(10) Backlight key
(11) Storage read number plus key
(12) Storage read number minus key
