- Page 1 FOR MODEL NUMBER MSD674 TO OPERATOR'S MANUAL SENTINEL SERIES/ TACTICAL OPERATIONS DRY SUIT MOBILITY BASED SIZING™ In order to take your measurements correctly and select the appropriate size, please follow the instructions provided on our website at: www.mustangsurvival.com/mobility...
-
Page 2: Table Of Contents
TABLE OF CONTENTS DESCRIPTION SENTINEL™ SERIES TACTICAL OPERATIONS DRY SUIT ....1-3 SENTINEL™ SERIES SIZING GUIDE ............3 INSTRUCTIONS FOR USE ................4 CCS™ ADJUSTABLE NECK SEAL ............4 NEOPRENE WRIST SEAL FITTING ............4-5 ATTACHING SUSPENDERS .................6 DONNING & DOFFING THE DRY SUIT ........... 7-8 CLEANING AND MAINTENANCE ............ -
Page 3: Description
DESCRIPTION MSD674 TO – SENTINEL™ SERIES TACTICAL OPERATIONS DRY SUIT THE SENTINEL™ SERIES TACTICAL OPERATIONS DRY SUIT IS A WATERPROOF & BREATHABLE CONSTANT WEAR DRY SUIT IDEAL FOR USERS ENGAGED IN POTENTIALLY HOSTILE MILITARY AND LAW ENFORCEMENT MARITIME OPERATIONS WHERE THERE IS A NEED FOR IMMERSED HYPOTHERMIA PROTECTION THAT WON’T HINDER THEIR PRIMARY MISSION. - Page 4 • 2 expanding thigh pockets with Velcro® closures that include internal stabilizers for small equipment. • 2 expanding calf cargo pockets with Velcro® closures • Large leg and wrist over cuffs have Velcro® closures for adjustability • 1 Package of YKK® lubricant MUSTANG SURVIVAL/ SENTINEL SERIES – TACTICAL OPERATIONS DRY SUIT...
-
Page 5: Sentinel™ Series Sizing Guide
Every Sentinel™ Series Tactical Operations Dry Suit produced by Mustang Survival is leak tested to ensure waterproof integrity prior to leaving our factory. All suits are 100% tested to ensure the highest level of reliability and performance. -
Page 6: Instructions For Use
This manual supplies instructional, routine maintenance and safety information for the Sentinel™ Series Tactical Operations Dry Suit. ADJUSTABLE NECK SEAL ™ Mustang Survival's patented Closed Comfort System CCS can be ™ worn loose to provide comfort out of the water and can quickly be drawn tight to keep the water out. - Page 7 If seal trimming is required, proceed as follows: CAUTION: Trim seals with extreme caution. A smooth trim line is essential. Excessive or careless trimming could result in loose seals that leak and necessitate replacement. Avoid nicking seal fabric, as this could result in tearing the seals when donning and doffing, and also could result in skin irritation.
-
Page 8: Attaching Suspenders
5. Repeat these steps for the other attachment point. 6. Use the suspender strap ends to adjust for a secure comfortable fit. FIGURE 4 FIGURE 5 FIGURE 6 MUSTANG SURVIVAL/ SENTINEL SERIES – TACTICAL OPERATIONS DRY SUIT... -
Page 9: Donning & Doffing The Dry Suit
DONNING & DOFFING THE DRY SUIT Before donning the suit, ensure that appropriate undergarments have been selected for the conditions. CAUTION: ALWAYS DON THE DRY SUIT ON A CLEAN SURFACE SUCH AS A TOWEL OR TARP TO AVOID ATTRACTING DEBRIS. PEBBLES, SAND, DIRT AND OTHER DEBRIS ON THE GROUND CAN CAUSE DAMAGE TO DRY SUIT SOCKS AND COMPROMISE THE SUIT’S INTEGRITY. - Page 10 7. Pull suit down past hips and slide legs from the suit. 8. Follow the cleaning and storage instructions for the suit. CAUTION: PULLING ON THE WRIST SEAL MAY DAMAGE THE SEAL. NOTE: IF WEARING SUSPENDERS, REMOVE SUSPENDERS PRIOR TO PROCEEDING MUSTANG SURVIVAL/ SENTINEL SERIES – TACTICAL OPERATIONS DRY SUIT...
-
Page 11: Cleaning And Maintenance
CLEANING AND MAINTENANCE CLEANING 1. Thoroughly rinse your dry suit after every use. CAUTION: DO NOT DRY CLEAN. DO NOT IRON. DO NOT BLEACH. 2. Treat stains with a pre-wash treatment such as Shout or Spray ‘n Wash ® ® Follow the manufacturer’s instructions. - Page 12 3. Repeat before long term storage. CAUTION: DO NOT LUBRICATE THE ZIPPER TEETH. NOTE: DO NOT DISCARD THE BLISTER PACKAGE. THE MOLYKOTE® LUBRICANT CAN BE STORED IN THE ZIPLOCK BAG AND REUSED FIGURE 9 FIGURE 10 MUSTANG SURVIVAL/ SENTINEL SERIES – TACTICAL OPERATIONS DRY SUIT...
-
Page 13: Storing The Dry Suit
It is extremely important that damaged suits are handled in accordance with repair requirements. The Sentinel Series Water Rescue Dry Suit takes advantage of Mustang’s Rapid Repair Technology™ enabling users to self-replace neck and wrist seals and repair small leaks in an hour or less. For... -
Page 14: Accessories
ACCESSORIES The following accessories are available for your Sentinel Series Boat Crew Dry Suit: NEOPRENE SURVIVAL HOOD (PART # MA7348) SENTINEL DRY SUIT LINER (PART # MSL600) SENTINEL FEMALE DRY SUIT LINER (PART # MSL601) YKK ZIPPER LUBRICANT (PART # MA0094) SENTINEL™... -
Page 15: Warranty Information
(the Customer End user) under normal and intended conditions and use. Proof of purchase may be required at the discretion of Mustang Survival. Products, which, in the sole judgment of Mustang Survival, have... - Page 16 We build gear that saves lives and fuels exploration. www.mustangsurvival.com DO NOT REMOVE PRIOR TO SALE. MUSTANG SURVIVAL AND SEAHORSE DESIGN ARE ALL REGISTERED TRADEMARKS OF MUSTANG SURVIVAL ULC. A BRAND OF THE SAFARILAND GROUP © 2016 SAFARILAND, LLC 052813 HT0674 REV 24MAR16...
