FOR MODEL NUMBERS MD2014 AND MD2016
OWNER'S MANUAL
MD2014
INFLATABLE PFD
MANUAL INFLATION MODEL
USCG APPROVALS:
RECREATIONAL: TYPE III
UNINSPECTED COMMERCIAL VESSELS:
TYPE V
DO NOT REMOVE PRIOR TO SALE
HT3159 REV 15JULY2020
MD2016
INFLATABLE PFD
MANUAL WITH AUTOMATIC BACKUP
INFLATION MODEL
USCG APPROVALS:
RECREATIONAL: TYPE III
UNINSPECTED COMMERCIAL
VESSELS: TYPE V
I

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MD2014 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Mustang Survival MD2014

Summary of Contents for Mustang Survival MD2014

  • Page 1 FOR MODEL NUMBERS MD2014 AND MD2016 OWNER'S MANUAL MD2014 INFLATABLE PFD MD2016 INFLATABLE PFD MANUAL INFLATION MODEL MANUAL WITH AUTOMATIC BACKUP INFLATION MODEL USCG APPROVALS: RECREATIONAL: TYPE III USCG APPROVALS: RECREATIONAL: TYPE III UNINSPECTED COMMERCIAL VESSELS: TYPE V UNINSPECTED COMMERCIAL...

  • Page 2: Table Of Contents

    SPECIAL CONSIDERATIONS FOR AUTOMATIC DEVICES (MD2016) .. 6 DEFLATING THE INFLATABLE PFD ..............7 USAGE BELOW FREEZING ..................7 RE-ARMING YOUR PFD (MD2014) ..............8 RE-ARMING YOUR PFD (MD2016) ..............9 REPACKING ......................12 IS YOUR PFD IN GOOD AND SERVICEABLE CONDITION? ....13 CARE AND MAINTENANCE INSTRUCTIONS ..........
  • Page 3 HOW AND WHY TO TEST YOUR PFD ............15 HOW DO YOU TEST YOUR PFD USING THE AUTOMATIC INFLATOR? (MD2016) ..........15 HOW DO YOU TEST YOUR PFD USING THE MANUAL INFLATOR? ................16 HOW DO YOU TEST YOUR PFD USING THE ORAL INFLATOR? .................. 17 WEAR YOUR PFD ....................18 HYPOTHERMIA......................18 HOW HYPOTHERMIA AFFECTS MOST ADULTS .......18...

  • Page 4: Approval Conditions And Carriage Regulations

    Not recommended for non-swimmers or weak swimmers. Users of inflatable PFDs must be at least 16 years old. Commercial - Models MD2014 and MD2016 are U.S. Coast Guard approved Type V inflatable PFDs, approved ONLY WHEN WORN for use on uninspected commercial vessels less than 40 feet in length not carrying passengers for hire as a substitute for a Type III PFD when used in accordance with this owner’s manual.

  • Page 5: Why Are Pfds Required Safety Equipment

    The Inflatable PFD is designed to offer maximum mobility with minimum bulk. The Inflatable PFD (MD2014) can be inflated either manually by jerking a pull-tab, or orally by mouth. The Inflatable PFD (MD2016) can be inflated either automatically during water immersion, manually by jerking a pull-tab, or orally by mouth.

  • Page 6: Readiness Checklist

    Automatic In ator Pull Tab Pull Tab MD2016 Service Indicator MD2014 Service Indicator SERVICE INDICATORS FIGURE 1 3. Ensure the oral-inflation dust cap is in the stowed position (Fig. 6). 4. For the MD2016 only - Ensure the bobbin is valid. The PFD, or bobbin, must have been purchased within the last three (3) years.

  • Page 7: Sizing And Fit

    Your Inflatable PFD is ready for use if all applicable boxes are checked. CONTACT YOUR MUSTANG DEALER IF YOU HAVE ANY CONCERNS ABOUT THE READINESS OF YOUR INFLATABLE PFD. SIZING AND FIT This PFD provides a minimum of 22.5 lbs of buoyancy when inflated and is designed for wearers over 16 years of age, with a chest range of 30-52 inches (76-132 cm) weighing over 80 pounds (36 kg).

  • Page 8: Inflating Your Inflatable Pfd

    Activate the inflation system by jerking firmly downward on the pull-tab (Fig. 3). The Inflatable PFD should fully inflate within 5 seconds. Manual Inflator Automatic Inflator MD2014 MD2016 PULL-TAB FIGURE 3 2. Automatic Backup Inflation (MD2016 only) Inflation will occur automatically within 10 seconds after the inflator is immersed in water.

  • Page 9: Special Considerations For Automatic Devices (Md2016)

    3. Oral Inflation Properly armed and inspected Inflatable PFDs will inflate when manually or automatically activated. However, you can fully inflate the Inflatable PFD by mouth (Fig. 4) should inflation not occur, or if you are in a non-emergency situation. To orally inflate the Inflatable PFD, first locate the oral inflation tube by opening the wearer ’s left...

  • Page 10: Deflating The Inflatable Pfd

    DEFLATING THE INFLATABLE PFD To deflate the Inflatable PFD, reverse the oral-inflation tube dust cap and insert it into the valve. The dust cap will not lock in the deflate position so it is necessary to hold it in place (Fig. 5). 2.

  • Page 11: Re-Arming Your Pfd (Md2014)

    RE-ARMING YOUR PFD (MD2014) A RE-ARM KIT (MA2014) IS REQUIRED FOR THIS PROCEDURE. FOLLOW INSTRUCTIONS IN THE EXACT SEQUENCE BELOW. Open inflator cover flap so that manual inflator is exposed (Fig. 7). 2. Remove the cylinder/bayonet assembly by rotating counterclockwise and then pull out. Discard the used cylinder/ bayonet assembly.

  • Page 12: Re-Arming Your Pfd (Md2016)

    6. Refold the Inflatable PFD in accordance with the Repacking section (see “Repacking” on page 12). YOUR INFLATABLE PFD (MD2014) IS NOW READY FOR MANUAL USE RE-ARMING YOUR PFD (MD2016) A RE-ARM KIT (MA2014) WITH A VALID BOBBIN INSTALL-BY-DATE (CHECK RE-ARM KIT PACKAGING) IS REQUIRED FOR THIS PROCEDURE.
  • Page 13 MD2016 Automatic Inflator Step 3 Cylinder Step 2 Sensor Ring Yellow Bobbin Step 9 (white side up) Bayonet Step 3 HOUSING*** Step 10 Step 4 O-Ring Step 9 Housing Shoulder Step 8 Pins Service Indicator Step 11 Lever Step 10 Pull Tab Service Indicator: If GREEN, unit is operable...
  • Page 14 7. IMPORTANT! Bobbin (yellow) must be installed into the HOUSING (***Figure 9), white side up, aligning the slots on the bobbin with the ridges inside the threaded housing. The bobbin will slide in easily if installed correctly. 8. Install cap by screwing clockwise until it meets the housing shoulder.

  • Page 15: Repacking

    Figure 11 MD2017 Automatic Inflator Cylinder Piercing Service Indicator 1/8 Turn Groove Pull-cord FIGURE 11 CYLINDER INSTALLATION REPACKING Repacking should only be done after deflating and re-arming the PFD. View Status Indicator FOLD SIDES FIGURE 12 CORRECT FIGURE 13 Fold sides (A) and (B) outward along dotted lines. Secure with Velcro™.

  • Page 16: Is Your Pfd In Good And Serviceable Condition

     Examine the single point status indicator ensuring it is green. If the indicator is red, your PFD needs to be re-armed (see “Re-arming Your PFD (MD2014)” on page 8 or see “Re-arming Your PFD (MD2016)” on page 9).  Ensure the manual pull-tab is accessible.

  • Page 17: Cleaning And Storing Of Your Inflatable Pfd

    If any item shows signs of damage, perform inspections listed in “Every Six (6) Months” inspection details. If in doubt, contact Mustang Survival customer service.  For MD2016 only. Ensure the current date is not three (3) years past the date on the bobbin.

  • Page 18: How And Why To Test Your Pfd

    For Both MD2014 and MD2016 Check the manual inflation system by first removing the CO cylinder/ bayonet assembly: rotate counterclockwise and pull out. On the...

  • Page 19: How Do You Test Your Pfd Using The Manual Inflator

    M7. Let the Inflatable PFD dry thoroughly. Re-arm and Repack the PFD (see “Re-arming Your PFD (MD2014)” on page 8 or see “Re-arming Your PFD (MD2016)” on page 9 and see “Repacking” on page 12).

  • Page 20: How Do You Test Your Pfd Using The Oral Inflator

    Inflatable PFD using the oral inflator. O8. Let the Inflatable PFD dry thoroughly. Re-arm (for your model) and Repack the PFD (see “Re-arming Your PFD (MD2014)” on page 8 or see “Re-arming Your PFD (MD2016)” on page 9 and...

  • Page 21: Wear Your Pfd

    WEAR YOUR PFD In approximately 80 percent of all boating fatalities, the victims were not wearing a PFD. Most fatal accidents happen on calm sunny days. This Inflatable PFD is much more comfortable to wear than other PFD types. Get into the habit of wearing this Inflatable PFD. Non-swimmers and children especially should wear a hybrid or non- Inflatable PFD at all times when on or near the water.

  • Page 22: Each Of These Devices Is Intended To Help You Save Your Own Life

    2. Do not attempt to swim unless it is to reach a nearby craft, fellow survivor, or a floating object on which you can lean or climb. Swimming increases the rate of body heat loss. In cold water, drown-proofing methods that require putting your head in the water are not recommended.

  • Page 23: Inflatable Pfd Safety Accessories

    7. If your Inflatable PFD is wet, allow it to dry thoroughly before storing it. Store it in a well-ventilated area. 8. Do not dry your Inflatable PFD in front of a radiator or other source of direct heat. INFLATABLE PFD SAFETY ACCESSORIES MA2014 Re-arm Kit —...
  • Page 24 MUSTANG ENGINEERED For 50 years Mustang Survival has been engineering high-performance marine gear for military, coast guard, and rescue personnel. With a focus on applied research and field-testing, we’re committed to the protection and enhancement of those who push themselves to extremes.
