Smoke hollow 30167G Assembly & Operation

Smoke hollow 30167G Assembly & Operation

Hide thumbs Also See for 30167G:

Advertisement

Quick Links

Download this manual
FOR YOUR SAFETY - IF YOU SMELL GAS:
1. SHUT OFF GAS TO THE APPLIANCE.
2. OPEN SMOKER DOOR.
3. EXTINGUISH ANY OPEN FLAME.
4. PERFORM A GAS LEAK TEST.
5. IF ODOR CONTINUES, KEEP AWAY FROM THE APPLIANCE AND IMMEDIATELY CALL YOUR
FIRE DEPARTMENT.
FAILURE TO FOLLOW THESE INSTRUCTIONS AND WARNINGS COULD RESULT IN FIRE OR
EXPLOSION, WHICH COULD CAUSE PROPERTY DAMAGE, PERSONAL INJURY OR DEATH.
1. Never operate this appliance unattended.
2. Never operate this appliance within 10 feet (3.05 m) of any other gas cylinder.
3. Never operate this appliance within 25 feet (7.5 m) of any flammable liquid.
4. Heated liquids remain at scalding temperatures long after the cooking process. Never touch cooking
appliance until liquids have cooled to 115°F (45°C) or less.
5. If a fire should occur, keep away from the appliance and immediately call your fire department. Do not
attempt to extinguish an oil or grease fire with water.
Failure to follow these instructions could result in fire, explosion or burn hazard, which could cause property
damage, personal injury or death.
This instruction manual contains important information necessary for the
proper assembly and safe use of the appliance.
Read and follow all warnings and instructions before assembling and using the
appliance.
Follow all warnings and instructions when using the appliance.
Keep this manual for future reference.
Installer - leave the manual with the consumer.
DANGER
DANGER
DANGER
DANGER
DANGER
DANGER
Assembly
& Operation
30167G/34167G
34166GC/38207G
Gas Smoker

Advertisement

loading
Need help?

Need help?

Do you have a question about the 30167G and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Smoke hollow 30167G

Summary of Contents for Smoke hollow 30167G

  • Page 1 Assembly & Operation 30167G/34167G 34166GC/38207G Gas Smoker DANGER DANGER FOR YOUR SAFETY - IF YOU SMELL GAS: 1. SHUT OFF GAS TO THE APPLIANCE. 2. OPEN SMOKER DOOR. 3. EXTINGUISH ANY OPEN FLAME. 4. PERFORM A GAS LEAK TEST. 5. IF ODOR CONTINUES, KEEP AWAY FROM THE APPLIANCE AND IMMEDIATELY CALL YOUR FIRE DEPARTMENT.
  • Page 2 Outdoor Leisure Products, Inc. 5400 Doniphan Drive Neosho, MO 64850 Toll Free: 866-475-5180 8:30am to 4:30pm, Central Time Monday through Friday...
  • Page 3 DANGER · This smoker is for OUTDOOR USE ONLY. · Accessory attachments and cookware not manufactured or supplied by Smoke Hollow for this · Never operate this smoker unattended. smoker are not recommended for use. · The use of alcohol, prescription or non prescription ·...
  • Page 4 READ ALL SAFEGUARDS AND INSTRUCTIONS THOROUGHLY! YOUR SAFETY IS VERY IMPORTANT - FAILURE TO FOLLOW PROPER PROCEDURES AND SAFEGUARDS MAY RESULT IN PROPERTY DAMAGE, PERSONAL INJURY OR DEATH. DANGER DANGER DANGER DANGER · Do not obstruct flow of combustion and ventilation. ·...

  • Page 5: Before Assembly

    Before Assembly Parts list for 34167G Read all safeguards and assembly instructions before assembling and operating your smoker. Before assembling your new smoker, unpack all the parts from the box. Carefully remove all packing material and lay out all the parts for easy access and identification. Do not discard the carton or packaging until your smoker is fully assembled and operating to your satisfaction.
  • Page 6 Before Assembly Parts list for 34166GC Read all safeguards and assembly instructions before assembling and operating your smoker. Before assembling your new smoker, unpack all the parts from the box. Carefully remove all packing material and lay out all the parts for easy access and identification. Do not discard the carton or packaging until your smoker is fully assembled and operating to your satisfaction.
  • Page 7 Before Assembly Parts list for 38207G Read all safeguards and assembly instructions before assembling and operating your smoker. Before assembling your new smoker, unpack all the parts from the box. Carefully remove all packing material and lay out all the parts for easy access and identification. Do not discard the carton or packaging until your smoker is fully assembled and operating to your satisfaction.
  • Page 8 Before Assembly Parts list for 30167G Read all safeguards and assembly instructions before assembling and operating your smoker. Before assembling your new smoker, unpack all the parts from the box. Carefully remove all packing material and lay out all the parts for easy access and identification.
  • Page 9 Assembly Assembly Step 1: Locate : Cabinet Assembly [1], Door Panel [2] Note : The door panel [2] is attached to the cabinet assembly [1]. Tools Needed : None Procedure Remove the door panel [2] from the cabinet assembly [1] by lifting straight up on the door.
  • Page 10 Assembly Step 3: Locate : Control panel assembly [3], Two 1/4-20x1/2” Bolts [13A] (2 Remaining from previous step). Tools Needed : Phillips head screwdriver 1. Place the control panel assembly between the front legs as shown.There are slots on the control panel that fit around the legs and line up with the bolt holes 2.Be sure all the tabs on the back side of the control panel are captured around the legs as shown below.
  • Page 11 Assembly Step 5: Locate : Damper [5], one 10-24x1/2” Bolt [13C], 10-24 nut[13E].10-24 Lock washer[13F] Tools Needed : Phillips head screwdriver and 3/8” wrench or pliers Procedure From the outside of the cabinet, insert a 10-24x1/2” bolt [13C] through the mounting hole for the damper. From the inside of the smoker cabinet, place the damper [5] over the vent hole in the back of the cabinet as shown.
  • Page 12 Assembly Step 6: Locate : Two Carry Handles [13J], one S-Hook(13H), Four 1/4-20x5/8” Bolts [13B], and Four 1/4-20 Flange Nuts [13D] Tools Needed Phillips head screwdriver and a 7/16” wrench or pliersput Procedure Put the ring end of the S-hook on one carry handle [13J]as shown.
  • Page 13 Then thread the bolts into the handle (a). Securely tighten two bolts. Step 8:(30167G Model) Locate: 30167G Door handle kit [13K] Note: The door handle kit [13K] consists of one door handle (a), two 2” spacers (b) two 10-24x2 3/8” bolts (c), two 10-24 lock washers (d).
  • Page 14 From the inside of the door panel. Step 10: 12/12A Locate 34167G/30167G: Twelve short grid racks [12], One Wood Box Rack [7].Four Cooking Grids [11]. 34166GC: Ten short grid racks [12], One Wood Box Rack [7]. Three Cooking Grids [11].
  • Page 15 Set the wood chip box [8] onto the wood chip box rack already inside the smoker cabinet. Place the water bowl [10] onto the lowest rack position inside the smoker cabinet, just above the wood chip box. 34167G/34166GC Model 38207G Model 30167G Model...
  • Page 16 This is to prevent the regulator from collecting debris from the ground during storage and while moving the smoker. 30167G Model 34167G/34166GC Model 38207G Model Assembly of your smoker is now complete. The following section refers to LP gas cylinder installation and use.
  • Page 17 Connecting the LP Gas Cylinder DANGER DANGER ALL INSTRUCTIONS AND SAFEGUARDS MUST BE FOLLOWED TO PREVENT FIRE, PROPERTY DAMAGE, OR PERSONAL INJURY. IMPORTANT: Any fuel supply cylinder used must be constructed and marked in accordance with specifications for propane cylinders of the U.S. Department of Transportation (DOT) CFR 49, or CAN/CSA B339.
  • Page 18 Connecting the LP Gas Cylinder DANGER DANGER ALL INSTRUCTIONS AND SAFEGUARDS MUST BE FOLLOWED TO PREVENT FIRE, PROPERTY DAMAGE, OR PERSONAL INJURY. Valve/pressure regulators are factory set to the correct Storage of the appliance indoors is only permissible if the operating pressures.
  • Page 19 Operation: Before Use Pre-Use Procedures Adding Wood Your smoker has been packaged with a retail store level To add wood before cooking, simply fill the wood chip point-of-purchase label that hangs on the front of the door box with your choice of flavoring hardwood chips. The panel.
  • Page 20 Operation: Lighting LP Gas Lighting Procedure 1. Check all connections for leaks using the leak test as explained on page 18. 2. Open the smoker door. 3. Check for any blockage to the venturi tube or burner. Remove any foreign objects or matter. 4.
  • Page 21 Operation: Cooking Damper Adjustments · Smoking for 2 to 3 hours at the ideal constant cooking Temperature maintenance is best controlled by different temperature of 225° to 250° F (110° to 120° C) will get the damper adjustments. The key to effective smoking is to best results.
  • Page 22 Operation: Cooking Temperature Chart Refer to this USDA Standard chart for properly cooked meat temperature. IMPORTANT: Measure the meat temperature using a meat probe thermometer. The heat indicator on the smoker gives the heat temperature inside the smoker cabinet, but is not an accurate measurement of the meat temperature. Celsius (ºC) Fahrenheit (ºF) Beef...

  • Page 23: After Use Safety And Maintenance

    After Use Safety and Maintenance DANGER DANGER Care and Maintenance to be performed before each use: · Use caution when lifting and moving the smoker to CAUTION : All care and maintenance procedures are to be avoid strains or back injury. 2 people are recommended performed only while the smoker is turned off and cooled.

  • Page 24: Limited Warranty

    This warranty may give you specific legal rights that vary by state. Outdoor Leisure Products, Inc. 5400 Doniphan Drive Neosho, MO 64850 ©2006 Outdoor Leisure Products, Inc. Smoke Hollow and the Smoke Hollow logo are trademarks of Outdoor Leisure Products, Inc. and are not to be used without express permission by Outdoor Leisure Products, Inc.
